Acta Optica Sinica, Volume. 45, Issue 13, 1306013(2025)
Development of High-Speed Optical Fiber Communication Technology (Invited)
As the cornerstone of global information transmission, optical fiber communication networks carry over 90% of worldwide data traffic. ITU’s telecommunication standardization sector (ITU-T) has initiated research and standardization of the beyond 1 Tbit/s (B1T) standard, which defines 1.6 Tbit/s as the foundational rate for next-generation high-speed optical fiber communication. To achieve thousands of kilometers of electrical relay-free transmission over conventional fibers, low-order modulation formats have become essential, while spectral expansion serves as a fundamental technical enabler. By taking 1.6 Tbit/s as an example: If quadrature phase shift keying (QPSK) modulation is adopted, the symbol rate will increase from about 130 GBaud in the 400 Gbit/s era to about 500 GBaud, expanding the spectral width to 48 THz. This necessitates leveraging multi-band spectral resources across O/E/S/C/L/U bands. It is foreseeable that high-speed optical communication will break free from the decades-long C-band-centric evolution model, fully embracing a new paradigm based on multi-band and ultra-wide spectrum technologies. Four key challenges emerge. 1) Fiber spectral capability: G.652.D and G.654.E fibers, with cutoff wavelengths of 1260 nm and 1530 nm respectively, support long-haul C+L band transmission but fall short for ultra-wide spectrum demands exceeding 24 THz. 2) Photonic device innovation: Core components like modulators and lasers require material-level breakthroughs to develop ultra-broadband devices covering O to U bands. 3) Optical amplification advancement: Novel doped fiber amplification technologies must evolve to meet system requirements for full optical domain amplification. 4) Passive component evolution: The frequency response characteristics of wavelength selective switches and filters will critically impact overall spectral efficiency. Collectively, high-speed optical communication is transitioning to a paradigm featuring “spectrum-expanded fibers and capacity-expanded systems”, marking a transformative leap in technological development.
G.652.D fiber, a critical derivative of standard single-mode fiber, has found extensive application in modern optical communication systems, particularly in metropolitan area networks and long-haul infrastructure. Compared to conventional G.652 fibers, G.652.D achieves reduced signal attenuation and distortion through refined manufacturing processes that minimize internal micro-defects. With its exceptional cost-performance ratio, G.652.D fiber is projected to remain the backbone for constructing high-capacity and long-distance optical communication networks for the foreseeable future. To address the demands of ultra-long-haul and high-capacity transmission, G.654 fiber was developed. This fiber features a pure silica core with a doped cladding, significantly reducing fiber loss by suppressing Rayleigh scattering. Introduced in the 2010s, G.654.E achieves a minimum loss of 0.14 dB/km while mitigating nonlinear effects by enlarging the core diameter and increasing the effective mode field area (Aeff). These enhancements drastically suppress stimulated Raman scattering (SRS) in C6T+L6T wide-spectrum systems, positioning G.654.E as a superior fiber choice for 400 Gbit/s and future Tbit/s-class ultra-long-haul backbone transmission. Currently, ultra-low-loss and large-effective-area fibers (e.g., G.654.E fiber) have only achieved a developed spectrum of 12 THz, which remains far from the ideal ultra-wide spectrum (24 THz). It is recommended that solid-core fibers adopt 24 THz spectrum expansion as a fundamental goal. Building on the basic fabrication processes of G.654.E fiber, research should focus on the relationship between cutoff wavelength, effective area, and attenuation to realize a new type of ultra-wide-spectrum fiber, addressing the near- to mid-term development requirements of high-speed optical communication. Given hollow-core fibers’ disruptive advantages over solid-core fibers across spectral bandwidth utilization, latency, attenuation, and nonlinearity suppression, high-speed optical communication systems leveraging hollow-core fiber architectures are poised to become the dominant paradigm in next-generation networks. Between 2018 and 2020, the Hollow-Core Fiber Group at the Optoelectronics Research Centre, University of Southampton, developed a 6-tube nested antinode-free hollow-core fiber (NANF-6) with an attenuation coefficient reduced to 0.28 dB/km. In 2022, the group further optimized the design, successfully fabricating a 5-tube double-layer nested antinode-free fiber (DNANF-5) with an attenuation of 0.174 dB/km, later pushing this value down to 0.138 dB/km. By 2024, in collaboration with Microsoft, the team achieved a groundbreaking attenuation coefficient of (0.08±0.03) dB/km, with their results published as a post deadline paper at OFC 2024. In August of the same year, researchers from Jinan University and China Mobile demonstrated another leap forward by fabricating an anti-resonant hollow-core fiber (AR-HCF) using a 4-tube truncated double-layer nested structure. This design achieved a record-low attenuation of 0.06 dB/km, surpassing the performance of conventional solid-core single-mode fibers and marking a historic milestone in ultra-low-loss optical fibers. In 2024, China Mobile leveraged the ultra-low backward Rayleigh scattering property of hollow-core fibers to propose a co-channel full duplex (CCFD) transmission concept. The team successfully demonstrated the world’s first 202.1 Tbit/s CCFD hollow-core fiber transmission, achieving identical performance to the unidirectional transmission while unlocking a fifth independent dimension, namely direction (following time slots, modulation, wavelength, and polarization) for optical multiplexing. In June 2024, China Mobile deployed the world’s first 800 Gbit/s hollow-core fiber transmission trial network in the Shenzhen?Dongguan metropolitan corridor, Guangdong Province. This pioneering field test rigorously validated the performance of AR-HCFs under real-world engineering stresses.
With the advancement of ultra-wide spectrum Tbit/s optical fiber communication technologies, higher demands are being placed on fiber transmission performance. Novel solid-core fibers must meet two core requirements: first, achieving ultra-low loss across E+S+C+L bands to ensure efficient full-spectrum transmission; second, optimizing cross-sectional design to satisfy wide-spectrum communication requirements for parameters including cutoff wavelength and dispersion. To this end, it is recommended to establish an ultra-wide spectrum fiber technology advancement task force to systematically research technical solutions and promote G.65X standard formulation, thereby laying the foundation for next-generation fiber standards. AR-HCFs, utilizing air as the transmission medium, demonstrate revolutionary advantages including theoretically ultra-low latency, ultra-low loss, minimal nonlinear effects, and ultra-wide usable spectral bandwidth. Current progress shows transmission loss in hollow-core fibers has been reduced to <0.1 dB/km, but large-scale deployment requires coordinated industrial chain development. Critical challenges remain in mass production industrialization and efficient field splicing with existing networks.
Get Citation
Copy Citation Text
Han Li, Yuqian Zhang, Mingqing Zuo, Dawei Ge, Yingying Wang, Wei Ding, Dong Wang, Liuyan Han, Dechao Zhang. Development of High-Speed Optical Fiber Communication Technology (Invited)[J]. Acta Optica Sinica, 2025, 45(13): 1306013
Category: Fiber Optics and Optical Communications
Received: Apr. 11, 2025
Accepted: May. 19, 2025
Published Online: Jul. 18, 2025
The Author Email: Han Li (lihan@chinamobile.com)
CSTR:32393.14.AOS250895
