Natural circulation systems are widely used in the nuclear industry for decay heat removal, post-accident containment cooling, and the cooling of radioactive waste storage facilities. Because a large number of spent fuel assemblies are densely arranged in the spent fuel pool, the spent fuel assemblies in the central area of the spent fuel pool can be approximated as having adiabatic boundary conditions. In the event of a coolant loss accident, the heat generated by the spent fuel assemblies can be exported only by the natural circulation of air.

This study aims to develop analytical models for fuel assembly natural circulation characteristics independent of the results of computational fluid dynamics (CFD) to investigate the natural circulation characteristics of spent fuel pools following a coolant loss accident.

Based on the experimental results of a fuel assembly pressure drop of a full-scale pressurized water reactor (PWR), the Darcy–Forchheimer model was firstly revised to predict the pressure drop of humid air flowing through the fuel assembly. Models for the fuel assembly natural circulation flow rate and peak cladding temperature were then established, and the effects of the relative humidity of air on the models were considered. Finally, these models were applied to investigating effects of total heating power, ambient temperature, and relative humidity on the natural circulation flow rate and peak cladding temperature of the fuel assembly.

The results show that the models accurately predict the natural circulation flow rate and peak cladding temperature of the fuel assembly under different heating powers, and the errors are less than 25% and 20%, respectively, as compared with the experimental measurement values.

The developed models in this study can be used to study the natural circulation characteristics of full-scale PWR fuel assemblies.
