High Power Laser and Particle Beams, Volume. 37, Issue 3, 035024(2025)

Research on resonant magnetic perturbation coil power supply based on active disturbance rejection control

Qian Jiang1,2, Ge Gao1, Shusheng Wang1、*, and Bei Ye1
Author Affiliations
  • 1Institute of Plasma Physics, Hefei Institutes of Physical Science, Chinese Academy of Sciences, Hefei 230031, China
  • 2University of Science and Technology of China, Hefei 230026, China
  • show less

    To solve the problems of the contradiction between response speed and overshoot and the poor anti-interference ability in the complex electromagnetic environment, the traditional PI controller is used in the resonant magnetic perturbations (RMP) coil power supply in tokamak. This paper adopts the linear active disturbance rejection control strategy to extract the differential quality of the reference signal in the transition differentiator to achieve fast current output without overshoot. Based on partially known mathematical model parameters of the power system, a fourth-order linear extended state observer is designed to estimate the disturbance of the system as a new state quantity to compensate the internal uncertainties and external disturbances of the power system. Finally, the simulation results show that compared with the traditional PI control strategy, the active disturbance rejection control strategy can effectively improve the dynamic characteristics of the output current signal. At the same time, it has stronger robustness and anti-interference characteristics in the case of complex environmental disturbance.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Qian Jiang, Ge Gao, Shusheng Wang, Bei Ye. Research on resonant magnetic perturbation coil power supply based on active disturbance rejection control[J]. High Power Laser and Particle Beams, 2025, 37(3): 035024

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Cutting-edge Interdisciplinary Technologies and Applications of Special Power Supplies

    Received: Aug. 14, 2024

    Accepted: Dec. 25, 2024

    Published Online: Apr. 29, 2025

    The Author Email: Shusheng Wang (wangss@ipp.ac.cn)

    DOI:10.11884/HPLPB202537.240263
