Optics and Precision Engineering, Volume. 33, Issue 6, 905(2025)

Femtosecond laser fused silica microhemispherical resonator release enhanced by a silicon reflective target

Xuye ZHUANG1, Qi QIAO1, Zhongfeng GAO1, Shilin HAN1, Youwang HU2, and Pinghua LI1、*
Author Affiliations
  • 1College of Mechanical Engineering, Shandong University of Technology, Zibo255000, China
  • 2College of Mechanical and Electrical Engineering, Central South University, Changsha410083, China
  • show less

    The fused silica micro-hemisphere resonator gyroscope is one of the most promising miniature vibratory gyroscopes, offering advantages such as a simple structure, high precision, and strong anti-interference capability. The micro-hemisphere resonator is the core component of the gyroscope, and its fabrication process is critical for performance. This study proposed a method to improve release quality while maintaining processing efficiency. In this study, a femtosecond laser was used for the release process, with the laser focused on the lower surface of the fused silica resonator through a silicon reflective target placed beneath it. This setup enhanced the intensity of the femtosecond laser inside the material, improving both the release speed and surface quality. A simplified mathematical model for laser intensity distribution inside fused silica and FDTD simulations were employed to analyze the laser energy field during femtosecond laser processing. The optimal process parameters were determined from the analysis. Experimental results show that when the single pulse energy is set at 2.2 μJ and the release speed is between 0.2 mm/s and 0.5 mm/s, a 300 μm thick quartz sheet was released with a release width ranging from 34.31 μm to 35.16 μm, and a surface roughness less than 400 nm. The release width increased by approximately 236% compared to the conventional focusing on the upper surface. This method effectively improves the release quality of the micro-hemisphere resonator, providing a solid technical foundation for the fabrication of high-quality fused silica resonators.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Xuye ZHUANG, Qi QIAO, Zhongfeng GAO, Shilin HAN, Youwang HU, Pinghua LI. Femtosecond laser fused silica microhemispherical resonator release enhanced by a silicon reflective target[J]. Optics and Precision Engineering, 2025, 33(6): 905

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Jan. 14, 2025

    Accepted: --

    Published Online: Jun. 16, 2025

    The Author Email:

    DOI:10.37188/OPE.20253306.0905
