Laser & Optoelectronics Progress, Volume. 62, Issue 15, 1522001(2025)

Process Method of Small-Tool Polishing for Mid-Spatial Frequency Error Smoothing of Conical Surface Component

Hang Fang1, Yuchuan Chen2, Lin Zhang2, Ye Ding1, Kailong Li2, Kuo Hai2, and Yunfei Zhang2、*
Author Affiliations
  • 1School of Mechanical Engineering, Shanghai Jiao Tong University, Shanghai 200204, China
  • 2Sichuan Precision and Ultra-Precision Machining Engineering Technology Center, Chengdu 610200, Sichuan , China
  • show less

    Currently, the conformal accuracy of small-tool smoothing polishing is low and does not satisfy the requirements of mid-spatial frequency (MSF) error smoothing. Hence, a small-tool polishing method for the MSF error smoothing of conical surface components based on a variable removal function is proposed. By performing theoretical modeling and finite-element simulation, the contact pressure distribution and the relative velocity model of conical surface components are established. Subsequently, based on Preston's equation, an annular removal function model is developed. By adopting the convolution principle and the constrained optimization algorithm, the dwell-time model for the small-tool polishing of conical surface components and its algorithm for conformal polishing are established. Small-tool polishing for the MSF error smoothing of conical surface components is investigated experimentally. The results show that the relative changes in the peak-to-valley value and root mean square are 13.7% and 9.3%, respectively, for a 310-mm-diameter conical mirror after smoothing. The peak value in the MSF band of the power spectral density curve decreased significantly, and the MSF error is effectively suppressed, thus confirming the correctness and feasibility of the proposed method.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Hang Fang, Yuchuan Chen, Lin Zhang, Ye Ding, Kailong Li, Kuo Hai, Yunfei Zhang. Process Method of Small-Tool Polishing for Mid-Spatial Frequency Error Smoothing of Conical Surface Component[J]. Laser & Optoelectronics Progress, 2025, 62(15): 1522001

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Optical Design and Fabrication

    Received: Nov. 25, 2024

    Accepted: Jan. 6, 2025

    Published Online: Jul. 2, 2025

    The Author Email: Yunfei Zhang (zhangyf306@yeah.net)

    DOI:10.3788/LOP242316

    CSTR:32186.14.LOP242316
