Chinese Optics, Volume. 18, Issue 4, 819(2025)

Optical transfer function measurement based on Hartmann wavefront sensor

Huang-ke ZHANG1,2, Zi-fan LI1,2, Wen-kai SHI1,2, Hong-min MAO1,2, Huan-jun LU1,2, Li-na FAN1,2, and Zhao-liang CAO1,2、*
Author Affiliations
  • 1Key Laboratory of Intelligent Optoelectronic Devices and Chips of Jiangsu Higher Education Institutions, School of Physical Science and Technology, Suzhou University of Science and Technology, Suzhou 215009, China
  • 2Advanced Technology Research Institute of Taihu Photon Center, School of Physical Science and Technology, Suzhou University of Science and Technology, Suzhou 215009, China
  • show less

    This study proposes a Hartmann wavefront sensor-based method for cost-effective, real-time measurement of Optical Transfer Function (OTF). First, an OTF measurement framework is established using wavefront data acquired through the Hartmann wavefront sensor. Subsequently, we design an optical configuration for OTF measurement, incorporating methodologies to determine depth of focus, characterize aberrations, and measure focal length. A dedicated calibration optical path is developed for objective lens aberration quantification, accompanied by systematic calibration procedures. Finally, an experimental setup is implemented to comprehensively assess lens performance, including Modulation Transfer Function (MTF), aberration, focal length, depth of focus, and chromatic aberration. The measurement results show that this method can achieve MTF measurement for the lens within a 0-1° field of view. The measured aberrations include astigmatism (0.114 λ), coma (0.128 λ), and spherical aberration (0.02 λ). At 0° field angle, the chromatic aberration values for red, green, and blue wavelengths are 0.047 λ, 0.055 λ, and 0.048 λ, respectively, increasing to 0.117 λ, 0.176 λ, and 0.154 λ at 1° field angle. The depth of focus is measured at 0.454 mm with a 2% error, while the focal length is determined to be 74.6 mm with a 0.8% error. These results confirm that the proposed measurement method enables accurate MTF characterization of optical lenses, providing a low-cost and real-time technical solution for the evaluation of MTF in optical systems.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Huang-ke ZHANG, Zi-fan LI, Wen-kai SHI, Hong-min MAO, Huan-jun LU, Li-na FAN, Zhao-liang CAO. Optical transfer function measurement based on Hartmann wavefront sensor[J]. Chinese Optics, 2025, 18(4): 819

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Jan. 18, 2025

    Accepted: Mar. 28, 2025

    Published Online: Aug. 13, 2025

    The Author Email:

    DOI:10.37188/CO.2025-0012
