Journal of Inorganic Materials, Volume. 39, Issue 12, 1339(2024)

Regulation of Low-dose Stannous Iso-octanoate for Two-step Prepared Sn-Pb Alloyed Perovskite Solar Cells

Yu WANG1,2, Hao XIONG2, Xiaokun HUANG3, Linqin JIANG2、*, Bo WU1、*, Jiansheng LI3, and Aijun YANG3
Author Affiliations
  • 11. School of Advance Manufacturing, Fuzhou University, Jinjiang 362200, China
  • 22. Key Laboratory of Green Perovskites Application of Fujian Province Universities, Fujian Jiangxia University, Fuzhou 350108, China
  • 33. PV Metrology Institute, Fujian Metrology Institute, Fuzhou 350003, China
  • show less

    In the preparation of Sn-Pb alloyed perovskite, a large amount of stannous fluoride (SnF2) additive is often employed to inhibit the oxidation of Sn2+ ions. However, excessive SnF2 deteriorates quality of the film, photoelectric conversion efficiency (PCE) and stability of the device. Therefore, the development of new antioxidants at low doses is essential to achieve high-performance Sn-Pb alloyed perovskite solar cells. In this study, a two-step process was used to prepare Sn-Pb alloyed perovskite film. In the first step, low-dose stannous iso-octanoate (SnOct2) was introduced to replace SnF2 to inhibit the oxidation of Sn2+. This study showed that the additive could improve the crystallization quality of the film, and the average grain size of the film with SnOct2 could reach 850 nm while the amount of grain boundaries was reduced. The film with the addition of SnOct2 still contained 93.5% Sn2+ after storage for 7 d in the glove box. And due to the excellent oxidation resistance of SnOct2, the device with the additional SnOct2 had a lower defect state density, which was reduced from 7.20×1015 to 4.74×1015 cm-3, inhibiting the non-radiative recombination. In addition, SnOct2 improved the surface energy levels of perovskite films. Finally, PCE of Sn-Pb alloyed perovskite cell supplemented with 0.030 mmol SnOct2 reached 17.25%, superior to that of device supplemented with 0.10 mmol SnF2 (11.63%). After storage in nitrogen for 50 d, more than 70% of initial PCE was still preserved.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Yu WANG, Hao XIONG, Xiaokun HUANG, Linqin JIANG, Bo WU, Jiansheng LI, Aijun YANG. Regulation of Low-dose Stannous Iso-octanoate for Two-step Prepared Sn-Pb Alloyed Perovskite Solar Cells[J]. Journal of Inorganic Materials, 2024, 39(12): 1339

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Apr. 15, 2024

    Accepted: --

    Published Online: Jan. 21, 2025

    The Author Email: Linqin JIANG (linqinjiang@fjjxu.edu.cn), Bo WU (wubo@fzu.edu.cn)

    DOI:10.15541/jim20240191
