High Power Laser and Particle Beams, Volume. 37, Issue 8, 089003(2025)
Decoupled temperature control of multi-spot laser solid-state phase transformation based on ADRC algorithm
In view of the limitations associated with traditional single-spot laser solid-state phase transformation temperature control methods in complex curved workpieces, this paper proposes a multi-input multi-output (MIMO) temperature decoupling control strategy based on active disturbance rejection control (ADRC). first, a finite element model of multi-spot laser-induced solid-state phase transformation was developed, and a model-order reduction method was applied to extract the key dynamic characteristics of the system, significantly reducing computational complexity and laying a foundation for effective control. Subsequently, to address the high-frequency jitter problem encountered by the conventional fal function within small-error regions, an improved bfal function based on Bernstein polynomials was proposed, thereby enhancing system observation accuracy and disturbance rejection capability. Moreover, an improved particle swarm optimization (PSO) algorithm was used to tune the parameter of ADRC controllers, effectively accelerating the optimization process. Finally, co-simulations conducted on the MATLAB/Simulink and COMSOL platforms demonstrated that the proposed PSO-ADRC controller achieves superior performance in terms of response speed, overshoot reduction, and steady-state accuracy compared to the conventional PID and standard ADRC methods. The method thus provides an efficient and precise solution for multi-spot laser solid-state phase transformation temperature control in complex curved workpieces.
Get Citation
Copy Citation Text
Zhijun Chen, Liangjian Zhang, Qunli Zhang, Xiaofei Ma, Jianhua Yao. Decoupled temperature control of multi-spot laser solid-state phase transformation based on ADRC algorithm[J]. High Power Laser and Particle Beams, 2025, 37(8): 089003
Category: Advanced Interdisciplinary Science
Received: Mar. 12, 2025
Accepted: Jun. 18, 2025
Published Online: Aug. 13, 2025
The Author Email: Jianhua Yao (laser@zjut.edu.cn)
