Chinese Journal of Liquid Crystals and Displays, Volume. 40, Issue 8, 1132(2025)

Liquid crystal micro lens array with modal control for integrated imaging 3D display

Haoran WANG1, Xueying CHANG2, Qilong CHEN2, Zhenyao BIAN1, Hongbo LU1,2, and Miao XU1,2、*
Author Affiliations
  • 1Key Laboratory of Advance Functional Materials and Devices of Anhui Province, School of Chemistry and Chemical Engineering, Hefei University of Technology, Hefei 230009, China
  • 2National Engineering Laboratory of Special Display Technology, State Key Laboratory of Modern Display Technology Jointly Established by the Province and Ministry, Anhui Province Key Laboratory of Measuring Theory and Precision Instrument, School of Instrument Science and Optoelectronics Engineering, Hefei University of Technology, Hefei 230009, China
  • show less

    Liquid crystal lenses have the advantages of compact structure, high integration, and adjustable focal length. This article proposes a method for preparing a liquid crystal micro lens array (LCMLA) with modal control for integrated imaging 3D display. Firstly, the influence of voltage amplitude and frequency on the potential distribution of liquid crystal lenses without and with high resistance layers was analyzed using simulation software COMSOL Multiphysics. Secondly, a transparent high resistance layer of polymer poly (3,4-ethylenedioxythiophene): polystyrene sulfonate (PEDOT∶PSS) and polyvinyl alcohol (PVA) was fabricated on a copper circular hole array electrode. And a comparative experiment was conducted to verify it, the experimental results show that the LCMLA without adding a high resistance layer changes the focal length from ∞ to 25.8 mm and the response speed is 645.7 ms when the voltage changes from 0 to 40 V at a fixed sine wave frequency of 1 kHz. The LCMLA with modal control incorporating a high resistance layer can adjust the lens characteristics by changing either the amplitude or frequency of the driving voltage. When the fixed frequency is 75 kHz, the voltage changes from 0 to 5 V, the focal length changes from ∞ to 19.5 mm, and the response speed is 621.4 ms. When the fixed voltage is 5 V, the frequency changes from 1 kHz to 75 kHz, the focal length changes from ∞ to 19.5 mm, and the response speed is 146.4 ms. Applying the prepared LCMLA with modal control to integrated imaging 3D display can achieve good 3D display effect and fast switching characteristics at low voltage.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Haoran WANG, Xueying CHANG, Qilong CHEN, Zhenyao BIAN, Hongbo LU, Miao XU. Liquid crystal micro lens array with modal control for integrated imaging 3D display[J]. Chinese Journal of Liquid Crystals and Displays, 2025, 40(8): 1132

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: May. 20, 2025

    Accepted: --

    Published Online: Sep. 25, 2025

    The Author Email: Miao XU (xumiao0711@hfut.edu.cn)

    DOI:10.37188/CJLCD.2025-0103
