Chinese Journal of Quantum Electronics, Volume. 42, Issue 3, 381(2025)

Research on highly sensitive ozone detection technology based on high precision cavity

LIU Menghui1,2, TONG Jinzhao1,2, LIN Chuan1,2, HUANG Chenguang3、*, and XIE Pinhua1,2、**
Author Affiliations
  • 1Anhui Institute of Optics and Fine Mechanics, HFIPS, Chinese Academy of Sciences, Hefei 230031, China
  • 2University of Science and Technology of China, Hefei 230026, China
  • 3University of Chinese Academy of Sciences, Beijing 100049, China
  • show less

    In this study, a highly sensitive ozone detection system based on high precision cavity technology was developed. A deep ultraviolet light-emitting diode (DUV-LED) with a center wavelength of 266 nm was used as light source, and an optical cavity with a length of 30 cm was constructed with two high reflectance mirrors with a reflectivity of 99.7%, which achieved an effective absorbing optical path of 84.7 m. Firstly, the stability of the DUV-LED light source and the interference of other gases at the center wavelength were investigated, and the effective cavity length and the cavity extinction value of the system were calibrated. Then, the performance of the system was evaluated using Allan variance, and it showed that the integrated system had a detection limit of 129×10-12 (1σ) for O3 at a time resolution of 1 s, with a total system uncertainty of 6.2%. Finally, to verify the environmental adaptability and stability of the system, the system was employed in a continuous 3 d comprehensive field observation at Hefei Science Island (China), and compared with the commercial instrument Thermo-49i. The observation results show that the O3 concentrations measured by the two systems have good consistency, with a correlation coefficient of 0.98, a slope of 1.01, and an intercept of 0.75. The consistency verifies the accuracy and reliability of the system in measuring O3, proving that the system can be applied to accurate measurement of O3 with high sensitivity and high time resolution in real environments.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Menghui LIU, Jinzhao TONG, Chuan LIN, Chenguang HUANG, Pinhua XIE. Research on highly sensitive ozone detection technology based on high precision cavity[J]. Chinese Journal of Quantum Electronics, 2025, 42(3): 381

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Oct. 8, 2023

    Accepted: --

    Published Online: Jun. 11, 2025

    The Author Email: Chenguang HUANG (huangcg@imech.ac.cn), Pinhua XIE (phxie@aiofm.ac.cn)

    DOI:10.3969/j.issn.1007-5461.2025.03.010
