Journal of Inorganic Materials, Volume. 40, Issue 5, 529(2025)

Nd:YLF Crystal Growth: Raw Materials Preparation by Melting Method and Property

Kaixuan ZHAO1,2, Wenpeng LIU2、*, Shoujun DING3, Renqin DOU2, Jianqiao LUO2, Jinyun GAO2, Guihua SUN2, Hao REN4, and Qingli ZHANG2
Author Affiliations
  • 11. Institutes of Physical Science and Information Technology, Anhui University, Hefei 230601, China
  • 22. Anhui Provincial Key Laboratory of Photonic Devices and Materials, Anhui Institute of Optics and Fine Mechanics, Hefei Institutes of Physical Science, Chinese Academy of Sciences, Hefei 230031, China
  • 33. School of Microelectronics and Data Science, Anhui University of Technology, Maanshan 243032, China
  • 44. National Laboratory of Solid State Microstructure, Department of Materials Science and Engineering, Nanjing University, Nanjing 210093, China
  • show less

    Nd3+-doped LiYF4 (Nd:YLF) crystal is a laser crystal with excellent performance, which is widely used in scientific research, industrial and medical fields. But its existing crystal growth method using binary fluoride mixtures is problematic due to fluoride oxides being formed in fluoride raw materials, and process of preparing raw materials by using HF gas fluorination is relatively complicated. Therefore, preparation of high-purity fluoride raw materials is one of the important factors to realize the growth of high-quality fluoride crystals. Meanwhile, crystal growth atmosphere usually contains CF4 or HF, which is highly corrosive to growth system and increases cost of crystal growth. In this work, to obtain high-quality Nd:YLF crystal, the polycrystalline growth raw material with high-purity YLF crystalline phase was first prepared using a nearly closed melting material device, which was a novel design facilitating the melting process and floating salvage process at the temperature above the crystal melting point. Intact Nd:YLF crystal was obtained after growth under a high-purity Ar atmosphere. X-ray diffraction (XRD) patterns of polycrystalline raw materials and growing crystals were tested, while lattice parameters, atomic coordinates, atomic occupancy and temperature factor were obtained by Rietveld refinement. By measuring X-ray rocking curve (XRC) of (100) crystallographic plane of the as-obtained Nd:YLF crystal, the full width at half maximum (FWHM) of diffraction peak is 0.007°. The segregation coefficient of Nd3+ in YLF calculated by measuring the content of each element is 0.3. The strongest absorption peaks of Nd:YLF crystal locate at 797.4 nm (a direction) and 792.3 nm (c direction) with absorption cross sections of 3.37×10-20 and 5.49×10-20 cm2, respectively. The strongest emission peak of Nd:YLF crystal locates at 1047 nm with stimulated emission cross section of 1.598×10-19 cm2 and fluorescence lifetime of 483 μs. Based on above data, Nd:YLF polycrystalline raw materials prepared by melting method achieve high phase purity. Combined with Czochralski method of crystal growth with vacuum extraction and heating process, the present growth method can greatly reduce the formation of fluoride oxide during the growth process, which proves a successful growth under Ar atmosphere.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Kaixuan ZHAO, Wenpeng LIU, Shoujun DING, Renqin DOU, Jianqiao LUO, Jinyun GAO, Guihua SUN, Hao REN, Qingli ZHANG. Nd:YLF Crystal Growth: Raw Materials Preparation by Melting Method and Property[J]. Journal of Inorganic Materials, 2025, 40(5): 529

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Nov. 1, 2024

    Accepted: --

    Published Online: Sep. 2, 2025

    The Author Email: Wenpeng LIU (wpliu@aiofm.ac.cn)

    DOI:10.15541/jim20240456
