Opto-Electronic Advances, Volume. 8, Issue 3, 240257-1(2025)

Soliton microcombs in optical microresonators with perfect spectral envelopes

Mulong Liu1、†, Ziqi Wei2,3、†, Haotong Zhu1、†, Hongwei Wang4, Xiao Yu5, Xilin Han5, Wei Zhao6、*, Guangwei Hu4、**, and Peng Xie3,5、***
Author Affiliations
  • 1School of Science, Northwest A & F University, Yangling 712100, China
  • 2School of physics, Peking University, Beijing 100871, China
  • 3Center of Materials Science and Optoelectronics Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
  • 4School of Electrical and Electronic Engineering, Nanyang Technological University, Singapore 308232, Singapore
  • 5Qiguang Research and Innovation Center, Aerospace Laser Technology and System Department, Shanghai Institute of Optics and Fine Mechanics, Chinese Academy of Science, Shanghai 201800, China
  • 6State Key Laboratory of Transient Optics and Photonics, Xi’an Institute of Optics and Precision Mechanics (XIOPM), Chinese Academy of Sciences (CAS), Xi’an 710119, China
  • show less

    We theoretically and experimentally investigate thermal dynamics involved soliton microcomb generation in silicon oxynitride microresonators. Importantly, auxiliary laser heat balance scheme with flexible thermal manipulation is introduced to circumvent thermal instability and the intra-cavity temperature can be tuned from 60 °C to 41.5 °C via the commercial thermoelectric controller. As a result, various perfect soliton states with ultra-smooth spectral envelopes are observed on a well-designed and fabricated microresonator with homogeneous sidewall and thickness where spatial modes interaction and distortion are eliminated. The pre-reported spectral abrupt jumps due to mode hybridization are completely avoided and solitons tail oscillation vanishes simultaneously. This reported ideal coherent comb source without residual temporal and spectral noise will facilitate practical applications such as spectroscopy, ranging and astrocomb calibration.

    Introduction

    Since last decade, microresonator-based optical frequency combs (i.e. microcombs) have attracted significant attentions due to their unprecedented advantages of ultrahigh repetition rates, wide bandwidth and high compactness1,2. Microcombs are promising for extensive applications including optical clocks3, coherent communications4, precise spectroscopy57, accurate ranging810, quantum optics11, etc. A myriad of material platforms have been successfully demonstrated for efficient microcomb generation12, including complementary metal-oxide semiconductor (CMOS)-compatible microresonators such as Si3N41315, silicon16, silica17,18 and silicon oxynitride19, as well as other platforms like CaF2 and MgF2 crystallines20,21, AlN22,23, AlGaAs24 and diamond25. CMOS-compatible materials are of particular importance in advancing microcomb technology, owing to their compatibility with semiconductor processing and their ability to integrate with other photonic devices platform. Silicon oxynitride, as a CMOS-compatible materials, has been widely used in the fabricating of high-quality factor optical resonators due to its relatively low nonlinear losses19. However, the influence of silicon oxynitride microresonator on the performance and dynamics of soliton microcombs remains an open question. Soliton microcombs, relying on the double balance between cavity loss and parametric frequency conversion on one hand, as well as anomalous dispersion and Kerr nonlinearity on the other, exhibit outstanding features of low frequency and amplitude noise and high coherence which are essential for practical applications.

    However, during the transition into a steady soliton state, the dramatic intracavity power drop can result in the pump frequency shifting out of cavity resonance through the thermo-optical effect, thus introducing the difficulties to deterministically capture solitons in experiments. The specific technical approaches are required according to distinct thermal and nonlinear properties for different platforms. To date, the rapid forward frequency-tuning26, forward and backward frequency-scanning27, power-kicking28, thermal tuning29, Euler bends30 and auxiliary-laser-based methods31,32 are exploited for single soliton generation based on materials with relative low (e.g. MgF233, silica34 and LiNbO335) and high (e.g. Si3N436 and AlN23) thermal-optical coefficients. With these advanced experimental techniques, soliton microcomb generation now has been extended from the telecom band37 to the visible38 and mid-infrared band39, along with a few proof-of-concept demonstration of applications40,41. However, certain techniques face significant limitations in soliton microcomb generation due to relatively high operational complexity. For instance, rapid forward frequency-tuning demands extremely precise scanning speed42, power-kicking necessitates meticulous regulation of pump power28, and conventional auxiliary-laser-based methods are difficult to flexibly control the temperature of microresonators43. Therefore, it is of great significance to realize the adiabatic process in a simpler and more accessible way.

    Beyond these encouraging progresses, certain challenges to further improve the performance of soliton microcombs still remain, especially for those with high thermal constant considering the continuously emerging new platforms. For instance, researchers quench thermorefractive effects of AlGaAs by cryogenic cooling temperatures to 4–20 K for soliton microcomb generation. Its thermorefractive value in room-temperature is an order of magnitude larger than that of Si3N4 and SiO2, and AlN by more than two orders of magnitude44. In addition, soliton properties in microresonator of previous reports are, generally, not "perfect" regarding temporal and spectral profile. For example, under the interaction of high-order nonlinearity and mode crossing, a spike will appear in the spectra envelope showing the soliton tail oscillation in the time domain, which will induce additional noise. To solve the chronic drift of solitons in the cavity, the phase modulation of the pump in the frequency domain45 and Raman effect via balancing with the high-order dispersion are sought46. These elaborate approaches to control the soliton generation dynamics leads to recent development of perfect soliton crystals (PSCs), which are composed by a number of dissipative Kerr solitons equally distributed around the resonator47,48 via regulating the comb line spacing. The PSC with intrinsic low redundant noise of individual solitons in temporal domain and no abrupt drop or jump on spectra could promise the applications in astronomical spectrometers49 and optical fiber communications4, which remains under explored.

    Here, we explore the thermal influence on soliton microcomb generation in silicon oxynitride materials platform. We found that the strong thermal effect prohibits the soliton microcomb generation under single pump frequency scanning scheme. Therefore, we employ a novel auxiliary-laser-assisted tuning method combined with precise and flexible thermal regulation via a thermoelectric controller (TEC), applied to a sophisticated design and processing silicon oxynitride microresonator with smooth sidewall and uniform thickness, thereby generate stable Kerr solitons. Eliminating the influences of other modes or mode distortion and sustaining the pure fundamental mode field, various perfect soliton states with favored smooth spectral envelope are accessible promptly by adjusting auxiliary light. Our perfect soliton state features the completely vanishing spectral discontinuities caused by avoided-mode-crossing (AMX) effects13,50,51, and shows no oscillating background waves, residual noise or radiation loss induced by high-order-dispersion (HOD) and/or AMX, which are crucial for highly accurate fast distance acquisitions. The corresponding ideal coherent microcombs avoid intensity jumps and radiation loss important for practical applications including spectroscopy, quantum optics, astronomy and others.

    Theory and simulation

    The Lugiato-Lefever equation (LLE) including second-order dispersion, Raman and thermal effects is used to describe the spectral-temporal dynamics of frequency comb generation27,52 in our material platform. Thermal effects are included by calculating and considering the intra-cavity power induced additional detuning and the generalized LLE can be written as,

    TREt=(α+κ2+iLβ222τ2+i(δ0+δT))E+κEin+iγL(|E|2+τR|E|2τ)E,

    dδTdt=δTτ0+ζP,

    where E(t, τ) is the envelope of field within the resonator, t and τ correspond to the slow time and the fast time, respectively, TR is the round-trip time, Ein is the pump field, δ0 is the laser detuning and δT is the thermal detuning.Equation (2) describes the thermal dynamics, where P is the average intracavity power and ζ describing the shift of the detuning in response to the average intracavity power depends on the thermal-optical coefficient of the material and the absorbed power converted to heat, τ0 is the thermal response time measured to be submicrosecond in previously fabricated microresonators. Since τ0 also depends on the design of the cavity, and it is set as 100 ns to reduce simulation time. Some parameters of the silicon oxynitride microresonator used for calculations to investigate the different soliton generation dynamics are as follows: the round-trip loss α is given as 0.006; the power transmission coefficient κ is 0.00147; the total cavity length L is set to 3.72 mm; the second order dispersion β2 is −37 ps2 km−1; the Raman shock time τR = 2.7 fs; the nonlinear coefficient γ = n2ω/cAeff is 0.11 (Wm)−1 with the nonlinear refractive index n2 and the effective mode area Aeff53.

    In the first stage, relatively stronger thermal effects with ζ = −1 × 104 (Ws)−1 is used for simulation. The laser detuning is linearly tuned from −0.004 to 0.056 in 0–1600 ns and held at 0.056 in 1600–3500 ns. It is found that stochastic solitons annihilate or survive in all 30 scans as seen from Fig. 1(a). The different colored curves represent the evolution of intracavity energy under the different pump powers. On the one hand, the Kerr comb starts to form into soliton states around the end of the laser tuning. With the power drop in the soliton transition, thermal detuning increases (becomes less negative) and total detuning decreases, exceeding the soliton existence region. Consequently, solitons annihilate due to thermal-induced resonance blueshift. On the other hand, the presence of thermal chaos also allows distinct routes to soliton formation. For instance, in some scans the comb remains in the chaotic state with a blue-detuned pump over the full time scanning. Therefore, a weak thermal effect with ζ = –5× 103 (Ws)−1 is chosen for the next stage to trigger soliton state. The laser detuning is linearly tuned from –0.004 to 0.043 and hold at 0.043 in remain time to induce soliton generation. Different soliton states can be obtained as shown in Fig. 1(b). Intra-cavity soliton number, closely associated with the power in the cavity, will not affect total detuning significantly for weak thermal effects here thus leading to solitons survive in all 20 scans. These results show that, the generated solitons can either survive or annihilate due to thermal dynamics when the pump laser is scanned from blue to red detuning region and then stop at a fixed wavelength. In previous frequency-scanning experiments27, the soliton steps are tens of nanoseconds making it difficult for soliton generation and stabilization, which is expected to be the strong thermal influences and needed to be overcome. In order to balance the blue detuning caused by thermal effects in microcavity, here auxiliary laser assisted tuning method is applied to different soliton states capturing. The bi-chromatic pump method is widely used for dual-comb spectroscopy54 and quantum informatics40. The basic principle of solitons generation in the microresonator is demonstrated by comparing Fig. 1(c) and Fig. 1(d). As manifested in Fig. 1(c) and Fig. 1(d), soliton pulses cannot be excited in the microresonator when there is only one CW pump, but they can be excited when a TE pump and a TM pump are existed simultaneously.

    The influences of thermal effects on soliton formation and auxiliary laser assisted tuning method. (a) For strong thermal effects of ζ = −1 × 104 (Ws)−1, intracavity energy evolution reflects soliton annihilation or in chaotic regime. Different color represents distinct microcomb routes and determined by intracavity energy instability. (b) For weak thermal effect of ζ = −5 × 103 (Ws)−1 solitons can always survive in all 20 scans. Calculated temporal profile (c-i) and spectral profile (c-ii) of chaotic state with only one pump. (c-iii) Schematic diagram of chaotic state with only one pump. Calculated temporal profile (d-i) and spectral profile (d-ii) of two solitons state with heat balance scheme. (d-iii) Schematic diagram of two solitons state with heat balance scheme.

    Figure 1.The influences of thermal effects on soliton formation and auxiliary laser assisted tuning method. (a) For strong thermal effects of ζ = −1 × 104 (Ws)−1, intracavity energy evolution reflects soliton annihilation or in chaotic regime. Different color represents distinct microcomb routes and determined by intracavity energy instability. (b) For weak thermal effect of ζ = −5 × 103 (Ws)−1 solitons can always survive in all 20 scans. Calculated temporal profile (c-i) and spectral profile (c-ii) of chaotic state with only one pump. (c-iii) Schematic diagram of chaotic state with only one pump. Calculated temporal profile (d-i) and spectral profile (d-ii) of two solitons state with heat balance scheme. (d-iii) Schematic diagram of two solitons state with heat balance scheme.

    Experimental setup and principle

    The experimental setup is built as shown in Fig. 2(c) to verify whether auxiliary laser assisted tuning method can play an effective role in soliton capture experiments. The key element is a microresonator with a 49 GHz free spectral range made of silicon oxynitride glass. Such material system is well established and used in on-chip nonlinear optics55,56 and repetition-rate-multiplicable pulsed laser sources57. In addition, this platform is different from LiNbO3 which relies on the unique photorefractive merit58,59. Figure 2(a) and 2(b) shows physical drawing and scanning electron microscope image of the microresonator. Pump light (TE polarization) centered at 1562.2 nm and auxiliary light (TM polarization) are simultaneously injected into the bus waveguide from two different directions after through the fiber polarization controller and erbium-doped fiber amplifier. The circulator is used to isolate the reversely transmitted light. The thermoelectric controller (TEC) enables precise temperature regulation, allowing for adjusting the resonant peak of microresonators. The microresonator pigtailed with a standard fiber array with coupling loss of about 2.5 dB per facet is then packaged into a standard 14 pins butterfly package with a commercial TEC.

    Experimental setup and single perfect soliton. (a) Physical drawing of a microresonator. (b) Scanning electron microscope image of the microresonator. (c) Experimental setup for perfect soliton generation. ECDL, external cavity diode laser; EDFA, erbium-doped fiber amplifier; FPC, fiber polarization controller; Cir, circulator; TEC, thermoelectric controller; OSA, optical spectrum analyzer. The zoom in of the chip shows a scanning-electron micrograph of the waveguide cross-section. (d) Low-noise single soliton state (blue curve) with a sech2 fitting spectral profile (red dashed curve). (e) Microwave beat note of the photo-detected soliton.

    Figure 2.Experimental setup and single perfect soliton. (a) Physical drawing of a microresonator. (b) Scanning electron microscope image of the microresonator. (c) Experimental setup for perfect soliton generation. ECDL, external cavity diode laser; EDFA, erbium-doped fiber amplifier; FPC, fiber polarization controller; Cir, circulator; TEC, thermoelectric controller; OSA, optical spectrum analyzer. The zoom in of the chip shows a scanning-electron micrograph of the waveguide cross-section. (d) Low-noise single soliton state (blue curve) with a sech2 fitting spectral profile (red dashed curve). (e) Microwave beat note of the photo-detected soliton.

    In this system, the auxiliary laser operating in the blue detuning regime at one cavity mode is to balance the intracavity heat flow and actively stabilize different soliton states. In detail, the c.w. pump laser counter-propagates in the microcavity and works at a different cavity mode, thus heats the cavity and red-shifts all cavity resonances. While the red-shifted resonances displace the auxiliary laser from its own cavity mode, in turn cooling the cavity. By properly setting the pump power and temperature of TEC (equally to varying the detuning of pump and auxiliary lasers), the heat flow induced by dual pump tends to balance out each other. Therefore, the pump laser can scan across the entire cavity resonance linewidth without thermal dragging. Furthermore, adjusting injection power of auxiliary laser or precise temperature control through TEC can be used to suppress the minimal power fluctuations and maintain power stability during stable solitons. Stable soliton states can be generated with high repeatability by implementing the auxiliary laser heating scheme.

    Accessing different soliton states in experiment

    In experiments, the microresonator with a loaded Q-factor of 1.7 × 106 and dispersion of −37 ps2 km−1 is used for soliton generation. The platform is well established and used in large-scale integrated photonic circuits as well as on-chip soliton crystal generation60 for its advantage of having a CMOS compatible process and high nonlinear performance. The delicately fabrication process of the microresonator ensure homogeneous waveguide sidewall is similar as that used in Wang's research57. Generally, residual fabrication-induced roughness of cross-section increases optical loss and degrades the resonator Q-factor, which is the primary reason contributing to significant fluctuations and imperfections in the spectral envelope of solitons. The pump and auxiliary laser wavelength are set as 1562.2 nm and 1545.4 nm with on-chip power of 32 dBm and 31.7 dBm, respectively. In this dual-pump scheme, the wavelength and power of the auxiliary laser can be adjusted to match different cavity resonances since the auxiliary laser only acts as a heat balancer. The resonances of the cavity shift toward shorter wavelengths with a decreasing operation temperature by tuning the TEC from 41.5 to 60 degrees Celsius. The microcavity first operates with a relatively high temperature and place the pump wavelength at the blue side of one resonance. Then the resonance is shifted toward the pump laser by reducing the temperature. In fact, pump laser is always coupled into the cavity through the fiber. Once the pump frequency is coupled into the cavity, the cavity will be heated due to the intra-cavity optical field enhancement. After tuning through the modulation instability combs and then the soliton crystal combs, one can increase the pump power to enhance intracavity energy, so the energy loss and cavity temperature can be balanced. With appropriate pump power, a step feature with a sharp power drop indicating soliton generation (Fig. 1(b)). Figure 2(d) shows the generated single soliton optical spectrum with electrical spectrum in Fig. 2(e). The second peak on the left side of the pump in Fig. 2(d) is the assistant pump light, which is important for balancing the energy and heat flow in the cavity. The dashed red curve is the fitted sech2 profile which characterizes pure single soliton spectral profile and agrees perfectly with the experimental observations. Figure 2(e) reflects the equidistant distribution of single soliton spectral lines and each resonance peak has only one spectral line. which indicates that single soliton is generated in a low-noise state.

    Figure 3(a–c) show experimental results of generated soliton states, wherein one, two and four solitons can be observed. The auxiliary laser component is filtered out here. It should be noted that the solitons formed here are perfect, meaning that they have exceptionally smooth spectra, without any spikes related to avoided-mode crossing as reported previously. This phenomenon is attributed to homogeneous sidewall of the microcavity avoiding different mode family interaction and unrelated to the incident light itself. In time domain, the beat between the pump and the spike region will lead to soliton tail oscillation and such jitter is unfriendly to precision measurement. Fortunately, the standard sech2 shape spectrum of single soliton shown in Fig. 3(a) is in excellent agreement with the simulation result as shown in Fig. 3(d). Such a smooth spectral envelope with low redundant noise and unprecedentedly small line-to-line power variations are essential to applications in ranging, spectroscopy and astronomy. In our device, the obvious Raman-induced self-frequency shift (RSFS) manifesting itself as the spectral center redshift from the pump wavelength is also demonstrated53,61. The shift induced by stimulated Raman scattering is 4.4 nm and the Raman shock time is inferred to 2.7 fs by comparing the spectrum of single soliton both in experiment and simulation.

    (a–c) Experimentally measured spectra for 1-, 2- and 4-solion states, respectively. (d–f) Calculated different soliton states. Insets shows the corresponding temporal profile where oscillation is avoided.

    Figure 3.(ac) Experimentally measured spectra for 1-, 2- and 4-solion states, respectively. (df) Calculated different soliton states. Insets shows the corresponding temporal profile where oscillation is avoided.

    Interestingly, it is further demonstrated that this scheme can suppress the thermal effect well and sequentially access stable different two soliton states flexibly through control the wavelength and power of auxiliary light as shown in Fig. 4. The generated spectra exhibit pronounced variations in the spectral envelope which arise from the interference of the Fourier components of the individual soliton. Figure 4(a–d) show four dual-soliton states obtained in experiments by first quickly adjusting the TEC from 5 kΩ to 2.5 kΩ to across the high noise state microcomb then carefully controlling tuning speed to acquire a low resistance around 2.2 kΩ for soliton transition. Consequently, intracavity power reducing will result in different soliton distribution around resonator periphery. Final distance between two solitons depends on intracavity energy and heat balance. In our case, the resistance is tuned from 5 kΩ to 2.2 kΩ with the temperature adjustment from 60 to 44 degrees Celsius. The resistance used here should be larger than that of the single soliton regime because the energy of dual-soliton is about twice that of single soliton. The corresponding simulated spectra are shown in Fig. 5(a–d) and the insets depict the temporal profile. Simulation results match well with experimental structured spectra. Such perfect soliton states originate from the smooth waveguide sidewall itself and are different from the temperature controlling induced AMX free microcombs, which relies on shifting the dispersive wave significantly to shorter wavelength with increasing temperature.

    (a–d) Experimentally measured spectra of different two solions states.

    Figure 4.(ad) Experimentally measured spectra of different two solions states.

    (a–d) Calculated spectra of different two-solion states. Insets show corresponding temporal profile.

    Figure 5.(ad) Calculated spectra of different two-solion states. Insets show corresponding temporal profile.

    Conclusions

    In summary, this work theoretically investigates thermal effect in silicon oxynitride microresonators based on the LLE model that incorporates thermal parameters. Simulations show that the generated solitons can either survive or annihilate due to thermal dynamics when the continuous pump laser is scanned from the blue to red detuning region. Therefore, the counter-propagating pump-auxiliary scheme possessing flexible thermal regulation is adopted to generate single soliton with favored smooth and standard sech2 spectral profile. Furthermore, different multi-soliton states can be obtained easily by adjusting the TEC and auxiliary laser to balance the intracavity thermal instability. Thanks to our elaborate design and processing technology introducing uniform waveguide thickness and sidewall, the observed smooth spectra profile of solitons without any spike related to mode interaction as reported before paves the way for further frequency domain applications in spectroscopy, astronomy and telecommunications. The concomitant tail-oscillation-free temporal pulse in absence of absorption background can also accelerate soliton-based precision measurement like ranging and imaging. In future work, we will also investigate the generation of soliton microcombs with perfect spectral envelopes using auxiliary laser heat balance scheme in other material platforms.

    [1] Y Sun, JY Wu, MX Tan et al. Applications of optical microcombs. Adv Opt Photonics, 15, 86-175(2023).

    [2] SA Diddams, K Vahala, T Udem. Optical frequency combs: coherently uniting the electromagnetic spectrum. Science, 369, eaay3676(2020).

    [3] TE Drake, TC Briles, JR Stone et al. Terahertz-rate Kerr-microresonator optical clockwork. Phys Rev X, 9, 031023(2019).

    [4] Y Geng, H Zhou, XJ Han et al. Coherent optical communications using coherence-cloned Kerr soliton microcombs. Nat Commun, 13, 1070(2022).

    [5] L Stern, JR Stone, SB Kang et al. Direct Kerr frequency comb atomic spectroscopy and stabilization. Sci Adv, 6, eaax6230(2020).

    [6] CY Bao, ZQ Yuan, L Wu et al. Architecture for microcomb-based GHz-mid-infrared dual-comb spectroscopy. Nat Commun, 12, 6573(2021).

    [7] LY Dang, LG Huang, LL Shi et al. Ultra-high spectral purity laser derived from weak external distributed perturbation. Opto-Electron Adv, 6, 210149(2023).

    [8] P Trocha, M Karpov, D Ganin et al. Ultrafast optical ranging using microresonator soliton frequency combs. Science, 359, 887-891(2018).

    [9] JD Wang, ZZ Lu, WQ Wang et al. Long-distance ranging with high precision using a soliton microcomb. Photonics Res, 8, 1964-1972(2020).

    [10] SL Camenzind, JF Fricke, J Kellner et al. Dynamic and precise long-distance ranging using a free-running dual-comb laser. Opt Express, 30, 37245-37260(2022).

    [11] MA Guidry, DM Lukin, KY Yang et al. Quantum optics of soliton microcombs. Nat Photonics, 16, 52-58(2022).

    [12] LW Chen, Y Zhou, Y Li et al. Microsphere enhanced optical imaging and patterning: from physics to applications. Appl Phys Rev, 6, 021304(2019).

    [13] CY Bao, Y Xuan, DE Leaird et al. Spatial mode-interaction induced single soliton generation in microresonators. Optica, 4, 1011-1015(2017).

    [14] YR Zhai, JC Liu, LH Jia et al. Dissipative Kerr soliton formation in dual-mode interaction Si3N4 microresonators. APL Photonics, 9, 101304(2024).

    [15] KW Liu, SY Yao, CX Yang. Raman pure quartic solitons in Kerr microresonators. Opt Lett, 46, 993-996(2021).

    [16] C Xiang, JQ Liu, J Guo et al. Laser soliton microcombs heterogeneously integrated on silicon. Science, 373, 99-103(2021).

    [17] JY Ma, LF Xiao, JX Gu et al. Visible Kerr comb generation in a high-Q silica microdisk resonator with a large wedge angle. Photonics Res, 7, 573-578(2019).

    [18] FJ Shu, PJ Zhang, YJ Qian et al. A mechanically tuned Kerr comb in a dispersion-engineered silica microbubble resonator. Sci China Phys Mech Astron, 63, 254211(2020).

    [19] DY Chen, A Kovach, XQ Shen et al. On-chip ultra-high-Q silicon oxynitride optical resonators. ACS Photonics, 4, 2376-2381(2017).

    [20] MF Qu, CH Li, KQ Liu et al. Dynamic process of soliton generation in CaF2 crystalline whispering gallery mode resonators with negative TO effects. Opt Express, 32, 42846-42855(2024).

    [21] H Wang, B Duan, K Wang et al. Direct tuning of soliton detuning in an ultrahigh-Q MgF2 crystalline resonator. Nanophotonics, 12, 3757-3765(2023).

    [22] XW Liu, CZ Sun, B Xiong et al. Integrated high-Q crystalline ALN microresonators for broadband Kerr and Raman frequency combs. ACS Photonics, 5, 1943-1950(2018).

    [23] SY Yao, KW Liu, CX Yang. Pure quartic solitons in dispersion-engineered aluminum nitride micro-cavities. Opt Express, 29, 8312-8322(2021).

    [24] L Chang, WQ Xie, HW Shu et al. Ultra-efficient frequency comb generation in AlGaAs-on-insulator microresonators. Nat Commun, 11, 1331(2020).

    [25] O Melchert, S Kinnewig, F Dencker et al. Soliton compression and supercontinuum spectra in nonlinear diamond photonics. Diam Relat Mater, 136, 109939(2023).

    [26] RL Miao, CX Zhang, X Zheng et al. Repetition rate locked single-soliton microcomb generation via rapid frequency sweep and sideband thermal compensation. Photonics Res, 10, 1859-1867(2022).

    [27] HR Guo, M Karpov, E Lucas et al. Universal dynamics and deterministic switching of dissipative Kerr solitons in optical microresonators. Nat Phys, 13, 94-102(2017).

    [28] V Brasch, M Geiselmann, MHP Pfeiffer et al. Bringing short-lived dissipative Kerr soliton states in microresonators into a steady state. Opt Express, 24, 29312-29320(2016).

    [29] J Li, S Wan, JL Peng et al. Thermal tuning of mode crossing and the perfect soliton crystal in a Si3N4 microresonator. Opt Express, 30, 13690-13698(2022).

    [30] XR Ji, JQ Liu, JJ He et al. Compact, spatial-mode-interaction-free, ultralow-loss, nonlinear photonic integrated circuits. Commun Phys, 5, 84(2022).

    [31] H Zhou, Y Geng, WW Cui et al. Soliton bursts and deterministic dissipative Kerr soliton generation in auxiliary-assisted microcavities. Light Sci Appl, 8, 50(2019).

    [32] XY Wang, XK Qiu, ML Liu et al. Flat soliton microcomb source. Opto-Electron Sci, 2, 230024(2023).

    [33] T Herr, V Brasch, JD Jost et al. Temporal solitons in optical microresonators. Nat Photonics, 8, 145-152(2014).

    [34] SS Jiang, CL Guo, HY Fu et al. Mid-infrared Raman lasers and Kerr-frequency combs from an all-silica narrow-linewidth microresonator/fiber laser system. Opt Express, 28, 38304-38316(2020).

    [35] MJ Yu, Y Okawachi, R Cheng et al. Raman lasing and soliton mode-locking in lithium niobate microresonators. Light Sci Appl, 9, 9(2020).

    [36] V Brasch, M Geiselmann, T Herr et al. Photonic chip–based optical frequency comb using soliton Cherenkov radiation. Science, 351, 357-360(2016).

    [37] Z Gong, XW Liu, YT Xu et al. Near-octave lithium niobate soliton microcomb. Optica, 7, 1275-1278(2020).

    [38] CL Wang, J Li, AL Yi et al. Soliton formation and spectral translation into visible on CMOS-compatible 4H-silicon-carbide-on-insulator platform. Light Sci Appl, 11, 341(2022).

    [39] W Wu, QB Sun, Y Wang et al. Mid-infrared broadband optical frequency comb generated in MgF2 resonators. Photonics Res, 10, 1931-1936(2022).

    [40] FX Wang, WQ Wang, R Niu et al. Quantum key distribution with on-chip dissipative Kerr soliton. Laser Photon Rev, 14, 1900190(2020).

    [41] J Riemensberger, A Lukashchuk, M Karpov et al. Massively parallel coherent laser ranging using a soliton microcomb. Nature, 581, 164-170(2020).

    [42] JR Stone, TC Briles, TE Drake et al. Thermal and nonlinear dissipative-soliton dynamics in Kerr-microresonator frequency combs. Phys Rev Lett, 121, 063902(2018).

    [43] HM Zheng, W Sun, XX Ding et al. Programmable access to microresonator solitons with modulational sideband heating. APL Photonics, 8, 126110(2023).

    [44] G Moille, L Chang, WQ Xie et al. Dissipative Kerr solitons in a III-V microresonator. Laser Photon Rev, 14, 2000022(2020).

    [45] BL Zhao, LR Wang, QB Sun et al. Repetition-rate multiplicable soliton microcomb generation and stabilization via phase-modulated pumping scheme. Appl Phys Express, 13, 032009(2020).

    [46] WC Fan, ZZ Lu, W Li et al. Low-threshold 4/5 octave-spanning mid-infrared frequency comb in a LiNbO3 microresonator. IEEE Photonics J, 11, 6603407(2019).

    [47] M Karpov, MHP Pfeiffer, HR Guo et al. Dynamics of soliton crystals in optical microresonators. Nat Phys, 15, 1071-1077(2019).

    [48] Y He, JW Ling, MX Li et al. Perfect soliton crystals on demand. Laser Photon Rev, 14, 1900339(2020).

    [49] MG Suh, X Yi, YH Lai et al. Searching for exoplanets using a microresonator astrocomb. Nat Photonics, 13, 25-30(2019).

    [50] C Kim, CC Ye, Y Zheng et al. Design and fabrication of AlGaAs-on-insulator microring resonators for nonlinear photonics. IEEE J Sel Top Quantum Electron, 29, 5900214(2023).

    [51] H Liu, WT Wang, JH Yang et al. Observation of deterministic double dissipative-Kerr-soliton generation with avoided mode crossing. Phys Rev Res, 5, 013172(2023).

    [52] CY Bao, Y Xuan, JA Jaramillo-Villegas et al. Direct soliton generation in microresonators. Opt Lett, 42, 2519-2522(2017).

    [53] ZZ Lu, WQ Wang, WF Zhang et al. Raman self-frequency-shift of soliton crystal in a high index doped silica micro-ring resonator [Invited]. Opt Mater Express, 8, 2662-2669(2018).

    [54] I Coddington, N Newbury, W Swann. Dual-comb spectroscopy. Optica, 3, 414-426(2016).

    [55] G Piccoli, M Sanna, M Borghi et al. Silicon oxynitride platform for linear and nonlinear photonics at NIR wavelengths. Opt Mater Express, 12, 3551-3562(2022).

    [56] ZZ Lu, WQ Wang, WF Zhang et al. Deterministic generation and switching of dissipative Kerr soliton in a thermally controlled micro-resonator. AIP Adv, 9, 025314(2019).

    [57] WQ Wang, WF Zhang, ST Chu et al. Repetition rate multiplication pulsed laser source based on a microring resonator. ACS Photonics, 4, 1677-1683(2017).

    [58] LK Chen, YF Xiao. On-chip lithium niobate microresonators for photonics applications. Sci China Phys Mech Astron, 63, 224231(2020).

    [59] M Zhang, B Buscaino, C Wang et al. Broadband electro-optic frequency comb generation in a lithium niobate microring resonator. Nature, 568, 373-377(2019).

    [60] WQ Wang, ZZ Lu, WF Zhang et al. Robust soliton crystals in a thermally controlled microresonator. Opt Lett, 43, 2002-2005(2018).

    [61] ZD Li, YQ Xu, S Shamailov et al. Ultrashort dissipative Raman solitons in Kerr resonators driven with phase-coherent optical pulses. Nat Photonics, 18, 46-53(2024).
