To meet the exponentially growing demand for data traffic capacity in data centers, photodetectors must quickly respond to 100 Gbps signals with high sensitivity. Nowadays, a port transmission rate of 400 Gb/s is being scaled up in data centers. Transceiver modules with 800 Gb/s port rate are now undergoing small-scale trials, and those with 1.6 Tb/s port rate have entered the prototype stage. Corresponding port rate standards include 8×200 Gb/s, 8×100 Gb/s, etc., with different modulation schemes. This necessitates the development of high-speed photodetectors capable of supporting these standards, with their photo-response bandwidth exceeding 57 GHz and responsivity over 0.5 A/W, for applications in single-wavelength 100 Gb/s optical channels^[1]. To accomplish the required PD performance, many attempts have been conducted, such as mushroom-type photodetectors^[2], dual-absorption-layer photodetectors^[3], PIN photodetectors^[4], PDA-PDs^[5], and uni-traveling-carrier photodiode (UTC-PD)^[6], etc. The UTC-PD, first proposed in 1997, effectively mitigates the space-charge effect in PIN PD by using electrons as a single transit carrier to promote its high-speed performance^[6]. MUTC-PD optimizes the UTC-PD’s absorber layer by dividing it into a p-doped region and a depleted region to obtain high speed and high responsivity performance simultaneously^[7-8]. However, MUTC-PD typically features thin absorber layers for enhanced high-speed performance, resulting in lower responsivity. Increasing the thickness of the absorber layer allows a greater responsivity, but it increases the carrier’s transit time and decreases the PD’s bandwidth. One possible method to reduce the PD’s response bandwidth degradation caused by the thick absorption layer is to increase the mean electron transit velocity^[9-11].

In this paper, a novel MUTC-PD structure with an electric field regulation layer inserted between its cliff and collector layers is proposed for performance optimization. By optimizing the doping concentration of the electric field regulation layer and the thickness of the collector layer, the electric field intensity inside the MUTC-PD’s collector layer can be tuned to a certain level to make the photo-generated electrons transit at their peak drift velocities constantly. At the same time, the electric field intensity in the PD’s absorber could be optimized to ensure that the photo-generated hole would transit at its saturated drift velocity in its depleted region, and the photo-generated electron’s diffusion enhancement factor could be maximized in its p-doped region. Moreover, as in the proposed novel MUTC-PD, the electrons transit at their peak drift velocity in the PD’s collector layer, enabling further optimization of the PD’s parasitic capacitance. This and the overall impact on the PD’s high-speed photo-response were analyzed. In the analysis, for better coupling of the incident light, the diameter of the PD was set to 16 μm. The following sections of this paper will refer to the proposed MUTC-PD as the swift-responding modified uni-traveling-carrier photodiode (SMUTC-PD) to distinguish it from the MUTC-PD.

Fig. 1 (color online) outlines the epitaxial structure of the SMUTC-PD. A 500 nm thick InP buffer layer, with an n-doping level of 5×10¹⁸ cm⁻³, was deposited above the SI-InP substrate. On top of this, an un-intentionally doped InP collector layer with a thickness of x nm was added to enable further optimization. A 20 nm thick InP electric field regulation layer with a p-doping level of 1×10¹⁶ cm⁻³ was placed above the collector layer. This regulation layer was designed to regulate the electric field intensity distribution in the collector layer. Next, an 80 nm thick InP cliff layer with a n-doping level of 7.2×10¹⁶ cm⁻³, a 40 nm thick InGaAsP layer (Q1.24) with a p-doping level of 5×10¹⁵ cm⁻³, and a 40 nm thick InGaAsP layer (Q1.46) with a p-doping level of 5×10¹⁵ cm⁻³ were added one by one consecutively. Q1.24 and Q1.46 represent the cut-off wavelengths of the corresponding InGaAsP materials. Then, a 100 nm thick, un-intentionally P-doped InGaAs layer and a 350 nm thick p-doped InGaAs layer with a doping level of 3.5×10¹⁶ cm⁻³ were grown as absorption regions of the PD. Above it, a 50 nm thick InGaAsP electron block layer with a p-doping level of 1×10¹⁹ cm⁻³ was grown. The topmost cap layer was a 50 nm thick p-doped InGaAs layer with a doping level of 1×10¹⁹ cm⁻³.

SMUTC-PD’s performance simulations were conducted with Silvaco Atlas. An extra 15 Ω series resistance was added to the ideal 50 Ω load resistance to analyze its parasitic performance. Also, an additional parallel parasitic capacitance of 5 fF was added to simulate the capacitance introduced by the metal contact pad. The negative differential mobility model was used to analyze the electron’s peak drift velocity performance in InP. The bias voltage in the simulation was set to 3 V. The material parameters of InP, InGaAsP, and InGaAs were obtained from Ref. [12-15]. Table 1 gives the optical and electrical parameters of the materials used in the simulation (InP and InGaAs).

As stated above, the SMUTC-PD introduces an electric field regulation layer (EFRL) to optimize the transit performance of the photo-generated electrons and holes. The transit bandwidth of SMUTC-PD was determined by the electron’s transit time in the collector layer, the p-doped absorption layer, and the hole’s transit time in the depleted absorption layer. The doping level of the EFRL was used to optimize the above parameters by adjusting the electric field intensity distribution in the three layers mentioned above. The simulation results are shown in Fig. 2 (color online). Electron and hole transit velocity distributions in the SMUTC-PD with different doping-level in EFRL are shown in Fig. 3-Fig. 4 (color online). In the above analysis, the thickness of the collector layer was set to 900 nm. Fig. 2 shows that the introduction of the EFRL made the electric field intensity distribution in the collector layer consistent. Thus, the electrons can transit with uniform velocity throughout the collector layer. Moreover, the optimization of the electric field intensity distribution in the collector layer and the depleted absorption region was achieved by adjusting the doping of the EFRL, which was set to D₀. Reducing the value of D₀ lowered the electric intensity in the collector layer (as shown in Fig. 2). The adjustment allowed the intensity to approach a level that enabled the electrons to transit through it at peak electron drift velocity, as shown in Fig. 3. At the same time, the electric intensity in the depleted absorption layer increased (as shown in Fig. 2), which enabled the holes’ transit velocity to approach maximum level (the saturated hole drift velocity), as shown in Fig. 4.

As shown in Fig. 2, the electric field intensity in the collector layer rises from 13 kV/cm to 30 kV/cm when D₀ goes from 3×10¹⁶ cm⁻³ to 5×10¹⁷ cm⁻³. Specifically, the electric field intensity in the collector layer is approximated at 11 kV/cm when D₀ is 1×10¹⁵ cm⁻³ and 1×10¹⁶ cm⁻³. In this range, the electrons can transit in InP at its peak drift velocity of 4×10⁷ cm/s. This was verified by the simulation analysis of the electron’s transit velocity distribution in the SMUTC-PD, shown in Fig. 3. Furthermore, when D₀ goes from 3×10¹⁶ cm⁻³ to 5×10¹⁷ cm⁻³, the mean velocity of electrons in the collector layer decreases from 3.8×10⁷ cm/s to 2.8×10⁷ cm/s.

As Fig. 2 shows, when D₀ is 1×10¹⁵ cm⁻³ and 1×10¹⁶ cm⁻³, in the depleted absorption region, the electric field intensity is approximated to be 86 kV/cm, and the velocity of holes is 4.3×10⁶ cm/s as Fig. 4 shows, approaching its saturated drift velocity. From Fig. 2 and 4, one can see that the electric field intensity decreases from 85 kV/cm to 47 kV/cm when D₀ goes from 3×10¹⁶ cm⁻³ to 5×10¹⁷ cm⁻³, and the maximum velocity of holes decreases from 4.2×10⁶ cm/s to 3.7×10⁶ cm/s. Simultaneously, the electrons consistently transit at their saturation drift velocity of 2.5×10⁷ cm/s.

In the p-doped absorption region, the hole relaxes. When D₀ is 1×10¹⁵ cm⁻³ and 1×10¹⁶ cm⁻³, the minimum velocity of electrons is 1.0×10⁷ cm/s and 9.3×10⁶ cm/s, according to Fig. 3. When D₀ goes from 3×10¹⁶ cm⁻³ to 5×10¹⁷ cm⁻³, the minimum velocity of electrons decreases from 7.9×10⁶ cm/s to 2.2×10⁶ cm/s.

In summary, in the above three layers, when D₀ is 1×10¹⁵ cm⁻³ and 1×10¹⁶ cm⁻³, the transit performance of electrons and holes can be optimized. Ultimately, the doping concentration of 1×10¹⁶ cm⁻³ was chosen for the EFRL layer, as in the above three layers. The collector layer is longer and has a greater impact on the PD’s high-speed characteristics.

When optimizing the SMUTC-PD’s dynamic photo-response performance, its collector layer’s thickness is a major influencing factor. It determines most of the photo-generated electrons’ transit time and the PD’s junction capacitance. Therefore, the thickness of the PD’s collector layer and its internal electric field intensity distribution need to be carefully designed. To improve the PD’s dynamic performance, its collector’s thickness can be increased to reduce its parasitic capacitance. At the same time, by optimizing the electric field intensity distribution in the PD’s collector, as stated in section 2, the photo-generated electrons can transit through the PD’s collector at peak drift velocity. Then, the electron’s transit time increase in the collector can be compensated for.

In the SMUTC-PD optimization, the PD collector’s thickness x changed from 0.1 μm to 1.3 μm. And the PD’s photo-response bandwidth was calculated correspondingly. Fig. 5−7 (color online) denotes the simulated PD’s carrier transit time determined photo-response bandwidth as “Tt” and a solid blue line with square marks. At the same time, Fig. 5−7 denotes the parasitic capacitance simulated from SMUTC-PD structure as “capacitance” and a solid red line with triangle marks. Fig. 5−7 denotes the total PD’s photo-response bandwidth that resulted from the carriers’ transit time and the PD’s parasitic effect in the simulation as “3 dB” and a solid green line with circle marks. As shown in Fig. 5, at the 3 V reverse bias voltage, in the collector’s thickness x changing range, the transit time determined bandwidth of the PD decreases continuously from 109 GHz to 77 GHz, but the total bandwidth rises to a peak of 68 GHz at x=0.9 μm, then decreases. Therefore, the collector layer thickness was optimized at 900 nm. As stated in Section 2, the doping concentration of the EFRL affects the electric field intensity distribution in the collector layer and determines its mean electron transit velocity. In the simulations shown in Fig. 5, the mean electron transit velocity is optimized to its peak drift velocity.

In order to investigate the effect of the doping concentration and thickness of the p-doped absorption region on the SMUTC-PD’s photo-response bandwidth, its doping concentration was set to change from 3×10¹⁶ cm⁻³ to 7×10¹⁶ cm⁻³ for short enough hole relaxation time. Its thickness is denoted as m μm. Then, the thickness of the depleted absorption region was set to (0.45-m) μm. The SMUTC-PD’s frequency photo-response performance was simulated to determine the optimal doping concentration in the p-doped absorption region^[16]. Fig. 6 shows the simulation results for the p-doped absorption region across various doping levels, while Fig. 7 shows the results for different m values. The optimal doping level for the p-doped absorption region was determined to be 3.5×10¹⁶ cm⁻³, while its optimal thickness was determined to be 0.35 μm.

Next, the effect of electron transit in SMUTC-PD’s collector layer on the PD’s parasitic capacitance was analyzed. According to Ref. [17-18], this electron’s transit velocity determined capacitance can be expressed by the following equation:

$ c = - \frac{{{\mathrm{d}}Q}}{{{\mathrm{d}}v}} = - i\frac{{{\mathrm{d}}\tau }}{{{\mathrm{d}}V}} = rP\frac{{{\mathrm{d}}v}}{{{v^2}{\mathrm{d}}E}}\quad, $ (1)

where dQ is the change in electric charge for a given change in voltage, dV. It was concluded that this capacitance depends on the differentiation of the electron transit velocity with respect to the electric field intensity determining it, i.e., the curve slope of the electron transit velocity versus the electric field intensity. It can further reduce the SMUTC-PD’s parasitic capacitance while the electron transits around its peak drift velocity. Finally, Fig. 8 (color online) depicts the frequency response of the optimized SMUTC-PD and of a MUTC-PD with the same structure except for the EFRL. The results show that the SMUTC-PD obtains a 3-dB bandwidth of 68 GHz, which is far greater than the MUTC-PD’s 54 GHz 3-dB bandwidth, while the incident optical power is set to 1 mW only. According to Ref. [17], for a standard MUTC-PD, large incident optical power is needed to regulate the electric field intensity in the collector layer to obtain its electron’s peak drift velocity. Thus, the proposed SMUTC-PD overcomes such limitations.

According to [19], the reflectivity of the top electrode is set at 0.6. As shown in Fig. 9, the responsivity of SMUTC-PD is 0.502 A/W, while the thickness of the absorption layer is set at 0.45 μm.

In conclusion, this paper proposes a novel SMUTC-PD for 100 Gbit/s optical receivers. The electric field intensity in the collector layer is optimized by introducing an electric field regulation layer after the cliff layer, ensuring that electrons consistently operate at peak velocity to offset the increased electron transit time caused by the extended collector layer while also achieving reduced capacitance. Additionally, this layer can redistribute the voltage between the absorption and collector layers, further enhancing the device's overall performance. Moreover, the device exhibits robust performance under low-power conditions, independent of incident optical power fluctuations. Ultimately, an optimal 3-dB bandwidth of 68 GHz with a responsivity of 0.502 A/W was attained, marking a significant 25.9% bandwidth enhancement compared to the original MUTC-PD's 54 GHz bandwidth. These findings demonstrate that the SMUTC-PD, featuring an electric field regulation layer, can effectively enhance the photodetector's high-speed performance, offering a promising solution for improving device bandwidth.
