Circularly polarized lasing from chiral metal-organic frameworks

Dexiang Zhu1,2,3, Zhouyuanhang Wang1,2,3, Xiangyu Xu1,2,3, Wenyu Du1,2,3, Wei Huang1,2,3, Yan Kuai1,2,3, Benli Yu1,2,3, Jianzhong Zheng4, Zhijia Hu1,2,3,5、*, and Siqi Li1,2,3,6、*
Author Affiliations
  • 1Information Materials and Intelligent Sensing Laboratory of Anhui Province, Hefei 230601, China
  • 2School of Physics and Optoelectronic Engineering, Anhui University, Hefei 230601, China
  • 3Key Laboratory of Opto-Electronic Information Acquisition and Manipulation of Ministry of Education, Hefei 230601, China
  • 4School of Environmental Science and Engineering, Nanjing Tech University, Nanjing 211816, China
  • 5e-mail: zhijiahu@ahu.edu.cn
  • 6e-mail: sqli@ahu.edu.cn
  • show less

    Circularly polarized lasers play a pivotal role in classical optics, nanophotonics, and quantum optical information processing, while their fabrication remains complex. This article begins with examining the interactions between stimulated emission and chiral matter, outlining a simple strategy for producing circularly polarized lasing from chiral metal-organic frameworks (MOFs), such as the zeolitic imidazolate framework (ZIF), embedded with achiral laser dyes (L/D-ZIFdyes). It is found that the stimulated emission threshold and intensity are influenced by the interplay between the chiral polarization of the pump light and the inherent chirality of the MOF nanoparticles. We further present the design of a chiral vertical-cavity surface-emitting laser (VCSEL), comprising an L/D-ZIFdyes solid-state film sandwiched between a high-reflectivity distributed Bragg reflector (DBR) mirror and a silver film. The cavity-based lasing exhibits higher asymmetry between emitting left-handed and right-handed polarized light compared to chiral spontaneous emission (SE) and amplified spontaneous emission (ASE), with an asymmetry value glum of approximately ±0.31. This value is nearly four-fold greater than that of SE and twice that of ASE. Our findings reveal a new approach to amplify chiral signals, promoting the comprehension and application of chiral–matter interactions, and offering a simple yet effective strategy to fabricate chiral lasers.

    1. INTRODUCTION

    The phenomenon of chirality, a fascinating aspect of nature, is gaining increasing attention. Chiral materials exhibiting circularly polarized luminescence (CPL) are emerging in various fields, including biological probes [13], three-dimensional displays [47], optoelectronic devices [811], and photocatalytic asymmetric synthesis [1215]. Chiral lasers, in particular, hold promising applications in areas such as biological imaging [1618] and quantum information processing [1921]. For instance, Yuan et al. fabricated chiral biological microlasers using green fluorescent proteins or chiral biomolecules as gain material [22]; Zhang et al. designed a resonant metasurface structure that utilizes the intrinsic chirality and giant field enhancement of the metasurfaces to achieve controlled emission of circularly polarized laser [23]. However, the development of chiral lasers faces challenges, including the high cost of obtaining chiral gain materials and the complexity of fabricating structures to manipulate chirality. Consequently, there is a pressing need for cost-effective optical materials and scalable manufacturing strategies for chiral microlasers/nanolasers.

    Metal-organic frameworks (MOFs) are a class of porous crystal material composed of metal ions or clusters interconnected by organic ligands through coordination bonds [2426]. Their open and versatile structure enables the synthesis of chiral MOFs (CMOFs) using chiral molecular assembly methods. Using such CMOFs as a platform to generate CPL signals is uniquely advantageous. The interconnected dimensionally tunable porous skeletons in MOFs can encapsulate dye molecules. This encapsulation minimizes intermolecular interactions, thereby reducing aggregation-caused quenching (ACQ) effects among dyes [27,28]. Additionally, the strategic integration of crystal synthesis and chiral modules in MOFs facilitates the creation of precise chiral frameworks, providing a detailed model to study the connection between structural and optical chirality [2934]. For instance, Zhao et al. successfully constructed chiral zeolite imidazolate framework (ZIF) displaying CPL by co-blending dimethylthiol-derived chiral emitters with ZIF-8 nanoparticles [35]. The obtained chiral ZIF nanomaterials bring fluorescence intensity enhancement to the chiral emitters, and an order of magnitude significantly amplifies the luminescence asymmetry factor (glum). Zhang et al. investigated the circularly polarized luminescence properties of chiral MOFs [36]. They prepared tunable CPL-emitting crystalline composites (L/D-MOFsachiralfluorophore) using enantiomeric MOFs with helical apertures. By confining achiral organic fluorophores within the nanoscale helical channels of the enantiomer L/D-CMOF, they achieved the amplification of the emission asymmetry factor and further produced a white CPL with multiple dyes.

    While most research has focused on the spontaneous emission (SE) process of CMOFsdye, the potential of stimulated emission-induced circularly polarized amplified spontaneous emission (ASE) and lasing phenomena remains underexplored. Chiral lasing, with its enhanced coherence and emission intensity, can unlock new possibilities for chiral materials. Here, we delved into the circular polarization properties of stimulated emission from CMOFs/achiral luminophores and developed a straightforward, cost-effective method for constructing CMOFs-based chiral lasers. Initially, we achieved the chiral ASE phenomenon using chiral ZIF-8 powder co-assembled with achiral laser dyes 4-(dicyanomethylene)-2-methyl-6-(p-dimethylaminostyryl)-4H-pyran (DCM). The chiral MOF host matrix was built by transferring chiral guest L/D-histidine to the non-chiral ZIF-8 nanoparticles (NPs). After loading achiral dye as the emitter, the obtained L/D-ZIFDCM NPs were confirmed to exhibit vigorous CPL activity first. Subsequently, we observed that the synthesized L/D-ZIFDCM NPs could attain stable ASE when population inversion occurred. The ASE intensity not only depends on the pump energy but also is influenced by the chiral polarization of the pump light and the chiral structure of the samples. We also observed that the right-handed (left-handed) component of emitted light from L-ZIFDCM (D-ZIFDCM) consistently surpassed its left-handed (right-handed) counterpart in both photoluminescence and ASE signals. Finally, we explored a strategy for chiral laser construction by integrating a vertical surface-emitting resonant cavity with L/D-ZIFDCM NPs. Notably, the glum has increased to four-fold (from ±0.085 to ±0.176 and to ±0.310) during the process of converting from SE to ASE and then to lasing emission. The multiple increase of glum presents a novel approach to amplify chiral signals and also proposes an effective strategy to fabricate chiral lasers.

    2. EXPERIMENT

    A. Chemicals

    Zn(NO3)2·6H2O(99%) and 4-(dicyanomethylene)-2-methyl-6-(p-dimethylaminostyryl)-4H-pyran (DCM, 95%) were purchased from Aladdin. L/D-histidine (99%), 2-methylimidazole (98%), methanol (99.5%), and N,N-dimethylformamide (DMF, 99.5%) were purchased from Macklin. All chemicals were used as received without further purification.

    B. Synthesis of Achiral ZIF-8 Nanoparticles

    First, 0.6 g of 2-methylimidazole was dissolved in 30 mL of methanol, and then 0.54 g of Zn(NO3)2·6H2O was dissolved in 30 mL of methanol. The configured Zn(NO3)2·6H2O solution was slowly added to the 2-methylimidazole solution, and the solution gradually changed to white. The reaction system was stirred at room temperature for 24 h. The solid product was collected by centrifugation and the product was washed twice by repeated centrifugation with methanol. Finally, the white powder was dried in an oven at 40°C.

    C. Synthesis of L/D-ZIF Nanoparticles

    0.52 g of 2-methylimidazole and 0.14 g of L/D-histidine were dissolved in 30 mL of a solution of water and methanol (volume ratio 2:3). 120 μL of triethylamine was added to the solution and stirred for 10 min at room temperature. Then, 30 mL of Zn(NO3)2·6H2O (1.8 mmol) methanol solution was slowly added to the mixed ligand solution. The reaction system was stirred at room temperature for 24 h and the crude product was obtained by centrifugation. The product was washed twice with a mixture of methanol and water and dried in an oven at 40°C.

    D. Synthesis of L/D-ZIFDCM Nanoparticles

    0.52 g of 2-methylimidazole, 0.14 g of L/D-histidine, and 0.018 g of DCM were dissolved in 30 mL of a solution of water and methanol (volume ratio 2:3). 120 μL of triethylamine was added to the solution and stirred for 10 min at room temperature. Then, 30 mL of Zn(NO3)2·6H2O (1.8 mmol) methanol solution was slowly added to the mixed ligand solution. The reaction system was stirred at room temperature for 24 h and the crude product was obtained by centrifugation. The product was washed twice with N,N-dimethylformamide, and then twice with a mixture of water and methanol. Finally, the powder obtained was dried in an oven at 40°C.

    E. Fabrication of L/D-ZIFDCM-Based Chiral Lasers

    First, L/D-ZIFDCM  DMF solution was prepared at a concentration of 300 mg/mL. Then 0.3 mL of the solution was added dropwise to the distributed Bragg reflector (DBR) mirror and slowly heated on a hot plate at 40°C. Finally, the silver-coated glass sheet was placed over the DBR and taped tightly around it.

    F. Characterization

    The scanning electron microscopy (SEM) images were obtained on a Hitachi’s REGULUS8230. Transmission electron microscopy (TEM) images and energy dispersive spectrometer (EDS) mapping were obtained on the JEM-2100 (JEOL). The powder X-ray diffraction (XRD) pattern was measured on a SmartLab 9kW. The absorption spectra were measured on a Shimadzu uv3600 (Japan). CD spectra were measured on MOS-500 BIOLOGIC, France. The optical signal was collected by a spectrometer (QE65PRO, Ocean Optics, resolution of 0.4  nm, integration time of 100 ms).

    3. RESULTS AND DISCUSSION

    A straightforward co-assembly strategy was employed to synthesize chiral ZIF-8 loaded with the achiral laser dye [Fig. 1(a)]. In the synthesis process, 2-methylimidazole, L/D-histidine, and organic dye DCM were dissolved in a mixed solution of water and methanol, followed by the addition of triethylamine as a crystallization regulator to regulate the growth of ZIF-8 crystals. Upon adding Zn2+ to this mixed solution and waiting for the MOF growth to complete, the final product was collected and purified to eliminate the excess DCM. The literature suggests that the binding of L/D-histidine to ZIF-8 may be stochastic, with a ZIF-8 cell containing two cages with 24 methylimidazole ligands, each cage randomly binding 2–3 L/D-histidine molecules as linkers [37,38]. During the growth of chiral ZIF-8, the DCM dye is encapsulated into the nanochannels. Other common dyes were also studied, such as rhodamine and coumarin; unluckily, only the linear guest molecules can be encapsulated in the chiral ZIF-8 (Figs. 6 and 7, Appendix A) [37].

    (a) Synthesis process and amplified spontaneous emission mechanism of L/D-ZIF⊃DCM. SEM images of (b) L-ZIF⊃DCM and (c) D-ZIF⊃DCM. Transmission electron microscopy images of (f), (g) L-ZIF⊃DCM and (h), (i) D-ZIF⊃DCM NPs.

    Figure 1.(a) Synthesis process and amplified spontaneous emission mechanism of L/D-ZIFDCM. SEM images of (b) L-ZIFDCM and (c) D-ZIFDCM. Transmission electron microscopy images of (f), (g) L-ZIFDCM and (h), (i) D-ZIFDCM NPs.

    (a) X-ray diffraction patterns of ZIF-8 and L/D-ZIF⊃DCM NPs. (b) Normalized absorption and fluorescence spectra of DCM in methanol. (c) CD absorption spectra of L/D-ZIF⊃ DCM in methanol. (d) CPL spectra of L/D-ZIF⊃DCM (the spectrum is measured by building an optical path in the laboratory).

    Figure 2.(a) X-ray diffraction patterns of ZIF-8 and L/D-ZIFDCM NPs. (b) Normalized absorption and fluorescence spectra of DCM in methanol. (c) CD absorption spectra of L/D-ZIFDCM in methanol. (d) CPL spectra of L/D-ZIFDCM (the spectrum is measured by building an optical path in the laboratory).

    (a) Chiral excitation testing optical path. Emission spectra of L-ZIF⊃DCM excited by (b) left-handed circular polarization lasing and (c) right-handed circular polarization lasing. Emission spectra of D-ZIF⊃DCM excited by (d) left-handed circular polarization lasing and (e) right-handed circular polarization lasing. (Each curve of the spectra is the average value of 50 pulses.) The inset shows the dependence of the emission intensity and full width at half-maximum on the pump energy density in the corresponding spectra.

    Figure 3.(a) Chiral excitation testing optical path. Emission spectra of L-ZIFDCM excited by (b) left-handed circular polarization lasing and (c) right-handed circular polarization lasing. Emission spectra of D-ZIFDCM excited by (d) left-handed circular polarization lasing and (e) right-handed circular polarization lasing. (Each curve of the spectra is the average value of 50 pulses.) The inset shows the dependence of the emission intensity and full width at half-maximum on the pump energy density in the corresponding spectra.

    (a) Circular polarization testing optical path for SE and ASE signals. LCP and RCP emission spectra of (b) L-ZIF⊃DCM and (c) D-ZIF⊃DCM pumped by a CW laser. LCP and RCP emission spectra of (d) L-ZIF⊃DCM and (e) D-ZIF⊃DCM pumped by a nanosecond laser at 38.2 mJ cm−2 (each curve of the spectra is the average value under 50 pulses).

    Figure 4.(a) Circular polarization testing optical path for SE and ASE signals. LCP and RCP emission spectra of (b) L-ZIFDCM and (c) D-ZIFDCM pumped by a CW laser. LCP and RCP emission spectra of (d) L-ZIFDCM and (e) D-ZIFDCM pumped by a nanosecond laser at 38.2  mJcm2 (each curve of the spectra is the average value under 50 pulses).

    (a) Structure diagram of VCSEL based on L/D-ZIF⊃DCM (L/D-VCSEL). (b) Reflectance spectra of DBR and silver films. (c) Emission spectra of L-VCSEL and (d) its integrated emission intensity and FWHM as a function of pump energy density. (e) LCP and RCP emission spectra of L-VCSEL devices when the pump pulse energy density is 38.2 mJ cm−2. (f) Emission spectra of D-VCSEL and (g) its integrated emission intensity and FWHM as a function of pump energy density. (h) LCP and RCP emission spectra of D-VCSEL devices when the pump pulse energy density is 38.2 mJ cm−2. (Each curve of the spectra is the average value under 50 pulses.)

    Figure 5.(a) Structure diagram of VCSEL based on L/D-ZIFDCM (L/D-VCSEL). (b) Reflectance spectra of DBR and silver films. (c) Emission spectra of L-VCSEL and (d) its integrated emission intensity and FWHM as a function of pump energy density. (e) LCP and RCP emission spectra of L-VCSEL devices when the pump pulse energy density is 38.2  mJcm2. (f) Emission spectra of D-VCSEL and (g) its integrated emission intensity and FWHM as a function of pump energy density. (h) LCP and RCP emission spectra of D-VCSEL devices when the pump pulse energy density is 38.2  mJcm2. (Each curve of the spectra is the average value under 50 pulses.)

    Photos of L-ZIF with (a) rhodamine 590, (b) 2-(4-dimethylaminostyryl)-1-methyl-pyridinium iodide (DASPI), and (c) rhodamine 640 under ambient light (top) and UV light (bottom).

    Figure 6.Photos of L-ZIF with (a) rhodamine 590, (b) 2-(4-dimethylaminostyryl)-1-methyl-pyridinium iodide (DASPI), and (c) rhodamine 640 under ambient light (top) and UV light (bottom).

    Photos of L-ZIF⊃ (a) DCM, (b) coumarin 460, and (c) coumarin 540A under ambient light (top) and UV light (bottom).

    Figure 7.Photos of L-ZIF (a) DCM, (b) coumarin 460, and (c) coumarin 540A under ambient light (top) and UV light (bottom).

    Scanning electron microscopy (a), (b) and transmission electron microscopy (c), (d) images of the ZIF-8 nanoparticles.

    Figure 8.Scanning electron microscopy (a), (b) and transmission electron microscopy (c), (d) images of the ZIF-8 nanoparticles.

    Scanning electron microscopy images of the L-ZIF.

    Figure 9.Scanning electron microscopy images of the L-ZIF.

    EDS mapping of L-ZIF⊃DCM.

    Figure 10.EDS mapping of L-ZIFDCM.

    Absorption spectra of L-ZIF and L-ZIF⊃dyes.

    Figure 11.Absorption spectra of L-ZIF and L-ZIFdyes.

    CD spectra of L/D-ZIF.

    Figure 12.CD spectra of L/D-ZIF.

    CPL testing optical path for collection systems.

    Figure 13.CPL testing optical path for collection systems.

    LCP and RCP emission spectra of circularly polarized light.

    Figure 14.LCP and RCP emission spectra of circularly polarized light.

    L/D-ZIF⊃DCM film by drop-injecting with DMF as solvent.

    Figure 15.L/D-ZIFDCM film by drop-injecting with DMF as solvent.

    The right panel of Fig. 1(a) shows the stimulated emission process of DCM-loaded CMOFs. Excitation by external light causes electrons to jump from the ground state (S0) to a higher energy state (lowest excited state, S1) with different magnetic quantum numbers. Following the establishment of population inversion between S0 and S1, chiral MOFs break the equilibrium between left- and right-handed circular polarizations in stimulated emission. Hence, by introducing guest achiral luminophores into the chiral host frame, effective transmission and expression of chirality from host to guest can be achieved. After the dye molecules were encapsulated within the chiral ZIF-8 framework, the nanoporous skeleton in the MOF effectively inhibited the ACQ of the dye. Therefore, we can judge the successful encapsulation of dyes by observing the emission behavior of the chiral ZIF-8 powders [Fig. 7(a)].

    Figures 1(b)–1(e) show the SEM images of the synthesized L/D-ZIFDCM NPs. The noticeable increase in cell volume and alteration in morphology of L/D-ZIFDCM compared to pure ZIF-8 (Fig. 8, Appendix B) can be attributed to the structural chirality imparted to ZIF-8 by the introduction of L/D-histidine. The structural similarities between L/D-ZIFDCM and L-ZIF (shown in Fig. 9, Appendix B) confirm that unlike L/D-histidine, the dye molecules are encapsulated inside ZIF-8 rather than being assembled onto its framework. TEM images in Figs. 1(f)–1(i) validate the structural chirality of L/D-ZIFDCM NPs. EDS mapping (Fig. 10, Appendix B) reveals a uniform distribution of C, N, O, and Zn in L/D-ZIFDCM NPs.

    As shown in Fig. 2(a), the XRD peaks of L/D-ZIFDCM align with those of achiral ZIF-8 as well as the simulated data, confirming that L/D-ZIFDCM maintains the same crystal structure as ZIF-8. Figure 2(b) displays the absorption and fluorescence spectra of the organic dye DCM in methanol. Figure 2(b) presents the absorption and fluorescence spectra of DCM in methanol, highlighting a broad absorption band between 400 and 550 nm and a fluorescence range from 550 nm to 700 nm. Additionally, we analyzed the absorption spectra of L-ZIF encapsulating various dyes (L-ZIFdye) as shown in Fig. 11, Appendix B. The results revealed that alongside the intrinsic absorption peaks of L-ZIF (200–300 nm), new absorption peaks emerged corresponding to the absorption bands of the encapsulated dyes. L/D-ZIFDCM displays a stable circular dichroic (CD) signal in the DCM gain range (Fig. 12, Appendix B), with L-ZIFDCM showing a negative CD signal and D-ZIFDCM the opposite, as depicted in Fig. 2(c). This difference highlights the distinct responses of the two chiral structures to circularly polarized light. Interestingly, L/D-ZIFDCM exhibits CPL signals similar to its CD properties [Fig. 2(d)], emphasizing its effectiveness in displaying chiral properties.

    To investigate the chiral characteristics of L/D-ZIFDCM, the emission spectra of the film samples under circularly polarized laser excitation were explored using the experimental setup depicted in Fig. 3(a). The film samples were prepared by compressing equal amounts of L/D-ZIFDCM powder between two glass sheets. The wavelength of the pump light was set at 532 nm, coinciding with the wavelengths where the CD spectra of L-ZIFDCM and D-ZIFDCM show significant negative and positive signals, respectively.

    The pump laser beam passed through a quarter-wave plate, converting its vertical polarization into either left- or right-handed circular polarization. Subsequently, the laser beam, after being focused through a lens, was directed vertically onto the sample. Emissions from the sample were captured by a horizontally positioned objective lens and analyzed with an optical spectrometer. Initially, the emission spectrum of L-ZIFDCM under a left-handed circularly polarized laser excitation was measured, as illustrated in Fig. 3(b). At the pump energy density of 1.27  mJcm2, a broad fluorescence peak centered at 610 nm with a full width at half-maximum (FWHM) of about 55 nm was observed. As the pump energy density gradually increases, the emission intensity increases and the spectrum narrows. When the pump energy density exceeds 5.09  mJcm2, the FWHM reduces to 20  nm, and the emission intensity increases abruptly, indicating a transition from broad SE to ASE. The integrated emission intensity and FWHM versus pump energy density are shown in the illustration, indicating a threshold of 5.7  mJcm2 for ASE.

    We also observed ASE behavior in L/D-ZIFDCM under right-handed circularly polarized laser excitation [Fig. 3(c)]. The FWHM of L-ZIF-DCM initially at about 55 nm, narrowed to approximately 12 nm once ASE occurred. Notably, L-ZIFDCM exhibited a stronger response to right-handed circularly polarized light compared to left-handed circularly polarized light. This disparity was manifested in a more intense fluorescence response under right-handed excitation at the same pump energy density and a lower ASE threshold for right-handed excitation than for left-handed excitation, as illustrated in Fig. 3(c). For the case of D-ZIFDCM’s stimulated emission pumped by a chiral laser [Figs. 3(d) and 3(e)], we observed an opposite phenomenon. The emission signal of D-ZIFDCM exhibited opposite intensity and ASE threshold contrast by different chiral laser pumping compared to L-ZIFDCM. This can be attributed to the fact that L/D-ZIFDCM with contrasting chiral structures responds differently to opposite circularly polarized optical absorption [22,39]. These results demonstrate that L/D-ZIFDCM exhibits distinct ASE behavior under chiral excitation, allowing for the selection of an appropriate circular polarization laser to reduce the ASE threshold.

    To further explore the chiral nature of the emission signal of the L/D-ZIFDCM without optical spin injection, the optical test path was adjusted as follows [Fig. 4(a)]. The sample was excited using a 532 nm linearly polarized continuous-wave laser beam, and the emission of the sample was separated into left- and right-handed circularly polarized light (LCP and RCP) components using a combination of a quarter-wave plate and a polarizer. As for the reliability analysis of the collection optical path (combination of quarter-wave plate and polarizer), we observed optical path errors by decomposing circularly polarized light (Fig. 13, Appendix C). To quantify the asymmetric luminescence signal intensity, we introduced the glum factor to characterize the polarization, defined as glum=2(ILIR)/(IL+IR), where I is the emission intensity, and L/R represents the left- and right-handed circular polarization components. The glum obtained is approximately equal to 0 (Fig. 14, Appendix C). According to the PL signal in Figs. 4(b) and 4(c), it can be found that different chiral structures have different circularly polarized component-dominated SE signals, with L-ZIFDCM producing RCP-dominated SE and D-ZIFDCM producing LCP-dominated SE. This phenomenon may be due to the fact that the L-ZIFDCM (D-ZIF-DCM) absorbs more right-handed (left-handed) circularly polarized photons, leading to a larger number of photons being excited to produce more intense spontaneous emission. A glum value of ±0.085 was calculated for the SE from L/D-ZIFDCM. This indicates that the larger glum obtained from SE of L/D-ZIFDCM samples originates from its chiral structure and not from errors in the collection optical paths.

    We subsequently measured the ASE’s glum by switching the excitation source to a 532 nm nanosecond pulsed laser, thus providing a higher pump energy to achieve population inversion. As depicted in Figs. 4(d) and 4(e), the samples inherit the chiral properties of its PL signal in the ASE state. Interestingly, for both L-ZIFDCM and D-ZIFDCM, we observed a significantly larger glum of ±0.176. We suggest that the marked discrepancy between the left- and right-handed circularly polarized components of the stimulated emission arises due to the sharp increase in emission intensity beyond the ASE threshold. This increase in emission intensity consequently leads to a rise in the glum value, indicating a stronger chiral response in the ASE regime compared to SE. L/D-ZIFDCM NPs exhibit low thresholds with stable ASE signals, qualifying them as excellent materials for lasing applications.

    To generate stimulated emission oscillation within an optical cavity, we employed a Fabry–Perot (F-P) cavity design [Fig. 5(a)]. This design consisted of a parallel high-reflectivity DBR mirror and a silver film, with L/D-ZIFDCM NPs serving as the optical gain medium. In the fabrication process, we first deposited a layer of L/D-ZIFDCM NPs on the DBR mirror using a drop-casting method. It was crucial to achieve a gain-mediated film with a uniform texture to prevent strong scattering interactions between the high-power pump laser and the L/D-ZIFDCM NPs, which could potentially damage the DBR mirror. Herein, we prepared a 300 mg/mL solution of L/D-ZIFDCM NPs using DMF as a solvent. As a polar solvent, DMF exhibits a high intermolecular gravitational force, leading to a low surface tension [40]. The lower surface tension, combined with a slower evaporation rate during droplet evaporation, enables the droplet to flow from areas of high NP concentration at the edge to lower concentration at the center. This flow pattern effectively prevents the accumulation of NPs at the droplet’s edge, resulting in a uniformly distributed and completely solid L/D-ZIFDCM NPs film on the DBR mirror (Fig. 15, Appendix D). Finally, we covered the glass substrate coated with silver film and sealed the edges with tape to complete the construction of the optical resonant cavity. The reflectance of DBR and Ag films was measured using a UV spectrophotometer. DBR allows the pump laser beam (532 nm) to pass through, while the reflectivity around 610 nm at the emission center of L/D-ZIFDCM NPs is greater than 99.6%. The reflectivity of Ag film (98.2%) is slightly lower than that of DBR, thus guiding the lasing emission [Fig. 5(b)].

    We initially examined the lasing properties of the device pumped by a nanosecond laser, capturing the transmitted emission signal across the Ag film in a vertical orientation. The emission spectra of a vertical-cavity surface-emitting laser (VCSEL) based on L-ZIFDCM is shown in Fig. 5(c). Notably, the broad PL peak at 613 nm rapidly changes to a distinct lasing peak as the pump power increases. The pump power density-dependent emission intensity and FWHM of the device are shown in Fig. 5(d), where the threshold behavior of the emission intensity and the marked reduction in FWHM substantiate the generation of lasing action. The L-ZIFDCM-based VCSEL exhibits an exceptionally low laser threshold of 2.3  mJcm2 (significantly smaller than the ASE threshold), which can be attributed to the increased propagation distance and the accumulation of photons inside the F-P cavity. Compared to the ASE signals observed in bare L/D-ZIFDCM film, the laser linewidth decreases significantly from 13–15 nm to about 7 nm. The optical path for measuring the VCSEL circular polarization is the same as that shown in Fig. 4(a). The optical signal emitted by the VCSEL is decomposed by a quarter-wave plate and a polarizer and is also collected along the central normal direction. At the pump energy density of 38.2  mJcm2, the RCP lasing emitted by the device is 36% higher than the LCP lasing, with a glum of 0.310, indicating a significant enhancement of the excited chiral light within the F-P cavity.

    The D-ZIFDCM-based laser devices have similar emission spectra and lasing thresholds to the L-ZIFDCM, while the intensity of LCP lasing is significantly higher than that of RCP lasing at sample pumping energy (with a glum value of approximately 0.308). Contrary to the intuitive thought that a planar F-P cavity might invert the chirality of light [4143], our experimental results demonstrate that the transmitted light, after interaction with an active resonant cavity, retains the same chirality as the ASE signal. However, experimental results show that the transmitted light after the action of an active resonant cavity retains the same chirality as the ASE signal. The glum value of VCSEL is 1.8 times that of ASE and nearly 4 times that of PL. Such significant glum enhancement of the chiral lasing within an F-P cavity is similar to previous reports [22].

    4. CONCLUSION

    In conclusion, we have successfully achieved chiral stimulated emission in chiral MOF NPs embedded with achiral dyes. The CPL and ASE signals of the L/D-ZIFDCM are manipulated by their structural configurations. Notably, the ASE intensity and threshold are influenced by the circular polarization of the pump light in relation to the intrinsic chirality of ZIF-8. Furthermore, we have developed a fabrication method for L/D-ZIFDCM-based VCSELs and achieved low-threshold lasing emission. Our investigation into the circular polarization characteristics of stimulated emission process revealed a higher asymmetry between the emitted left- and right-handed polarized light compared to the standard SE and ASE signal, with the glum increasing from ±0.08 to ±0.17 and to ±0.31. These findings indicate that circularly polarized stimulated emission offers significant advantages over ordinary circularly polarized SE. Our study provides a simple and cost-effective pathway for creating chiral ASE and laser devices, poised to enhance the fabrication and widen the application scope of chiral lasers.

    Acknowledgment

    Acknowledgment. The authors thank the Modern Experimental Technology Center of Anhui University for the SEM and TEM measurements.

    APPENDIX A: OPTICAL PHOTOS OF L/D-ZIF?DYE POWDER

    We found that the rhodamine series of dyes rhodamine 590, rhodamine 640, and trans-4-[4-(dimethylamino)styryl]-1-methylpyridinium iodide (DASPI) cannot adapt well to chiral ZIF-8 (Fig. 6), whereas the coumarin series as well as 4-(dicyanomethylene)-2-methyl-6-(p-dimethylaminostyryl)-4H-pyran can be easily wrapped into the ZIF-8 framework (Fig. 7).

    APPENDIX B: MATERIAL CHARACTERIZATION

    The loading of L-histidine changed the regular rhombic dodecahedral morphology of ZIF-8 (Figs. 8 and 9). EDS mapping (Fig. 10) reveals a uniform distribution of C, N, O, and Zn inL/D-ZIFDCM nanoparticles. After loading the dye, L/D-ZIFdye showed a new absorption peak in the absorbance band of the dye (Fig. 11). The L/D-ZIF also exhibited a CD signal as shown in Fig. 12.

    APPENDIX C: COLLECTION OPTICAL PATH TESTING

    The 633 nm pump laser source is converted into circularly polarized light through the polarizer and the wave plate (the optical axis of the quarter-wave plate is at an angle of 45° with respect to the transmission axis of the polarizer). The circularly polarized light is decomposed into LCP and RCP components by rotating the other polarizer (Fig. 13). The glum obtained is approximately equal to 0 (Fig. 14).

    APPENDIX D: MORPHOLOGICAL CHARACTERIZATION OF L/D-ZIF?DCM FILMS

    We prepared solid films with uniform texture using a DMF solution of L/D-ZIFDCM (Fig. 15). The film was placed between a DBR and a glass plate covered with a silver film to form a chiral laser device.
