Laser & Optoelectronics Progress, Volume. 61, Issue 15, 1512003(2024)

Quadratic Peak-Seeking Algorithm to Improve The Frequency Shift Positioning Accuracy of Brillouin Optical Time Domain Reflectometer

Yingkai Chen1, Liping Chen2, Yonghong Zheng3, Bo Gao4, Yongzheng Li3、***, Linlin Fu5, Xinyu Liu1, Dingyi Ma1, Haoran Gao1, Qiuming Huang1, Linfeng Guo1,6、*, and Xiaomin Xu7、**
Author Affiliations
  • 1School of Physics and Optoelectronic Engineering, Nanjing University of Information Science & Technology, Nanjing 210044, Jiangsu, China
  • 2China Railway (Shanghai) Investment Group Co., Ltd., Shanghai 200126, China
  • 3China Railway No.3 Group East China Construction Co., Ltd., Nanjing 211153, Jiangsu, China
  • 4Nanjing Metro Construction Co., Ltd., Nanjing 210019, Jiangsu, China
  • 5China Railway Tunnel Group No.2 Co., Ltd., Langfang 065200, Hebei, China
  • 6Jiangsu Key Laboratory for Optoelectronic Detection of Atmosphere and Ocean, Nanjing 210044, Jiangsu, China
  • 7Department of Engineering, University of Cambridge, Cambridge CB2 1PZ, United Kingdom
  • show less

    The practical demand for the use of Brillouin optical time-domain reflectors in engineering applications is constantly being raised: how to accurately determine the starting position of strain/temperature change, facilitate rapid repair, save manpower and material costs, especially in complex situations such as underground engineering and underwater engineering that cannot be directly observed, the precise determination of the starting position of frequency shift along the fiber optic line is particularly important. An improvement is made on the algorithm for obtaining spectrum in Brillouin optical time-domain reflectometer based on peak finding algorithm and short-term Fourier transform. A new quadratic peak finding algorithm is proposed, which calculates the starting and ending points of temperature/strain by judging the peak situation in the Brillouin gain spectrum. In the case of a pulse width of 100 ns and a monitoring distance of 1800 m, the positioning error of the starting and ending points of the 50 m temperature range is 0.4 m, achieving a spatial resolution of 1 m at a detection distance of 2000 m. This algorithm improves the accuracy of the Brillouin optical time-domain reflectometer in locating the temperature starting point and length without increasing the computational time and optoelectronic devices. Compared with the Brillouin optical time-domain reflectometer using peak finding algorithm, the Brillouin optical time-domain reflectometer using secondary peak finding algorithm has stronger practicality and higher cost-effectiveness.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Yingkai Chen, Liping Chen, Yonghong Zheng, Bo Gao, Yongzheng Li, Linlin Fu, Xinyu Liu, Dingyi Ma, Haoran Gao, Qiuming Huang, Linfeng Guo, Xiaomin Xu. Quadratic Peak-Seeking Algorithm to Improve The Frequency Shift Positioning Accuracy of Brillouin Optical Time Domain Reflectometer[J]. Laser & Optoelectronics Progress, 2024, 61(15): 1512003

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Instrumentation, Measurement and Metrology

    Received: Aug. 24, 2023

    Accepted: Sep. 6, 2023

    Published Online: Aug. 8, 2024

    The Author Email: Yongzheng Li (liyongzhengzt@163.com), Linfeng Guo (guolf_nj@163.com), Xiaomin Xu (xx787@eng.cam.ac.uk)

    DOI:10.3788/LOP231978

    CSTR:32186.14.LOP231978
