Laser & Optoelectronics Progress, Volume. 61, Issue 12, 1211004(2024)

Adaptive Binocular Digital Fringe Projection Method for High Reflective Surfaces

Jingfa Lei1,2, Bo Zhao1,2, Ruhai Zhao1,2、*, Yongling Li1,3, and Miao Zhang1,2
Author Affiliations
  • 1School of Mechanical and Electrical Engineering, Anhui Jianzhu University, Hefei 230601, Anhui, China
  • 2Anhui Key Laboratory of Intelligent Manufacturing of Construction Machinery, Hefei 230601, Anhui, China
  • 3Sichuan Key Laboratory of Process Equipment and Control Engineering, Zigong 643000, Sichuan, China
  • show less

    Binocular digital fringe projection has been widely used in three-dimensional (3D) shape measurement. However, for objects with considerable variations in surface reflectance, the information on digital fringes may be lost due to overexposure, resulting in a decrease in measurement accuracy. Therefore, this paper proposes an adaptive binocular digital fringe projection method to address this issue. First, grayscale images with different intensities are projected onto the object's surface to create a mask image. Furthermore, multiple sets of saturated point pixel clusters are generated, and the surface reflectance of the object within these clusters is calculated. Besides, the optimal projection light intensity value for each pixel in the clusters of saturated pixel points is determined. Second, the generated adaptive digital fringe sequence is projected onto the object's surface using the mapping relationship between the camera and projector pixel points. Finally, the phase is solved using the multifrequency heterodyne method, and the 3D object shape is reconstructed through phase matching performed by the left and right cameras. The experimental results show that the proposed method achieves a reduction of 99.57% and 96.57% in phase root mean square and average relative errors, respectively, compared with the existing binocular methods. Additionally, more accurate phase extraction and matching of the saturated exposure area are realized, and the relative error of height in the fitting model is reduced by 72.12%, thereby enhancing the measurement accuracy of the 3D shape of the strongly reflective object surfaces.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Jingfa Lei, Bo Zhao, Ruhai Zhao, Yongling Li, Miao Zhang. Adaptive Binocular Digital Fringe Projection Method for High Reflective Surfaces[J]. Laser & Optoelectronics Progress, 2024, 61(12): 1211004

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Imaging Systems

    Received: Jul. 12, 2023

    Accepted: Aug. 22, 2023

    Published Online: Jun. 5, 2024

    The Author Email: Zhao Ruhai (zhaoruhai@ahjzu.edu.cn)

    DOI:10.3788/LOP231704

    CSTR:32186.14.LOP231704
