Acta Optica Sinica, Volume. 45, Issue 16, 1622001(2025)

Design of Stellar Simulation System with Independent Modulation Based on Regional Division

Da Xu1,2, Gaofei Sun1,2、*, and Xianzhu Liu1
Author Affiliations
  • 1Department of Opto-Electronic Engineering, Changchun University of Science and Technology, Changchun 130022, Jilin , China
  • 2Jilin Engineering Research Center of Photoelectric Measurement & Control Instruments, Changchun 130022, Jilin , China
  • show less

    Objective

    Traditional star sensors and emerging attitude navigation sensors face increasing limitations in calibration techniques. Current methodologies inadequately address complex space environment simulation requirements, high-precision calibration standards, and rapid testing needs for large-scale constellations (e.g., the Qianfan Constellation Project). This research presents a region-partitioned star-point independent modulation stellar simulation system for generating authentic star maps with precise stellar colors. The system enables independent spectral and energy modulation for individual star points, offering an alternative to conventional star observation tests and advanced calibration capabilities for next-generation navigation devices.

    Methods

    The research began with an analysis of the minimum modulation rate necessary for stellar spectral modulation, followed by the derivation of theoretical modulation rates meeting spectral simulation accuracy requirements. Based on predetermined digital micromirror device (DMD) partitioning criteria, the DMD was segmented accordingly. The system architecture incorporated a cylindrical collimating beam expansion system and a three-region independent modulation optical system. Image quality assessment confirmed the production of flat, curvature-free spot shapes and achieved spectral resolution exceeding 5 nm across the spectral plane, validating the system's capacity for accurate spectral modulation and simulation.

    Results and Discussions

    Performance tests utilized an established experimental platform. Initial modulation capability assessment revealed a maximum full width at half maximum (FWHM) of 4.61 nm for monochromatic light output, satisfying the 5 nm spectral resolution requirement. Spectral simulation accuracy test across three regions employed target values of 3000 K, 5000 K, 7000 K, and 9000 K. Results indicated a maximum spectral simulation error of 7.2% across regions, with inter-region consistency variations below 1.8%. Independent spectral modulation verification assigned sub-regions 1, 2, and 3 to simulate 3000 K, 7000 K, and 9000 K, respectively, yielding spectral simulation errors of 4.7%, 4.8%, and 4.3%. These findings demonstrate the system’s effectiveness in achieving precise, independent spectral control for multiple star simulations.

    Conclusions

    This research establishes a region-partitioned modulation methodology for star map simulation, facilitating precise spectral control of individual star points. Experimental validation confirmed high accuracy (<7.5% error) and consistency (<1.8% deviation) across a 3000?9000 K range. The system demonstrates capability in simulating three stars with arbitrary color temperatures, indicating its potential as a replacement for traditional star observation tests. This technology advances calibration solutions for future navigation systems while reducing calibration complexity and testing duration, supporting efficient star sensor mass production.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Da Xu, Gaofei Sun, Xianzhu Liu. Design of Stellar Simulation System with Independent Modulation Based on Regional Division[J]. Acta Optica Sinica, 2025, 45(16): 1622001

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Optical Design and Fabrication

    Received: Apr. 21, 2025

    Accepted: May. 19, 2025

    Published Online: Aug. 13, 2025

    The Author Email: Gaofei Sun (sungf@cust.edu.cn)

    DOI:10.3788/AOS250970

    CSTR:32393.14.AOS250970
