High Power Laser and Particle Beams, Volume. 37, Issue 3, 035010(2025)

Development of dual front-stage voltage fast pulsed power supply

Mingrui Li1,2, Xiaojun Wang1,2, Daqing Gao1,2、*, Jie Gao1,2, Jiqiang Li1, Kaiming Yan1, Yuqiang Zhang1, Mengyan Sun2, Anzhou Huo1, Zhengyu Wang1, and Xin Zhao1
Author Affiliations
  • 1Institute of Modern Physics, Chinese Academy of Sciences, Lanzhou 730000, China
  • 2School of Nuclear Science and Technology, University of Chinese Academy of Sciences, Beijing 100049, China
  • show less

    A fast pulsed power supply is developed to meet the requirements of High Intensity heavy-ion Accelerator Facility (HIAF) ion source. Based on front-stage voltage fast switching method, we proposed a circuit topology ensuring fast rising of current and flat top stability. In this paper the circuit is analyzed, the essential parameters of the circuit are calculated, and the control method is established for adapting abruptly-changed voltage. A 16 kW power supply based on the principle of modular manufacturing was tested on real magnet load. The results show the value of flat top current reaches 570 A, the error is less than ±1×10-4, the repetition frequency reaches 3 Hz, the rise time and fall time is less than 30 ms, the flat top time can be set within 900 ms.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Mingrui Li, Xiaojun Wang, Daqing Gao, Jie Gao, Jiqiang Li, Kaiming Yan, Yuqiang Zhang, Mengyan Sun, Anzhou Huo, Zhengyu Wang, Xin Zhao. Development of dual front-stage voltage fast pulsed power supply[J]. High Power Laser and Particle Beams, 2025, 37(3): 035010

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Power Circuit Topology and Simulation Technology

    Received: Sep. 27, 2024

    Accepted: Feb. 1, 2025

    Published Online: Apr. 29, 2025

    The Author Email: Daqing Gao (gaodq@impcas.ac.cn)

    DOI:10.11884/HPLPB202537.240344
