Laser & Optoelectronics Progress, Volume. 62, Issue 16, 1624001(2025)

Dust Density Detection Method for Photovoltaic Module Surface Based on Image Dark Channel Prior

Fangbin Wang1,2、*, Hualin Mao1, Xue Gong1,2, Darong Zhu1,2, Weisong Zhao1, and Ping Wang1
Author Affiliations
  • 1School of Mechanical and Electrical Engineering, Anhui Jianzhu University, Hefei 230601, Anhui , China
  • 2Key Laboratory of Construction Machinery Fault Diagnosis and Early Warning Technology, Hefei 230601, Anhui , China
  • show less

    Dust on the surface of photovoltaic (PV) modules significantly reduces their power generation efficiency and may also corrode the protective glass surface of the panels, necessitating monitoring and cleaning. However, existing operational and maintenance detection methods for PV power stations struggle to accurately assess the dust density on PV modules, which brings difficulties to the cleaning work of PV modules. This study proposes an image dark channel prior-based detection method of dust density on PV module surface. First, the relationship between the transmittance of dust on PV module surfaces and the dust density is derived based on the assumption of dust spherical particles. Subsequently, the calculation method for the transmittance of dust on PV module surfaces based on the image bright primary color is presented by the prior knowledge of the dark channel. Finally, an experimental platform is set up and several indoor dust density detection experiments on PV module surfaces are conducted. The experimental results indicate that there exists a clear exponential function relationship between the transmittance calculated using the image dark channel prior knowledge and the dust density. Moreover, the calculated dust density has little relation with the irradiance from light source, and the accuracy of the established model increases first and decreases later with the increase of observation angle and incident angle, which are recommended to take between 30°‒40° for practical application.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Fangbin Wang, Hualin Mao, Xue Gong, Darong Zhu, Weisong Zhao, Ping Wang. Dust Density Detection Method for Photovoltaic Module Surface Based on Image Dark Channel Prior[J]. Laser & Optoelectronics Progress, 2025, 62(16): 1624001

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Optics at Surfaces

    Received: Feb. 5, 2025

    Accepted: Mar. 14, 2025

    Published Online: Aug. 6, 2025

    The Author Email: Fangbin Wang (wangfb@ahjzu.edu.cn)

    DOI:10.3788/LOP250598

    CSTR:32186.14.LOP250598
