Laser & Optoelectronics Progress, Volume. 61, Issue 12, 1211003(2024)

Color 3D Reconstruction for Used Machinery Parts using Improved SGM

Zelin Zhang1,2, Xing Cao1, Lei Wang1,2、*, and Xuhui Xia1,2
Author Affiliations
  • 1Key Laboratory of Metallurgical Equipment and Its Control, Ministry of Education, Wuhan University of Science and Technology, Wuhan 430081, Hubei, China
  • 2Hubei Key Laboratory of Mechanical Transmission and Manufacturing Engineering, Wuhan University of Science and Technology, Wuhan 430081, Hubei, China
  • show less

    To improve the remanufacturing efficiency of used mechanical parts and detect their surface failure state comprehensively, this paper proposes a color three-dimensional (3D) reconstruction technique using an improved semi-global matching (SGM). Traditional SGM algorithms often produce unsatisfactory parallax maps owing to the complex structure of mechanical parts and large illumination interference in a real environment. Addressing this, we propose a multifeature cost fusion strategy, which integrates color cost, Census transform, and gradient data to establish a more comprehensive similarity measurement function to improve the reliability of the initial cost. Furthermore, in the process of cost aggregation, a gradient threshold distinguishes between weak textures and edge regions. Moreover, we employ the Gaussian function to determine the distance weight of the local cross region to improve the algorithm's matching performance in the image light distortion region, weak part texture, and complex edge structures. Finally, we obtain a refined parallax map using parallax calculation and multistep parallax optimization. Besides, by merging this with an RGB image via texture mapping, we achieve a 3D color model reconstruction for used machinery components. Experimental outcomes indicate that the proposed method offers precise texture details and minimal size error for 3D color models and can be applied to the online detection of the surface failure information of used mechanical parts in the real production line.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Zelin Zhang, Xing Cao, Lei Wang, Xuhui Xia. Color 3D Reconstruction for Used Machinery Parts using Improved SGM[J]. Laser & Optoelectronics Progress, 2024, 61(12): 1211003

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Imaging Systems

    Received: Jul. 5, 2023

    Accepted: Aug. 11, 2023

    Published Online: Jun. 5, 2024

    The Author Email: Wang Lei (candywang@wust.edu.cn)

    DOI:10.3788/LOP231667

    CSTR:32186.14.LOP231667
