Journal of Inorganic Materials, Volume. 40, Issue 5, 521(2025)

Broadband 3 μm Mid-infrared Emission in Dy3+/Yb3+ Co-doped Tellurite Glass under 980 nm LD Excitation

Yuzhou PAN, Fajian HE, Lulu XU, and Shixun DAI*
Author Affiliations
  • Laboratory of Infrared Material and Devices, Research Institute of Advanced Technologies, Ningbo University, Ningbo 315000, China
  • show less

    Three to five μm mid-infrared laser has broad applications in atmospheric communication, environmental monitoring, medical treatment, and defense. Here, a series of glasses with compositions of 70TeO2-25ZnO-5La2O3, doped with Dy3+ or Yb3+, and co-doped with Dy3+/Yb3+, were prepared using the melt-quenching method in an inert atmosphere-protected glovebox. Thermal properties, structural characteristics, hydroxyl content, and mid-infrared luminescence of the glasses were characterized through measurements such as differential scanning calorimetry (DSC), X-ray diffraction (XRD), Raman spectra, transmission spectra, and 3 μm band fluorescence spectra. The results indicate that 70TeO2-25ZnO-5La2O3 glass possesses high resistance to crystallization (ΔT=101 ℃) and low phonon energy (760 cm-1). Under 980 nm laser diode (LD) excitation, Dy3+/Yb3+ co-doped tellurite glass produces a broadband fluorescence emission around 3 μm region, with a full width at half maximum (FWHM) of 326 nm. This is attributed to the high energy transfer efficiency from Yb3+ to Dy3+ (98.74%) and the low hydroxyl absorption coefficient near 3 μm (0.32 cm-1). Based on Judd-Ofelt and Dexter theories, spontaneous radiative transition probability, fluorescence branching ratio, and other spectroscopic parameters of Dy3+ ions, as well as microscopic parameters of Yb3+→Dy3+ energy transfer, were calculated. The primary energy transfer pathway is analyzed and identified as Yb3+: 2F5/2→Dy3+: 6H7/2, 6F9/2. This study demonstrates that the low-hydroxyl Dy3+/Yb3+ co-doped TeO2-ZnO-La2O3 glass can serve as an excellent 3 μm mid-infrared gain medium.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Yuzhou PAN, Fajian HE, Lulu XU, Shixun DAI. Broadband 3 μm Mid-infrared Emission in Dy3+/Yb3+ Co-doped Tellurite Glass under 980 nm LD Excitation [J]. Journal of Inorganic Materials, 2025, 40(5): 521

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Oct. 24, 2024

    Accepted: --

    Published Online: Sep. 2, 2025

    The Author Email: Shixun DAI (daishixun@nbu.edu.cn)

    DOI:10.15541/jim20240441
