Laser & Optoelectronics Progress, Volume. 61, Issue 17, 1712007(2024)

Simultaneous Measurement Method of Six-Degree-of-Freedom Error of Precision Rotating Axis

Hongquan Wen1, Wenjun Yang1,2、*, Zilong Zhang1, Zhen Liu1, and Liangcai Zeng1,2
Author Affiliations
  • 1School of Mechanery and Automation, Wuhan University of Science and Technology, Wuhan 430081, Hubei, China
  • 2Key Laboratory of Metallurgical Equipment and Control Technology, Ministry of Education, Wuhan University of Science and Technology, Wuhan 430081, Hubei, China
  • show less

    This study proposes a method for simultaneous measurement of six-degree-of-freedom errors in precision rotating axes using absolute measurement. The proposed method addresses the limitations of current precision rotating shaft motion accuracy detection technologies, which are unable to balance high precision, efficiency, dynamic continuity, and comprehensive error measurement. Utilizing multi-wavelength phase-shifting interferometry, the method measures the instantaneous absolute pose of micro/nanostructure characteristic samples aligned with the rotational axis motion. It establishes a six-degree-of-freedom motion error model for precision rotating axes and identifies the mapping relationship between each degree of freedom error and the pose transformation of the standard micro/nanostructure feature space. By analyzing the characteristic spatial pose of micro and nanostructures, the six-degree-of-freedom error of the precision rotation axis is separated, enabling simultaneous, continuous, and high-precision measurements. Experiments conducted on a precision air bearing rotary table revealed an angle positioning error of 2.98", a tilt error of 0.91", a radial error of 399 nm, and an axial error of 37 nm.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Hongquan Wen, Wenjun Yang, Zilong Zhang, Zhen Liu, Liangcai Zeng. Simultaneous Measurement Method of Six-Degree-of-Freedom Error of Precision Rotating Axis[J]. Laser & Optoelectronics Progress, 2024, 61(17): 1712007

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Instrumentation, Measurement and Metrology

    Received: Dec. 25, 2023

    Accepted: Jan. 26, 2024

    Published Online: Sep. 14, 2024

    The Author Email: Wenjun Yang (yangwenjun@wust.edu.cn)

    DOI:10.3788/LOP232750

    CSTR:32186.14.LOP232750
