Chinese Journal of Quantum Electronics, Volume. 42, Issue 2, 187(2025)

Investigation of high‑precision real time wavelength monitoring method based on Fabry‑Perot etalon

LIN Yuqing1,2, XIA Hua1、*, ZHANG Zhirong1,2,3,4,5、**, SUN Pengshuai1, WU Bian1, LI Zhe6, and CAI Yongjun7
Author Affiliations
  • 1Anhui Provincial Key Laboratory of Photonic Devices and Materials, Anhui Institute of Optics and Fine Mechanics, HFIPS, Chinese Academy of Sciences, Hefei 230031, China
  • 2Science Island Branch, Graduate School of University of Science and Technology of China, Hefei 230026, China
  • 3Key Laboratory of Environmental Optics and Technology, Anhui Institute of Optics and Fine Mechanics, HFIPS,Chinese Academy of Sciences, Hefei 230031, China
  • 4College of Environmental Science and Optoelectronic Technology, University of Science and Technology of China,Hefei 230026, China
  • 5Advanced Laser Technology Laboratory of Anhui Province, Hefei 230037, China
  • 6College of Physics and Materials Engineering, Hefei Normal University, Hefei 230601, China
  • 7Pipe China Institute Academy of Science & Technology, Langfang 065000, China
  • show less

    When high-precision laser absorption spectroscopy techniques such as cavity ring-down spectroscopy and cavity enhanced spectroscopy are used in gas measurements, the stability of laser output wavelength directly affects the accuracy of measurement results. Therefore, accurate measurement of laser wavelength is crucial to high-sensitivity laser absorption spectroscopy technology. Taking the distributed feedback (DFB) laser commonly used in the cavity ring-down absorption spectrum as an application example, a wavelength monitoring system is built in this work based on Fabry-Perot (F-P) etalon. The system utilizes the interference phenomenon of F-P etalon, and adjusts the laser driving current to scan the wavelength. And at the same time, a standared wavelength meter is used as reference, then the functional relationship between wavelength and interference light intensity can be obtained, which will be used for inversion of wavelength information in the subsequent measurement. In the experiment, a DFB laser with central wavelength of 1653 nm is used, and the F-P system has realized the wavelength measurement in the range of 1653.66160 nm to 1653.77718 nm for this laser. The linear fitting correlation between the measurement results and the reading of the reference wavelength meter is 0.9999, which proves the reliability of the F-P wavelength monitoring system. In order to further verify the stability and measurement accuracy of the system, a 10-minute continuous monitoring is carried out at the central wavelength of the laser, and the results show that the system accuracy is ± 9.12 × 10-5 nm. It is indicated that this work is of great significance for realizing high-precision atmospheric background and isotope gas measurement by cavity ring-down absorption spectroscopy technology in the future.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Yuqing LIN, Hua XIA, Zhirong ZHANG, Pengshuai SUN, Bian WU, Zhe LI, Yongjun CAI. Investigation of high‑precision real time wavelength monitoring method based on Fabry‑Perot etalon[J]. Chinese Journal of Quantum Electronics, 2025, 42(2): 187

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Mar. 15, 2023

    Accepted: --

    Published Online: Apr. 1, 2025

    The Author Email: Hua XIA (huaxia@aiofm.ac.cn), Zhirong ZHANG (zhangzr@aiofm.ac.cn)

    DOI:10.3969/j.issn.1007-5461.2025.02.004
