Optics and Precision Engineering, Volume. 33, Issue 10, 1534(2025)

Monitoring of blood temperature and acoustic impedance based on forward stimulated brillouin scattering in aluminum coated optical fibers

Shanglin HOU*, Hang SHAN, jie DONG, Gang WU, and Zuyong YAN
Author Affiliations
  • School of Science, Lanzhou University of Technology, Lanzhou730050, China
  • show less

    Based on the temperature and acoustic impedance sensing theory utilizing forward stimulated Brillouin scattering (FSBS) in aluminum-coated optical fibers, the influence of coating thickness on acoustic mode frequency and linewidth was investigated, simultaneous measurement of temperature and acoustic impedance was realized, and an innovative high-sensitivity method for disease detection in blood was proposed. The simulation results demonstrated linear relationships between the frequency/linewidth variations of radial acoustic modes R0,m with temperature and acoustic impedance. Fibers with different coating thicknesses exhibited distinct different sensitivities. The optimal linewidth-based acoustic impedance sensitivity is of 3.90 MHz/(kg·mm²·s) at 3 µm coating thickness and maximum frequency-based temperature sensitivity reaches up to 51.44 kHz/℃ at 5 µm coating thickness. Measurement errors can be reduced to 0.015 ℃ and 0.033 kg/(mm²·s) for 3 µm coating, and 0.008 ℃ and 0.027 kg/(mm²·s) for 5 µm coating, respectively. Taking ±0.5 μm coating thickness variation into account, the temperature and acoustic impedance tolerance vary within 0.003-0.020 ℃ and 0.021-0.032 kg/(mm²·s) for 3 µm coating, and 0.003-0.009 ℃ with 0.004-0.058 kg/(mm²·s) for 5 µm coating, respectively. This sensing system enables real-time monitoring of blood temperature and acoustic impedance, demonstrating potential applications in distinguishing normal physiological states from pathological conditions (e.g., hyperproteinemia, anemia) through multi-parameter analysis. The technology may provide innovative solutions for early disease diagnosis and precision medicine through its high-sensitivity detection capabilities.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Shanglin HOU, Hang SHAN, jie DONG, Gang WU, Zuyong YAN. Monitoring of blood temperature and acoustic impedance based on forward stimulated brillouin scattering in aluminum coated optical fibers[J]. Optics and Precision Engineering, 2025, 33(10): 1534

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Feb. 21, 2025

    Accepted: --

    Published Online: Jul. 23, 2025

    The Author Email: Shanglin HOU (houshanglin@vip.163.com)

    DOI:10.37188/OPE.20253310.1534
