Laser & Optoelectronics Progress, Volume. 61, Issue 9, 0922001(2024)

Three-Wavelength Wide-Range Fast Frequency Shift Based on Optical Phase-Locked Loop

Yanhui Zhao1, Min Yang2, Guangli Yu2,3, Jianyong Ding1,2, Weibiao Chen1,3、*, and Fangren Hu1、**
Author Affiliations
  • 1College of Electronic and Optical Engineering & College of Microelectronics, Nanjing University of Posts and Telecommunications, Nanjing 210046, Jiangsu, China
  • 2Advanced All Solid State Laser Technology R&D Center, Nanjing Institute of Advanced Laser Technology, Nanjing 210038, Jiangsu, China
  • 3Shanghai Institute of Optics and Fine Mechanics, Chinese Academy of Sciences, Shanghai 201800, China
  • show less

    Three-frequency ratio technology is important for sodium Doppler lidar to detect the temperature and wind field in the mesosphere. To realize this technology, three emitted lasers with 589 nm wavelength (f+, f0, f-) should be frequency stable, the frequency switching speed should be fast and the two frequencies (f+, f-) should be frequency locked to 630 MHz relative to the central frequency (f0). In order to meet the above technical requirements, a scheme based on optical phase-locked loop (OPLL) is proposed to realize three-frequency ratio technology. The OPLL is used to realize frequency offset locking. The frequency offset locking range is ± (200~2500) MHz, the minimum step is 200 kHz and the jitter of the beat signal is within ±50 Hz. By setting the frequency shift value and changing the polarity of the error signal, the wavelength of the slave laser is constantly changed, and the three-wavelength output is realized. The PID (proportional, integral, derivative) circuit is optimized to improve the stability of the beat signal, reduce the frequency switching time and the frequency cutting time is less than 10 ms. The experimental results show that the OPLL system can realize fast switching and locking of three frequencies and meet the technical requirements of three-frequency ratio technology.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Yanhui Zhao, Min Yang, Guangli Yu, Jianyong Ding, Weibiao Chen, Fangren Hu. Three-Wavelength Wide-Range Fast Frequency Shift Based on Optical Phase-Locked Loop[J]. Laser & Optoelectronics Progress, 2024, 61(9): 0922001

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Optical Design and Fabrication

    Received: Mar. 27, 2023

    Accepted: May. 19, 2023

    Published Online: May. 6, 2024

    The Author Email: Weibiao Chen (wbchen@mail.shcnc.ac.cn), Fangren Hu (hufr@njupt.edu.cn)

    DOI:10.3788/LOP230954

    CSTR:32186.14.LOP230954
