AEROSPACE SHANGHAI, Volume. 42, Issue 3, 61(2025)

Design and Analysis of Antennas with Multiple Hoop Truss Modules Grouped in Parallel

Ning XUE1, Xiaofeng CHEN2, Guang ZHENG3, Chuanzhi CHEN1、*, and Jinbao CHEN1
Author Affiliations
  • 1National Key Laboratory of Aerospace Mechanism,Nanjing University of Aeronautics and Astronautics,Nanjing211106,,China
  • 2Shanghai Aerospace Systems Engineering Institute,Shanghai201109,China
  • 3Key Laboratory of Impact and Safety Engineering,Ningbo University,Ningbo315211,,China
  • show less

    Ultralarge deployable antennas are one of the important directions for the future development of space payload mechanisms.However,the existing antenna configurations are difficult to simultaneously meet the requirements of both expandability and folding ratio.Therefore,a design scheme for deployable antennas with strong expansion,ultra-high folding ratio,and multiple hoop truss modules grouped in parallel is proposed.The kinematic performance is investigated,a modal analysis is carried out,and the folding performance is verified with the help of tests.First,a two-layer topology configuration design based on inverse generation and an improved Denavit-Hartenberg (D-H) method for partitioning are proposed to complete the antenna grouping and configuration design.Then,the topology analysis of the antenna and the analysis of the degrees of freedom of the unfolding process are carried out based on the screw theory and graph theory to verify the rationality of the design.Finally,based on the theoretical derivation and simulation,along with the prototype tests,the kinematics and folding characteristics of the antenna are investigated and verified.The results show that the proposed grouping method can meet the requirements of strong expansion and ultra-high folding ratio,and the designed space deployable mechanism has good deployable performance and kinematic characteristics.The research results provide a method for the design and theoretical analysis of deployable mechanisms for ultra-large deployable antennas.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Ning XUE, Xiaofeng CHEN, Guang ZHENG, Chuanzhi CHEN, Jinbao CHEN. Design and Analysis of Antennas with Multiple Hoop Truss Modules Grouped in Parallel[J]. AEROSPACE SHANGHAI, 2025, 42(3): 61

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Structures and Mechanisms

    Received: Nov. 4, 2024

    Accepted: --

    Published Online: Sep. 29, 2025

    The Author Email:

    DOI:10.19328/j.cnki.2096-8655.2025.03.008
