Journal of Atmospheric and Environmental Optics, Volume. 20, Issue 4, 423(2025)

Parametric analytical model of modulation transfer function in turbid atmosphere

GUO Mengxing1,2,3, WU Pengfei2,3、*, FAN Zizhao2,3,4, and RAO Ruizhong2,3
Author Affiliations
  • 1Institutes of Physical Science and Information Technology, Anhui University, Hefei 230601, China
  • 2Key Laboratory of Atmospheric Optics, Anhui Institute of Optics and Fine Mechanics, HFIPS,Chinese Academy of Sciences, Hefei 230031, China
  • 3Advanced Laser Technology Laboratory of Anhui Province, Hefei 230037, China
  • 4School of Environmental Science and Optoelectronic Technology, University of Science and Technology of China,Hefei 230022, China
  • show less

    Modulation transfer function (MTF) is an important indicator to evaluate the effect of turbid atmosphere on the imaging quality of objects. Based on the equivalence principle, this paper studies the quantitative relationship between MTF and key atmospheric optical parameters by using the discrete coordinate numerical solution method of radiative transfer and the linear fitting method, and establish the parametric analytical MTF model in turbid atmosphere. The results have revealed that in the range of optical thickness 0.1–1.0, single scattering albedo 0.1–1.0, and asymmetry factor 0.05–0.95: 1) As for the factors affecting the critical frequency, optical thickness is the largest, followed by scattering albedo, and asymmetry factor is the smallest. 2) In termes of factors affecting MTF, in the low spatial frequency range, the optical thickness is the largest, followed by the single scattering albedo, and the asymmetry factor is the smallest; while in the high spatial frequency range, the single scattering albedo is the largest, followed by the optical thickness, and the asymmetry factor is the smallest. 3) The overall average relative error of the established model is less than 8%, and for many practical application scenarios (asymmetric factor ≥ 0.7, single scattering albedo ≥ 0.55), the average relative error of the model is less than 5%.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Mengxing GUO, Pengfei WU, Zizhao FAN, Ruizhong RAO. Parametric analytical model of modulation transfer function in turbid atmosphere[J]. Journal of Atmospheric and Environmental Optics, 2025, 20(4): 423

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Oct. 20, 2022

    Accepted: --

    Published Online: Sep. 30, 2025

    The Author Email: Pengfei WU (wupengfei@aiofm.ac.cn)

    DOI:10.3969/j.issn.1673-6141.2025.04.001
