High Power Laser and Particle Beams, Volume. 37, Issue 2, 023005(2025)

Matching theory and PIC simulation for klystron output cavity with beam

Hu He... Lurong Lei and Shifeng Li |Show fewer author(s)
Author Affiliations
  • National Key Laboratory of Science and Technology on Advanced Laser and High Power Microwave, Institute of Applied Electronics, CAEP, Mianyang 621900, China
  • show less

    The matching theory based on an equivalent circuit model is outlined that self-consistently determines the modulation of a klystron output cavity for arbitrary coupling of the output waveguide to the cavity and arbitrary cavity and/or electron beam parameters. An equivalent circuit model including a mutual inductance and the induced current for the output cavity is established, the output power and the reflected power are discussed. For the cases where the complex coupling coefficient equals 1 and does not equal 1, we respectively determined expressions for the reflected power. We derived an expression for the output power corresponding to the gap voltage for the case when the coupling is perfectly matched to the output waveguide, and also for the case of arbitrary coupling. We worked out expressions for the resonant frequency of the output cavity and externally-loaded Q leading to the matching conditions. If the matching conditions are satisfied, the output power corresponding to the new theory equals approximately the output power corresponding to the traditional theory.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Hu He, Lurong Lei, Shifeng Li. Matching theory and PIC simulation for klystron output cavity with beam[J]. High Power Laser and Particle Beams, 2025, 37(2): 023005

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Jul. 11, 2024

    Accepted: Jan. 2, 2025

    Published Online: Mar. 25, 2025

    The Author Email:

    DOI:10.11884/HPLPB202537.240338
