Journal of Advanced Dielectrics, Volume. 15, Issue 4, 2540005(2025)

Structure, dielectric and piezoelectric characteristics of the modified by Bi2O3 and Mn2O3 oxides binary BiFeO3-BaTiO3 ceramics

E. S. Esin, N. A. Boldyrev*, E. I. Sitalo, L. A. Shilkina, A. V. Nazarenko, I. A. Shvetsov, and L. A. Reznichenko

Pure and superstoichiometric modified by 2wt.% Bi2O3 and 2wt.% manganese oxide (Mn2O3) ceramic samples of the binary system 0.71BiFeO3-0.29BaTiO3 were fabricated using conventional ceramic technology by double solid-phase synthesis with following sintering. Mechanical activation of synthesized powders was carried out at the stage of manufacturing press powders prepared for sintering. X-ray analysis at room temperature showed that all studied ceramics have pseudo-cubic symmetry. Grain morphology, dielectric and piezoelectric properties of selected solid solutions were investigated. The modification increased the homogeneity of the material, dielectric constant and piezomodulus d33 and also resulted in a decrease in the dielectric loss tangent. The highest piezoelectric coefficient d33=105 pC/N was obtained. Dielectric characteristics of ceramics revealed ferroelectric relaxor behavior and region of diffuse phase transition from the paraelectric to ferroelectric phase in the temperature range of 740–770K.

Tools

Get Citation

Copy Citation Text

E. S. Esin, N. A. Boldyrev, E. I. Sitalo, L. A. Shilkina, A. V. Nazarenko, I. A. Shvetsov, L. A. Reznichenko. Structure, dielectric and piezoelectric characteristics of the modified by Bi2O3 and Mn2O3 oxides binary BiFeO3-BaTiO3 ceramics[J]. Journal of Advanced Dielectrics, 2025, 15(4): 2540005

Download Citation

EndNote(RIS)BibTexPlain Text
Save article for my favorites
Paper Information

Category: Research Articles

Received: Nov. 16, 2024

Accepted: Feb. 16, 2025

Published Online: Aug. 5, 2025

The Author Email: N. A. Boldyrev (nboldyrev@sfedu.ru)

DOI:10.1142/S2010135X25400053
