Acta Optica Sinica, Volume. 45, Issue 14, 1420014(2025)

Computer Imaging Based on Optical Diffractive Neural Network (Invited)

Chuang Yang1,2, Nanxing Chen1,2,3、**, Shengjie He1,2, Zhongjun Li1,2, Haoliang Liu1,2, Limin Jin1,2, Kairui Cao3, Can Huang1,2, and Jingtian Hu1,2、*
Author Affiliations
  • 1Ministry of Industry and Information Technology Key Laboratory of Micro-Nano Optoelectronic Information System, Harbin Institute of Technology (Shenzhen), Shenzhen 518055, Guangdong , China
  • 2Guangdong Provincial Key Laboratory of Semiconductor Optoelectronic Materials and Intelligent Photonic Systems, Harbin Institute of Technology (Shenzhen), Shenzhen 518055, Guangdong , China
  • 3National Key Laboratory of Laser Spatial Information, School of Astronautics, Harbin Institute of Technology, Harbin 150001, Heilongjiang , China
  • show less

    Significance

    The recent surge in data-intensive applications and increasing demands for improved latency and energy efficiency have led to the reemergence of optical computing as a vital complement to traditional electronic processors. Diffractive deep neural networks (D2NNs) represent the cutting edge of this renaissance, utilizing light propagation physics through engineered diffractive layers to perform complex computations in the photonic domain. As an inherently parallel, high-bandwidth, and energy-efficient platform, D2NNs facilitate tasks including lensless imaging, compressive sensing, and phase retrieval at speeds surpassing current GPUs and ASICs. These networks optimize learnable phase and amplitude masks across multiple diffractive planes through end-to-end, gradient-based training, incorporating task-specific priors directly into the hardware architecture, thereby enhancing resilience against noise and optical aberrations. The significance of D2NN-based computational imaging (CI) stems from its ability to transfer computational burden from electronic systems to passive photonic structures and its potential to enable novel imaging applications in biomedical diagnostics, remote sensing, and industrial inspection. With advancing fabrication techniques in metasurfaces and nano-printing, D2NNs are positioned to become fundamental to next-generation intelligent photonic systems that integrate sensing, computation, and decision-making processes at light speed.

    CI systems based on D2NN technology incorporate high-dimensional matrix operations and feature extraction directly into light propagation processes. The system architecture consists of cascaded diffractive layers, each implemented as a learnable phase mask that modulates the incident wavefront according to established diffraction models. Through comprehensive simulation-based training, the optimized phase configuration enables various imaging capabilities during light transmission, including holographic display, phase imaging, and super-resolution imaging. This integrated approach achieves processing speeds at the picosecond scale while maintaining power consumption at the microwatt level.

    Progress

    The structure and operational principles of optical diffraction neural networks are initially presented in Fig. 1, encompassing (1) the fundamental D2NN architecture, (2) the modulation principle achieved through diffractive optical elements, and (3) the modulation process implemented via metasurfaces. D2NN comprises multiple cascaded, grid-patterned diffractive layers: phase control is attained by modifying each pixel’s transmittance in the diffractive elements, while metasurfaces enable more sophisticated manipulation of the optical field, including its polarization, amplitude, and phase. Figure 2 presents a comparative analysis of two optical paths: one for computational holographic wavefront reconstruction using spatial light modulators, and another for optical information detection based on a D2NN. In Fig. 3, the relationship between the holographic display process and D2NN is examined, addressing speckle and noise suppression in holographic reconstructions and the elimination of artifacts from holograms. Figure 4 illustrates network-structure enhancements of D2NN for holographic display, including Res-D2NN with residual skip-connections, multi-view D2NN arrays, and pyramid-shaped D2NN. Phase-imaging investigations appear in Fig. 5 and Fig. 6: Fig. 5 describes a diffractive phase imager, a multispectral phase imager, and a 3D multi-plane wavelength-multiplexed phase imager; Fig. 6 presents a hybrid multiplexing design for all-optical complex-amplitude imaging and an all-optical phase imaging scheme through random scattering media. Super-resolution imaging via D2NN is explained in Fig. 7, including a solid-immersion subwavelength amplitude and phase imager and the 3D optimized optical-field principle of an optical super-oscillation D2NN. Figures 8 and 9 address all-optical scattering objects and single-pixel imaging, respectively: Fig. 8 elaborates on all-optical scattering imaging, a highly robust “vaccination” training-strategy network, a hybrid information-transmission system combining electronic encoding with diffractive decoding, and fiber-integrated D2NN; Fig. 9 includes task-specific image reconstruction, all-optical object hiding and defect detection, and broadband single-pixel diffraction networks. Finally, the review examines the field’s outstanding challenges and current research directions, including the absence of strong optical nonlinearities, challenges in adapting to dynamic scenes, and discrepancies between simulated physics and real-world propagation.

    Conclusions and Prospects

    D2NN has emerged as an increasingly significant tool for computational imaging. In summary, comprehensive and detailed research remains necessary to advance holographic display, phase imaging, super-resolution imaging, scattering imaging, and single-pixel imaging with D2NN, to facilitate the academic and engineering development of this imaging paradigm.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Chuang Yang, Nanxing Chen, Shengjie He, Zhongjun Li, Haoliang Liu, Limin Jin, Kairui Cao, Can Huang, Jingtian Hu. Computer Imaging Based on Optical Diffractive Neural Network (Invited)[J]. Acta Optica Sinica, 2025, 45(14): 1420014

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Optics in Computing

    Received: Apr. 16, 2025

    Accepted: May. 27, 2025

    Published Online: Jul. 14, 2025

    The Author Email: Nanxing Chen (chennanxing_hit@163.com), Jingtian Hu (hujingtian@hit.edu.cn)

    DOI:10.3788/AOS250936

    CSTR:32393.14.AOS250936
