Chinese Optics, Volume. 17, Issue 5, 1183(2024)

An MTF calculation model under the influence of ghost images

Peng-yi XIAO1,2, Ming-xin LIU1、*, Lei YAN1, Ming-yu HU1, and Xin ZHANG1
Author Affiliations
  • 1Changchun Institute of Optics, Fine Mechanics and Physics, Chinese Academy of Sciences, Changchun 130033, China
  • 2University of Chinese Academy of Sciences, Beijing 100049, China
  • show less

    To investigate the impact of ghost images on optical system performance, we develope a Modulation Transfer Function (MTF) calculation model under the influence of ghost images generated by secondary reflection. We first introduce the analyzing and describing method of ghost image using the paraxial approximation. Then, starting from the definition of the MTF, and considering the influence of ghost image irradiance on the modulation of the image plane, an MTF calculation model under the influence of ghost images is constructed. By conducting a case study calculation on a system and comparing it with the simulation results, it is found that the maximum mean square error is less than 0.049373, which verifies the accuracy of the model. Furthermore, a detailed analysis is conducted, examining cases that exhibited larger errors and clarifying the range in which this calculation method can be applied. The research results indicate that the paraxial approximation method is both accurate and reliable when calculating the MTF under the influence of ghost images is accurate, and is applicable in most cases. This study serves as a valuable exploration in the ghost image analysis of optical systems.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Peng-yi XIAO, Ming-xin LIU, Lei YAN, Ming-yu HU, Xin ZHANG. An MTF calculation model under the influence of ghost images[J]. Chinese Optics, 2024, 17(5): 1183

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Jul. 21, 2023

    Accepted: --

    Published Online: Dec. 31, 2024

    The Author Email:

    DOI:10.37188/CO.2023-0121
