Optics and Precision Engineering, Volume. 33, Issue 2, 194(2025)

Adjustable optical path cylindrical multi-pass cell TDLAS system

Taohua LI, Mingsheng NIU*, Yongpeng SHI, Hui LI, Huiyuan LIU, Le YANG, Haotian YUAN, and Hongfu FANG
Author Affiliations
  • School of Physical and Physical Engineering, Qufu Normal University, Qufu273165, China
  • show less

    In order to improve the detection performance and integration of TDLAS detection system, A TDLAS system based on a portable adjustable optical path length cylindrical mirror multi-pass cell was designed, which achieved the simulated optical path length of 14 m, 10.6 m, 9.2 m, 7.1 m and 5.8 m. To reduce the impact of noise generated during gas measurement in TDLAS system on detection accuracy and sensitivity, the Variational Mode Decomposition (VMD) wavelet denoising algorithm optimized by the Northern Goshawk Optimization (NGO) was proposed. The simulation results showed that compared with other algorithms, the NGO-VMD wavelet denoising algorithm could effectively reduce noise without causing signal distortion. The performance of the system was evaluated by testing CH4 using a DFB laser with the central wavelength of 1.653 μm based on direct absorption detection technology. The results showed that the signal-to-noise ratio of the detection signal was increased from 66 to 109, and the lower detection limit of the system was improved from 12.1 ppm to 7.28 ppm. Allan analysis of variance showed that the optimal detection sensitivity of the system was improved from 641 ppb to 526 ppb at the integration time of 263 s after optimization with the NGO-VMD wavelet algorithm. The finding provided a reference for improving the performance of TDLAS trace gas detection system.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Taohua LI, Mingsheng NIU, Yongpeng SHI, Hui LI, Huiyuan LIU, Le YANG, Haotian YUAN, Hongfu FANG. Adjustable optical path cylindrical multi-pass cell TDLAS system[J]. Optics and Precision Engineering, 2025, 33(2): 194

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Nov. 6, 2024

    Accepted: --

    Published Online: Apr. 30, 2025

    The Author Email: Mingsheng NIU (qsdmsniu@qfnu.edu.cn)

    DOI:10.37188/OPE.20253302.0194
