Optical Instruments, Volume. 47, Issue 3, 76(2025)

Effect of laser parameters and photoacoustic materials on ultrasonic signals

Feng XIE*, Youjun YU, Yi KANG, and Dawei ZHANG*
Author Affiliations
  • School of Optical-Electrical and Computer Engineering, University of Shanghai for Science and Technology,Shanghai 200093, China
  • show less

    Photoinduced ultrasound is widely used in medical diagnosis, material characterization, nondestructive testing, structural health monitoring and other fields. These applications have specific requirements on ultrasonic intensity and bandwidth. This paper quantitatively analyzed the effects of photoacoustic materials and laser parameters on ultrasonic frequency and intensity. The following conclusions are drawn by relevant experiments. With the increase of the incident laser energy, the amplitude corresponding to all frequencies in the ultrasonic spectrum increases, and the incident laser energy is proportional to the amplitude of the ultrasound. Meanwhihle, the ultrasonic intensity increases by 15% with increase of 50 mJ laser energy. The change of incident laser frequency has no effect on ultrasonic signal. The increase of gold nanoparticle concentration can not only enhance the amplitude of ultrasound, but also increase the frequency of ultrasound. The thin layer of gold nanoparticles and polydimethylsiloxane leads to insufficient absorption of light energy, and the thick layer causes the attenuation of the high frequency component of ultrasound. The mixture of carbon black and polydimethylsiloxane produces higher intensity ultrasound than the mixture of gold nanoparticles and polydimethylsiloxane under the same circumstances, but the frequency distribution is concentrated in the low frequency domain.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Feng XIE, Youjun YU, Yi KANG, Dawei ZHANG. Effect of laser parameters and photoacoustic materials on ultrasonic signals[J]. Optical Instruments, 2025, 47(3): 76

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Received: Feb. 28, 2024

    Accepted: --

    Published Online: Jul. 28, 2025

    The Author Email: Feng XIE (155651727269@qq.com), Dawei ZHANG (dwzhang@usst.edu.cn)

    DOI:10.3969/j.issn.1005-5630.202402280027
