High Power Laser and Particle Beams, Volume. 37, Issue 3, 035005(2025)

Compact Marx generator-based pulse power source

Hanpeng Hu1, Dening Yin2, Nan He2, Yaqi Huang3, Zhenming Zhang1, Xiulu Zhang1、*, Shengyi Song4, and Changying Yuan1
Author Affiliations
  • 1School of Nuclear Science and Technology, Southwest University of Science and Technology, Mianyang 621010, China
  • 2Sichuan Zhongwu Technology Co., Ltd, Mianyang 621000, China
  • 3School of Mathematics and Physics, Southwest University of Science and Technology, Mianyang 621010, China
  • 4Key Laboratory of Pulsed Power, Institute of Fluid Physics, CAEP, Mianyang 621900, China
  • show less

    To reduce the threshold of using pulse power source, a compact pulse power source based on Marx generator is designed and implemented. The Marx generator is a 7-stage unipolar charging coaxial structure with low inductance ceramic capacitor and ultraviolet preionization output narrow pulse. It uses adjustable primary high voltage power supply and 2-way synchronous trigger switch, and metal shell as grounding shield and discharge circuit; it is filled with high pressure N2. Using the power source based on the above design, when the charging voltage is 26 kV and the charging voltage is 0.3 MPa, the high voltage pulse of 33 ns rise time, 59 ns pulse width and 109.2 kV amplitude is obtained on the 60 Ω load. The power source is housed in an aluminum alloy cylinder with a diameter of 0.2 m and a length of 1.1m. This paper provides a design idea and a reference prototype for compact and modular pulse power source, which can be used as flash X-ray radiography drive source.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Hanpeng Hu, Dening Yin, Nan He, Yaqi Huang, Zhenming Zhang, Xiulu Zhang, Shengyi Song, Changying Yuan. Compact Marx generator-based pulse power source[J]. High Power Laser and Particle Beams, 2025, 37(3): 035005

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Aug. 11, 2024

    Accepted: Nov. 9, 2024

    Published Online: Apr. 29, 2025

    The Author Email: Xiulu Zhang (zhangxiulu@swust.edu.cn)

    DOI:10.11884/HPLPB202537.240254
