Optics and Precision Engineering, Volume. 33, Issue 6, 895(2025)

Performance simulation and wavefront measurement of telescope at cryogenic temperature

Junru SONG*, Weiming TONG, Zhongrui JIN, Dongke HE, Zhiyuan LIU, and Yue MA
Author Affiliations
  • Beijing Institute of Space Mechanics & Electricity, Beijing100094, China
  • show less

    Cryogenic space telescope is applied in 90K cryogenic environment, but developed in a laboratory environment at room temperature and pressure. The huge differences in application and development environments result in two different sets of parameters of optical components. A telescope with good image quality at cryogenic temperature is actually a system with large aberration in laboratory environment. In order to quantitatively evaluate the imaging quality of a cryogenic telescope, a structural thermos optical performance simulation was conducted,and a testing method for wavefront error of the telescope in a 90 K cryogenic environment was designed. Firstly, the working temperature of the telescope at 90 K is achieved through the dual cooling of liquid nitrogen cold shroud radiation and refrigeration machine in the vacuum chamber. The wavefront measurement of the telescope is achieved through the interference measurement of parallel light tube beam expansion. Secondly, the error sources of the testing system were analyzed and calibrated to correct the test results. Finally, the consistency between the measured cryogenic wavefront values and the model simulation of the telescope was compared and analyzed, as well as the manifestation of wavefront errors and the corresponding mapping relationship of structural design. The experimental results show that the design simulation of the telescope is accurate, the 90 K low-temperature wavefront testing method is reasonable and feasible, the simulation accuracy is better than 20 nm,and the wavefront testing accuracy is better than 9 nm. The test results can be used for the design improvement of the optical mechanical system of the space telescope.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Junru SONG, Weiming TONG, Zhongrui JIN, Dongke HE, Zhiyuan LIU, Yue MA. Performance simulation and wavefront measurement of telescope at cryogenic temperature[J]. Optics and Precision Engineering, 2025, 33(6): 895

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Oct. 8, 2024

    Accepted: --

    Published Online: Jun. 16, 2025

    The Author Email: Junru SONG (sjr1987bit@163.com)

    DOI:10.37188/OPE.20253306.0895
