All light that enters a gravitational singularity known as a black hole will never escape, whereas all light that tries to enter a white hole is rejected (Fig. 1). The fascinating electromagnetic properties of these objects have motivated the study of systems exhibiting similar characteristics from fluid dynamics,1 acoustics,2 and Bose–Einstein condensates3 to linear4^,5 and nonlinear6^–9 optics. In particular, the previously proposed linear optical black holes have relied on metamaterials to imitate curved space–time with a complex refractive index profile.4^,5

Here, we introduce the concept and provide a proof-of-principle demonstration of an “optical black and white hole” that deterministically absorbs all light of one linear polarization while rejecting all light of the orthogonal polarization. It relies on coherent perfect absorption10 enabled by spatial coherence and interference; and has a simple geometry that can be implemented using available materials.

Although the effects of interference on absorption of a single beam of light have been studied for a long time,11^–15 only since 2012 it has become well known that interference of two coherent light beams on a thin absorber can eliminate the Joule losses of optical energy or, by contrast, can lead to total, deterministic absorption of light.10^,16^,17

Consider a thin light-absorbing film of subwavelength thickness. The result of interference of two temporally coherent counterpropagating incident beams of the same intensity on such a film is illustrated by two opposite cases. In the first, a standing wave is formed with zero electric field, a node arising from destructive interference, at the position of the absorbing film. As the film is much thinner than the optical wavelength, its electric–dipole interaction with the electromagnetic field is negligible and the absorber will appear to be transparent for both incident waves. (The amplitude of the magnetic field is at a maximum here, but magnetic dipole transitions may be neglected in this simplified picture as they are typically much less efficient than electric dipole transitions.) In the second case, the film is at a position of constructive interference, an electric field maximum (antinode), where the electric–dipole interaction is strong and the associated absorption becomes very efficient.

Irrespective of the mechanism of absorption, an analysis of such interference16 shows that perfect deterministic transmission and absorption of light can be achieved in a thin (relative to the wavelength) absorber if, for traveling-wave illumination, its reflectivity from either side is one-quarter, and one-half of optical power is absorbed in the film. For fundamental reasons, an infinitesimally thin film cannot absorb more than half of the energy from a traveling wave,18^,19 and a very close approximation of this limit is possible with natural materials (e.g., multilayered graphene20 or thin metal layers21^–23) or/and metamaterial structuring of films of nanoscale thicknesses.10^,24 If coherent waves of equal amplitude incident on both sides of such an absorber interfere constructively (or destructively) at the absorber, as described in the previous paragraph, then reflected and transmitted waves on either side of the absorber will have equal amplitude and a π (or 0) phase difference, resulting in complete cancellation (or constructive interference) of all outgoing fields and thus complete absorption (or transmission) of all incident light. In a bigger picture that includes the thermal radiation of the film, the Landsberg thermodynamic limit25 caps the efficiency of radiative energy utilization at a value slightly lower than 100%.

The regime of nearly perfect absorption in a standing wave has been experimentally demonstrated with classical light,10 single26 and entangled photons,27 and has been used in applications such as all-optical light modulation with ultrafast optical pulses,28 single-photon optical switching,29 data processing in classical30 and quantum31 networks, as well as image recognition.32

So far, we discussed perfect absorptivity and transmissivity arrangements involving two coherent counterpropagating beams. The interference required for perfect broadband absorption and transmission can be constructed by splitting an incident beam of light into two coherent beams using a beam splitter and directing these two beams to opposite sides of the absorber. However, this is not possible without a complex and bulky arrangement of multiple mirrors, making such absorbers impractical.

The main purpose of the present work is to demonstrate that interference on a thin absorber can lead to nearly perfect absorption of thermal or laser light from a broadband source utilizing its spatial coherence, i.e., uniformity of the phase of the wavefront. Spatial coherence is a characteristic feature of single-mode laser light but is also a feature of remote sources. Indeed, all waves are spatially coherent on sufficiently small-length scales.33 For instance, light with wavelength λ=500nm that comes from the closest star outside the solar system, Proxima Centauri (star diameter δ=214,550km), located at a distance D=4.25 light-years from Earth is spatially coherent across a wavefront diameter of d=0.16λD/δ=15m. Light from a similar star located within the Andromeda Galaxy, the closest major galaxy, at a distance of 2.54 million light-years, is spatially coherent across a wavefront diameter of 9000 km (e.g., the distance between the UK and Japan).

For the conceptual design that we propose in this work, consider two mirrors set at a right angle to each other and a thin absorber placed along the bisector plane separating them (Fig. 2). If the arrangement is narrower than the spatial coherence area of the incident radiation, light rays directed by the mirrors onto opposite sides of the same absorber area from nonoverlapping parts of the incident beam will be coherent and therefore interfere.

The type of interference is determined by the polarization of light. In the case of light that is linearly polarized in the plane of the absorber (perpendicular to the plane of incidence, i.e., s-polarization), the polarization state and relative phase of the waves propagating toward either side of the absorber do not change upon reflection: beams arriving on the opposite sides of the absorber are in phase and they interfere constructively [Fig. 2(a)]. Hence, this arrangement enables total absorption of any spectral component of the incident light: perfect broadband absorption.

However, if the incident light is polarized perpendicular to the plane of the absorber (parallel to the plane of incidence, i.e., p-polarization), upon reflection the electric-field vector rotates +90deg on one of the mirrors and −90deg on the other [Fig. 2(b)]. These polarization changes may be represented as trajectories between antipodal points on the Poincaré sphere, in opposite directions along its equator. With a sign depending on the direction of polarization rotation, the geometrical Pancharatnam–Berry phases34 before and after reflection differ by an amount equal to half of the solid angle encompassed by their trajectory on the Poincaré sphere. Accordingly, the beams accrue a geometric phase difference of π upon reflection and interfere destructively at the absorber, resulting in electric-field cancellation and thus negligible absorption: a perfect arrangement for total transmission. Due to the geometric nature of the phase difference, the effect does not depend on the wavelength. Therefore, an incident light beam polarized perpendicular to the plane of the absorber will suffer no absorption for any spectral component, resulting in the reflection of all light by the device.

The optical black and white hole device studied here consists of two identical 90-deg prisms manufactured from BK7 glass (Precision Optical Inc.) and polished to 80-nm surface flatness. The height of the prisms is 15 mm, whereas their legs are 21.3-mm wide. A 20-nm layer of chromium was deposited on a leg of one prism by thermal evaporation before the device was assembled by placing the chromium-coated prism face in contact with the uncoated prism, as shown in Fig. 1, with glass index-matching liquid covering the contact area to avoid any air gap, i.e., to ensure that the refractive index is the same on either side of the chromium film. For this proof-of-principle demonstration, the mirror reflections within the device occur by total internal reflection at the glass–air interfaces of the prism hypotenuses; we chose chromium as the absorber material, as it provides close to the desired absorption and reflection characteristics in a film of deep subwavelength thickness in the near-infrared part of the spectrum where the proof-of-principle demonstration is performed (S1.1, S1.2, and Fig. S6 in the Supplementary Material).

As illustrated by Fig. S7 in the Supplementary Material, the experiments were performed with the output of a continuous wave C + L band tunable laser (HP 8168F) with a spectral width of 100 kHz, which was collimated by a fiber collimator and directed toward the device such that the incident laser beam was centered on the boundary between the prisms. Reflected light then passed through an analyzer that selected one of the eigenpolarizations (s or p-polarization with the electric field parallel or perpendicular to the absorbing film) before being detected by an optical power meter. We measured the power r of the reflected light as a fraction of the incident optical power r0 to determine the reflectivity of the device, RM=r/r0.

A small, fixed angle of incidence of β≈2deg within the plane of the chromium film and a ∼1-mm slit were used to separate incident and reflected light, which had a Gaussian distribution with 1/e2 diameter of ∼7mm in the plane perpendicular to the chromium film (Fig. S7 in the Supplementary Material). This spaces multiple reflections by more than the slit width, avoiding any additional interference or Fabry–Perot-cavity effects, allowing us to remove reflections from the glass–air interface analytically. To show the performance of antireflection–coated prisms, the 4% reflectivity of the glass–air interface has been removed from the measured reflectivity RM, by calculating the reflectivity with an antireflection coating on the input face as R=1/(0.962RM−0.04+0.04). The absorptivity A is given by A=1−R. The optical paths were matched by translating one prism relative to the other using a piezo stage and optimizing the bandwidth of absorption for s-polarization, which also compensates for any slight size differences between the prisms of nominally identical size.

We investigated the dependence of reflectivity and absorptivity as functions of α (Fig. 3)—the beam’s angle of incidence on the device—and laser wavelength λ (Fig. 4).

Figure 3 shows the measured reflectivity and absorptivity at a wavelength of 1570 nm as a function of the angle of incidence for two incident polarizations (s and p) parallel and perpendicular to the plane of the absorbing film. At oblique incidence, a similar absorptivity of around 60% (∼40% reflectivity) of the incident power is observed for both polarizations. However, as the angle of incidence approaches 0 deg, the absorptivity changes dramatically, approaching complete absorption (negligible rejection) for s-polarization and decreasing toward minimal absorption (increasing toward complete rejection) for p-polarization. Arguably, the rapid angular transition to black-hole-like absorption of s-polarized light and white-hole-like rejection of p-polarized light at normal incidence may be thought of as an event horizon.

Figure 4 shows the spectral dependence of the optical black and white hole responses. The observed reflectivity and absorptivity are spectrally flat across the tuning range of the laser, indicating that it is broadband. For the optical black hole case, we observe 91% absorption; however, we observed 85% reflectivity for the optical white hole case. Simulations illustrate traveling-wave propagation toward the device for the black hole case [Fig. 4(a)], where negligible interference above the prisms indicates the near-complete absence of reflected light. By contrast, for the white hole case [Fig. 4(b)], almost all light is rejected by the device, resulting in almost equal amplitudes of light propagating toward and away from the prisms and thus the formation of a standing wave. The simulations in Figs. 4(a) and 4(b) were carried out in COMSOL Multiphysics for s- and p-polarized coherent plane wave illumination (λ=1570nm, from the upper boundary) of aligned prisms with a leg length L=14μm and refractive index 1.5, with a 320-nm-thick antireflecting coating having a refractive index of 1.225 on the input face and with a 20-nm-thick absorber with a refractive index of 4.6+4.4i. Lateral outer boundaries above the prisms are periodic, and a scattering condition was used for all other outer boundaries. (Light scattering from the prism tip becomes insignificant at macroscopic prism sizes and can also be avoided by adding a reflective coating; see S1.4 and Fig. S5 in the Supplementary Material.)

We note that the ultimately broadband optical black hole and white hole responses for s- and p-polarizations that occur for perfectly aligned identical prisms, can be reversed (over a large but finite bandwidth) by introducing a relative displacement Δz=λ0/2 between the prisms, where λ0 is the free-space wavelength and z is the direction of normal incidence (S1.3 in the Supplementary Material). The measurements in Fig. 4 illustrate this: they show s-polarization with Δz≈0 (black hole case) and Δz≈800nm (white hole case). The tuning range of our laser is not large enough to distinguish between ideal and approximate black/white hole configurations.

Although an ideal optical black and white hole is expected to deliver deterministic absorption and rejection of light, less than 100% absorptivity and reflectivity was observed in our proof-of-principle experiments. Causes of the finite absorptivity and reflectivity include diffraction at edges and flatness of faces of the prisms, as well as wavefront distortions arising from imperfect illumination optics. Calculations show that various real absorber materials can deliver very close to deterministic absorption and deterministic rejection of light over multiple octaves of the electromagnetic spectrum (S1.2 in the Supplementary Material).

The acceptance angle within which near-complete absorption or rejection of light occurs as well as angular alignment tolerances is controlled by the size of the prisms and becomes large as the prism size L approaches the wavelength λ (S1.4 and Fig. S5 in the Supplementary Material). Arrays of microprism devices would offer large overall apertures and large acceptance angles, e.g., for light-harvesting applications, as well as large angular alignment tolerances. Translational alignment errors need to be small compared with the wavelengths of interest (S1.3 in the Supplementary Material), implying that larger translational errors relative to the prism size can be tolerated for smaller prisms and longer wavelengths.

In essence, ultimately broadband, complete absorption and rejection of light is a wave interference phenomenon enabled by a layer of substantial subwavelength thickness with suitable traveling-wave absorption and reflection characteristics. It follows that conceptionally similar black hole wave absorbers and/or white hole wave rejectors may be implemented for all sorts of waves. Indeed, coherent perfect absorption has been reported for electromagnetic waves from microwaves to optical frequencies10^–17 as well as for sound waves.35^–37 Although such works have demonstrated great potential, reliance on complex multicomponent interferometers has stood in the way of practical device implementations. By showing how spatial coherence can be exploited to achieve deterministic wave-matter interaction—or its deterministic absence—in simple, compact, monolithic, and broadband devices, the concept reported here indicates how the large body of work on thin-film coherent perfect absorption can be translated robustly into practical applications.

In summary, we have demonstrated how spatial coherence enables broadband deterministic absorption and rejection of light of orthogonal polarizations by simple and compact devices. We describe these as optical black and white holes, as the concept allows for complete absorption and rejection, in principle with unlimited bandwidth, characteristics shared with the black and white holes of general relativity. In practice, a very large bandwidth can be obtained, with limitations arising from the device size (Fig. S5 in the Supplementary Material) and material dispersion (S1.2 in the Supplementary Material). Our device implementation shows how the large body of work on coherent perfect absorption can be translated into practical devices, such as broadband energy harvesters, polarizers, perfect absorbers (e.g., for stealth technologies), and detectors. The latter could offer high quantum efficiency, directional selectivity, and sensitivity to spatial coherence and polarization. Arising from wave physics, the concept is also applicable to waves outside of electromagnetism, with implications from photonics to acoustics and beyond.
