Acta Optica Sinica, Volume. 44, Issue 12, 1201002(2024)

Accurate Acquisition of Initial Fluorescence in Phytoplankton Primary Productivity Measurement by Fluorescence Dynamics Method

Ming Dong1,2, Gaofang Yin1,2、*, Nanjing Zhao1,2、**, Xiang Wang3, Xiaoling Zhang4, Mingjun Ma2, Tianhong Liang2, Renqing Jia2, Min Xu2, Xiang Hu2, and Peng Huang2
Author Affiliations
  • 1School of Environment Science and Optoelectronic Technology, University of Science and Technology of China, Hefei 230026, Anhui , China
  • 2Key Laboratory of Environmental Optics and Technology, Anhui Institute of Optics and Fine Mechanics, Chinese Academy of Sciences, Hefei 230031, Anhui , China
  • 3School of Electrical Engineering, Anhui Polytechnic University, Wuhu 241200, Anhui , China
  • 4Institutes of Physical Science and Information Technology, Information Materials and Intelligent Sensing Laboratory of Anhui Province, Anhui University, Hefei 230601, Anhui , China
  • show less

    Objective

    After illumination, the electron transport chain of dark-adapted phytoplankton is inhibited to bring about the gradual closure of the reaction center. Light energy absorbed by the light-harvesting pigment is released solely by fluorescence or thermal dissipation to elevate fluorescence yield. This increase initiates the chlorophyll fluorescence induction process. In the early stage of chlorophyll fluorescence induction, the photochemical reaction has not yet commenced, and the photosynthetic reaction center remains fully accessible. This stage is termed the initial fluorescence phase, and it is measured by light sources with varying wavelengths within the visible light spectrum. These measurements provide vital photosynthetic insights, including pigment content, reaction center concentration, energy absorption, and excitation energy transfer. They precisely depict the structure and composition of light-harvesting pigments in phytoplankton, along with energy absorption efficiency. Consequently, this technique critically contributes to analyzing the photosynthetic status and primary productivity of live phytoplankton. Following the revelation of chlorophyll fluorescence induction, multiple techniques for measuring initial fluorescence have emerged. For example, Schreiber et al. introduced the technique of pulse amplitude modulation (PAM) for measuring photoinduced fluorescence kinetics, Kolber et al. suggested the fast repetition rate fluorescence (FRRF) measurement technique, and Strasser et al. developed the OJIP technique for rapidly measuring chlorophyll fluorescence-induced kinetic curves by continuous excitation luminescence. Currently, research on the technical approaches predominantly centers on characteristic absorption bands. Nevertheless, the sensitivity of non-characteristic absorption bands remains limited, hindering the accurate portrayal of the structural composition of light-harvesting pigments and energy absorption efficiency. Therefore, the development of a profoundly sensitive method for initial fluorescence measurement is pivotal in advancing the investigations of phytoplankton primary productivity.

    Methods

    We employ the photosynthetic electron transport model and the OJIP fluorescence kinetics measurement technology to regulate the redox state of electron receptors proximate to the O phase, thereby attaining optimal excitation conditions. Under weak light excitation, LHCII absorbs energy at a low level, and the excitation energy is transferred to the reaction center. The electron acceptor can receive and promptly re-oxidize electrons to establish a rapid dynamic equilibrium, which leads to a consistent initial fluorescence signal. Due to the weak nature of the initial fluorescence signal, integrating and amplifying signals across various bands within the microsecond range enable the attainment of highly sensitive detection (50-150 μs) of initial fluorescence. Thus, precise acquisition technology for initial fluorescence is indispensable for investigating the primary productivity of phytoplankton by fluorescence dynamics. Validation of the initial fluorescence measurement results involves comparing the PSII absorption coefficient and initial fluorescence similarity.

    Results and Discussions

    The findings from the initial fluorescence measurements indicate strong correspondence between the measurements of photosynthetic pigment absorption in phytoplankton and actual absorption patterns. For example, Microcystis aeruginosa exhibits a PE absorption peak at 569 nm and a PC absorption peak at 620 nm, and freshwater green algae show an absorption peak of Chl a at 439 nm and a Car absorption peak at 474 nm (Fig. 3). Moreover, compared to the reference sample, the verification results indicate the proficient representation of PSII absorption by the initial fluorescence, thereby confirming a substantial degree of measurement accuracy. The PSII fluorescence yield closely mirrors the initial fluorescence profile, exhibiting similarity values of 0.996 for Microcystis aeruginosa, 0.999 for Scenedesmus dimorphus, 0.999 for Scenedesmus obliquus, 0.999 for Chlorella ellipsoidea, 0.998 for Oocystis lacustris, and surpassing 0.998 for all four species of freshwater green algae (Fig. 4).

    Conclusions

    We address the constraints of existing initial fluorescence measurement methodologies, which predominantly concentrate on characteristic absorption bands to reduce sensitivity for absorption bands lacking distinct characteristics. As a result, these techniques inadequately represent the energy absorption efficiency of photosynthetic organs in algae. To this end, we propose a precise technology for acquiring initial fluorescence and facilitating primary productivity measurement in phytoplankton by fluorescence dynamics. This approach integrates the photosynthetic electron transfer model with the measurement principles of OJIP fluorescence dynamics technology. The results of the initial fluorescence measurements demonstrate significant correspondence between the measurements of photosynthetic pigment absorption in phytoplankton and actual absorption patterns. For example, Microcystis aeruginosa exhibits a PE absorption peak at 569 nm and a PC absorption peak at 620 nm, and freshwater green algae show an absorption peak of Chla at 439 nm and a Car absorption peak at 474 nm. Furthermore, the comparative verification results indicate a close similarity between the shapes of the PSII fluorescence yield and the initial fluorescence, affirming the capacity of the initial fluorescence to precisely mirror PSII absorption. The similarity values are noteworthy, with 0.996 for Microcystis aeruginosa, 0.999 for Scenedesmus dimorphus, 0.999 for Scenedesmus obliquus, 0.999 for Chlorella ellipsoidea, 0.998 for Oocystis lacustris. Additionally, all the four species of freshwater green algae surpass 0.998. We introduce a remarkably sensitive measurement technology for initial phytoplankton fluorescence to facilitate precise and accurate measurements. Consequently, noteworthy technical advancements are provided for investigating primary productivity in phytoplankton.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Ming Dong, Gaofang Yin, Nanjing Zhao, Xiang Wang, Xiaoling Zhang, Mingjun Ma, Tianhong Liang, Renqing Jia, Min Xu, Xiang Hu, Peng Huang. Accurate Acquisition of Initial Fluorescence in Phytoplankton Primary Productivity Measurement by Fluorescence Dynamics Method[J]. Acta Optica Sinica, 2024, 44(12): 1201002

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Atmospheric Optics and Oceanic Optics

    Received: Jul. 27, 2023

    Accepted: Aug. 28, 2023

    Published Online: Jun. 17, 2024

    The Author Email: Gaofang Yin (gfyin@aiofm.ac.cn), Nanjing Zhao (njzhao@aiofm.ac.cn)

    DOI:10.3788/AOS231322

    CSTR:32393.14.AOS231322
