Acta Optica Sinica, Volume. 45, Issue 13, 1306033(2025)

Optimization Scheme of Multi-Span Relay Amplification Along Optical Fiber Link for Simultaneous Sensing and Communication (Invited)

Yang Lu, Jiexuan Gu, Pengcheng Liu, Mo Chen, Qiang Bian, Jianfei Wang, Xiaoyang Hu, Yu Chen, Wei Chen, and Zhou Meng*
Author Affiliations
  • College of Meteorology and Oceanology, National University of Defense Technology, Changsha 410000, Hunan , China
  • show less

    Objective

    Developed distributed acoustic sensing (DAS) makes it possible to simultaneously sense and communicate via a single fiber link. In a long-haul optical fiber link, relay amplifiers are required to simultaneously amplify forward communication signals and Rayleigh backscattering (RBS) signals. However, cascading relay amplifiers progressively accumulate and amplify amplified spontaneous emission (ASE) noise, elevating the DAS system’s intensity noise and thereby limiting the sensing and communication distance. To this end, we conduct research on the design of multi-span relay amplification scheme in an optical fiber link. A noise model of cascaded relay amplification is established, and the influence of the relay amplification scheme on the signal-to-noise ratio (SNR) of RBS signals is theoretically analyzed. Experiments are performed, and these results confirm the validity of the theoretical analysis. We focus on analyzing the impact of key parameters of relay amplification on the noise performance of the DAS system, excluding hardware design of the relay amplifier.

    Methods

    By establishing a noise model for cascaded bidirectional erbium-doped fiber amplifiers (EDFAs), we investigate factors influencing the SNR (RSN) of RBS signals in DAS systems, including EDFA gain (G), nonlinear threshold (Pth), single span length (L), and the number of cascaded spans (M). The critical threshold for determining whether a DAS system can acquire sensing signals is when the RSN drops to 1. Based on this condition, it is essential to comprehensively optimize system parameters such as pump power (Pp), pulse width (Tp), the correlation coefficient of ASE noise (2nsphνΔν), gain coefficients (Ga, Gb), single span length (L), and the number of cascaded spans (M) to achieve the best sensing and communication performance. Finally, a DAS system with a cascaded amplified link is constructed to experimentally validate the effectiveness of the noise model.

    Results and Discussions

    For optical fiber links, each additional relay amplifier contributes to a cumulative increase in the DAS system’s noise. To maintain the SNR, it is necessary to shorten the single span length (L) and reduce the EDFA gain (G). Specifically, it can be implemented by referring to Eq. (7). Additionally, optimizing the DAS system’s probe pulse can enhance the RBS signals strength while mitigating excess noise introduced by nonlinear effects such as modulation instability (MI) and stimulated Brillouin scattering (SBS). This approach involves precisely controlling the probe pulse’s peak power and pulse width, and extending the linear frequency sweep range to exceed the fiber’s Brillouin gain bandwidth.

    Conclusions

    We conduct a comprehensive study on the design of multi-span relay amplification for integrated sensing-communication fiber links. By establishing a noise model for cascaded bidirectional EDFAs, the effects of EDFA gain (G), ASE noise (PASE), single span length (L), and the number of cascaded spans (M) on the SNR of RBS signals are investigated. Theoretical and experimental results show that this relay scheme supports a maximum single span length of 108 km. Accounting for optical nonlinear noise, we further elucidated the relationship between EDFA gain constraints and probe pulse characteristics (peak power, pulse width, and linear-frequency sweep range). This study provides a solid theoretical foundation for optimizing multi-span relay amplification in integrated sensing-communication fiber links, with significant practical relevance for fiber infrastructure monitoring and security applications.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Yang Lu, Jiexuan Gu, Pengcheng Liu, Mo Chen, Qiang Bian, Jianfei Wang, Xiaoyang Hu, Yu Chen, Wei Chen, Zhou Meng. Optimization Scheme of Multi-Span Relay Amplification Along Optical Fiber Link for Simultaneous Sensing and Communication (Invited)[J]. Acta Optica Sinica, 2025, 45(13): 1306033

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Fiber Optics and Optical Communications

    Received: May. 28, 2025

    Accepted: Jun. 6, 2025

    Published Online: Jul. 18, 2025

    The Author Email: Zhou Meng (zhoumeng6806@163.com)

    DOI:10.3788/AOS251165

    CSTR:32393.14.AOS251165
