Chinese Optics, Volume. 17, Issue 2, 342(2024)

Multi-channel laser beam combining and closed-loop correction technology in visible light band

Xin-hang XU1、*, Gao-sheng LI1,2, Bing XIE3, and Xu-dong HAN1
Author Affiliations
  • 1Changchun Institute of Optics, Fine Mechanics and Physics, Chinese Academy of Sciences, Changchun 130033, China
  • 2AVIC CAMA (ShangHai) Infrared Technology Co. Ltd, Shanghai 201306, China
  • 332031 Unit of PLA, Kaifeng 475000, China
  • show less

    To achieve periodic closed-loop correction of multiple lasers with different wavelengths in the visible wavelength band, a laser beam combining system is designed. This system involves independent monitoring and adjusting of beam pointing and position deviation. First, according to the application requirements of the system, the design indexes of the beam combining system and the overall beam combining scheme are proposed. Then, based on the overall beam combining scheme, we establish the beam control model for the beam combining system. Through numerical simulation experiments, we obtain the solution method for beam control of the beam combining system. The closed-loop beam combining system realizes independent monitoring of the unit beam’s pointing and position deviation through the respective beam pointing and position monitoring device. The monitoring results are then used to calculate the control quantity of the beam adjusting device. The independent and efficient adjustment of beam pointing and position deviation is achieved using a two-dimensional swing mirror and a one-dimensional platform, respectively. Finally, a closed-loop beam combining simulation experimental system with beam monitoring and adjustment device is built using two laser beams of different wavelengths. The periodic closed-loop beam combining system is verified to have an effective beam combing effect. The experimental results demonstrate that over an extended operational period, both lasers achieve precise beam combining with the reference optical path. Furthermore, the beam combining pointing accuracy is better than ±7 μrad, and the positioning accuracy is better than ±0.84 mm. The laser beam combining system developed in this study boast high beam combining accuracy, a fast correction speed, and excellent augmentability for multiple laser beams. Besides, it can accomplish periodic closed-loop beam combining of laser beams, ensuring long-term working stability of the combined laser.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Xin-hang XU, Gao-sheng LI, Bing XIE, Xu-dong HAN. Multi-channel laser beam combining and closed-loop correction technology in visible light band[J]. Chinese Optics, 2024, 17(2): 342

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: May. 4, 2023

    Accepted: --

    Published Online: Apr. 15, 2024

    The Author Email:

    DOI:10.37188/CO.2023-0077
