AEROSPACE SHANGHAI, Volume. 42, Issue 2, 110(2025)

Assembly Method of MBSE Model for Overall Design of Launch Vehicles

Wenfeng ZHANG, Yili JIN, Wei ZHENG*, Yuanpeng LIU, Dingrui LIU, and Shan LUO
Author Affiliations
  • Shanghai Institute of Aerospace Systems Engineering,Shanghai201109,China
  • show less

    The core of the model-based systems engineering (MBSE) method is to establish high-quality integrated models.Model assembly is the foundation for realizing MBSE integrated modeling,since single-point models are difficult to ensure the support and maintenance of the functionality and performance of an entire system.In this paper,based on the single-point MBSE models of launch vehicle systems constructed in recent years,the top-down model assembly methods are investigated.A high-level and extensible top-level model tree is built,and the assembly sequences and methods for various professional MBSE models are clarified.Finally,taking the overall performance,trajectory,and aerodynamics as examples,the construction of an integrated MBSE model for launch vehicles is realized,accelerating the transformation and implementation of MBSE.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Wenfeng ZHANG, Yili JIN, Wei ZHENG, Yuanpeng LIU, Dingrui LIU, Shan LUO. Assembly Method of MBSE Model for Overall Design of Launch Vehicles[J]. AEROSPACE SHANGHAI, 2025, 42(2): 110

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Intelligent Manufacturing and Smart Factories

    Received: Jan. 15, 2025

    Accepted: --

    Published Online: May. 26, 2025

    The Author Email:

    DOI:10.19328/j.cnki.2096-8655.2025.02.011
