Journal of Infrared and Millimeter Waves, Volume. 43, Issue 6, 833(2024)

An adaptive denoising of the photon point cloud based on two-level voxel

Zhen-Hua WANG1, Wu-Zhong YANG1, Xiang-Feng LIU1,2, Feng- Xiang WANG2, Wei-Ming XU2,3、*, and Rong SHU2,3、**
Author Affiliations
  • 1College of Information Technology,Shanghai Ocean University,Shanghai 201306,China
  • 2Key Laboratory of Space Active Opto-Electronics Technology,Shanghai Institute of Technical Physics,Chinese Academy of Sciences,Shanghai 200083,China
  • 3School of Physics and Optoelectronic Engineering,Hangzhou Institute for Advanced Study,University of Chinese Academy of Sciences,Hangzhou 310024,China
  • show less

    With a single-photon detector, photon-counting LiDAR (PCL) captures a large amount of background noise along with the target scattered/reflected echo signals, because of the influence of factors such as the background environment, target characteristics, and instrument performance. To accurately extract the signal photons on the ground surface from a noisy photon point cloud (PPC), this paper presents an adaptive denoising approach for PPC using two levels of voxels. First, coarse denoising is performed utilizing large-scale voxels, which are built based on the spatial distribution features of the PPC. The density of the voxel is then used to select the voxels that contained dense signal photons. Second, fine denoising with small-scale voxels is conducted. These voxels are built using the nearest neighbor distance, and a topologicalrelationship between voxels is used to further extract voxels containing signal photons aggregated on the ground surface. Finally, this method is performed on the PPC from ATL03 datasets collected by the Ice, Cloud, and Land Elevation Satellite-2 both during daytime and at night and compared with the improved Density-Based Spatial Clustering of Applications with Noise (DBSCAN), improved Ordering Points to Identify the Clustering Structure (OPTICS), and the method used in the ATL08 datasets. The results show that the proposed method has the best performance, with precision, recall, and F1 score of 0.98, 0.97, and 0.98, respectively.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Zhen-Hua WANG, Wu-Zhong YANG, Xiang-Feng LIU, Feng- Xiang WANG, Wei-Ming XU, Rong SHU. An adaptive denoising of the photon point cloud based on two-level voxel[J]. Journal of Infrared and Millimeter Waves, 2024, 43(6): 833

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Infrared Optoelectronic System and Application Technology

    Received: Mar. 27, 2024

    Accepted: --

    Published Online: Dec. 13, 2024

    The Author Email: XU Wei-Ming (xuwm@mail.sitp.ac.cn), SHU Rong (shurong@mail.sitp.ac.cn)

    DOI:10.11972/j.issn.1001-9014.2024.06.015
