Laser Technology, Volume. 49, Issue 4, 539(2025)
Research on laser frequency stabilization with PDH technique based on F-P cavity
In order to meet the application requirements of the frequency-stabilized lasers and make the laser frequency be freely locked in a certain range, a tunable laser stabilized to Fabry-Pérot (F-P) cavity using the Pound-Drever-Hall (PDH) technique was proposed. The laser frequency was locked on the F-P cavity by means of direct modulation of the laser current. The results show that, the fractional frequency instability turns out to be 5.3×10?12@1 s averaging time by analyzing the beat frequency from two identical lasers, which is three orders of magnitude better than free running. The linewidth of the stable laser is 381.68 kHz@10 μs and the 12 h power stability is 1.7×10?3. By controlling the F-P cavity length, the continuous tuning can be achieved over a range greater than 1.2 GHz and the tuning factor is 401.7 kHz/mV. The frequency-stabilized laser can reach the application target and its continuous tuning characteristics can effectively compensate for the limitation of the absorption cell as the frequency reference.
Get Citation
Copy Citation Text
Xinlong WANG, Jun GAO, Hanli YE, Chensheng WANG. Research on laser frequency stabilization with PDH technique based on F-P cavity[J]. Laser Technology, 2025, 49(4): 539
Category:
Received: Jun. 12, 2024
Accepted: --
Published Online: Aug. 28, 2025
The Author Email:
