Optical Instruments, Volume. 46, Issue 1, 1(2024)

Study on asynchronous locking technology of femtosecond fiber laser with full deflection maintaining

Cheng TANG, Qiang HAO*, and Zheng LIU
Author Affiliations
  • School of Optical-Electrical and Computer Engineering, University of Shanghai for Science and Technology, Shanghai 200093, China
  • show less

    In this paper, a terahertz dual-comb ranging system is constructed based on a fully bias-maintaining erbium-doped fiber laser, phase-locked loop system and terahertz ranging optical path. In the experiment, the full bias-maintaining erbium-doped fiber laser had a repetition frequency of 79.261 MHz, and the repetition frequency was locked and the frequency was adjustable at 1.54 MHz by piezoelectric ceramic (PZT) and stepper motor (SM) dual-stage feedback control scheme. The peak-peak jitter and standard deviation of jitter were ±1.5 mHz and 0.4 mHz respectively. The repetition frequency difference of the dual-comb was set at 10 Hz, and the maximum jitter and standard deviation of repetition frequency difference within 10 min were calculated to be 3 mHz and 0.6 mHz. Furthermore, the asynchronous sampling dual-comb system was applied to the terahertz ranging, and the error of measuring the moving distance was 3 μm. The system has the advantages of high locking precision and strong stability, and is expected to be used in biological nondestructive testing and industrial precision machining.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Cheng TANG, Qiang HAO, Zheng LIU. Study on asynchronous locking technology of femtosecond fiber laser with full deflection maintaining[J]. Optical Instruments, 2024, 46(1): 1

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Mar. 3, 2023

    Accepted: --

    Published Online: Mar. 6, 2024

    The Author Email: HAO Qiang (qianghao@usst.edu.cn)

    DOI:10.3969/j.issn.1005-5630.202303030034
