High Power Laser and Particle Beams, Volume. 36, Issue 11, 115023(2024)

A novel design of solid state inductive adder based on LC resonance

Xinzhe Zhai1,2, Jinhui Chen1,2、*, Guanwen Wang1, and Guanjian Wu1
Author Affiliations
  • 1Institute of High Energy Physics, Chinese Academy of Sciences, Beijing 100049, China
  • 2University of Chinese Academy of Sciences, Beijing 100049, China
  • show less

    To address the issues of low repetition frequency and short lifespan associated with the traditional thyratron half-sine pulse power supply used in accelerators, a new half-sine type inductive adder pulse power supply based on LC resonance was developed. The pulse generation is controlled by two types of switches: IGBTs in the primary side of the transformer serve as the active pulse turn-on switch, while the secondary side high-voltage silicon stack acts as the passive pulse turn-off switch. This design increases the possibility of using high-power IGBT with long turn-off delay in narrow pulse applications. By utilizing the saturation characteristic of the transformer core, the energy of the storage capacitor is self-supplied through reverse resonance in the primary side of the adder, reducing the circuit's charging time and thermal loss. By combining PSpice simulation and circuit experiments, a prototype of a 5-layer stack pulse power supply was developed and tested under different parameters. Experimental results have shown that compared to the traditional thyratron half-sine pulse power supply, this pulse power supply can achieve higher pulse repetition frequency and lower power loss.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Xinzhe Zhai, Jinhui Chen, Guanwen Wang, Guanjian Wu. A novel design of solid state inductive adder based on LC resonance[J]. High Power Laser and Particle Beams, 2024, 36(11): 115023

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Sep. 9, 2024

    Accepted: Sep. 30, 2024

    Published Online: Jan. 8, 2025

    The Author Email: Jinhui Chen (chenjh@ihep.ac.cn)

    DOI:10.11884/HPLPB202436.240316
