Photonics Research, Volume. 13, Issue 4, 1010(2025)

Reusable high-Q plasmonic metasurface

Qianwen Jia1, Junhong Deng2, Anwen Jiang1, Guoxia Yang1, Fengzhao Cao1, Min Ni1, Jiayi Zhang1, Yihe Li1, Haojie Li1,3, Dahe Liu1, Guixin Li4, and Jinwei Shi1、*
Author Affiliations
  • 1Applied Optics Beijing Area Major Laboratory and Key Laboratory of Multiscale Spin Physics, Ministry of Education, School of Physics and Astronomy, Beijing Normal University, Beijing 100875, China
  • 2Shenzhen Institute for Quantum Science and Engineering, Southern University of Science and Technology, Shenzhen 518055, China
  • 3School of Physics and Optoelectronic Engineering, Shandong University of Technology, Zibo 255000, China
  • 4Department of Materials Science and Engineering, Southern University of Science and Technology, Shenzhen 518055, China
  • show less

    Metallic nanostructures supporting surface plasmons are crucial for various ultrathin photonic devices. However, these applications are often limited by inherent metallic losses. Significant efforts have been made to achieve high quality-factor (Q-factor) resonances in plasmonic metasurfaces, particularly through surface lattice resonances (SLRs) and bound states in the continuum (BICs). Despite these advances, a direct comparison between these two mechanisms remains unexplored. Here, we report a reusable plasmonic metasurface that supports multiple high-Q resonances by leveraging hybrid plasmonic–photonic modes. By systematically tuning the lattice constant and dielectric cladding thickness, we achieve substantial Q-factor enhancements of both SLRs and BICs in a monolithic device with a small footprint of 200 μm×200 μm by using an incoherent light source. A direct comparison between these two resonances is also discussed. This high-Q performance holds significant promise for applications in sensing, lasing, and nonlinear and quantum optics, paving the way for the development of next-generation nanophotonic devices.

    1. INTRODUCTION

    Surface plasmons (SPs) have garnered significant research interests for their ability to confine light at sub-wavelength scales, thereby circumventing the diffraction limit and enabling substantial field enhancement [13]. Leveraging these unique properties, extensive studies have been conducted in various plasmonic systems, including plasmon–exciton [46], plasmon–photon [79], plasmon–phonon [10,11], and pure plasmon coupling [1217]. These studies have advanced applications in laser technology [18], sensing [16], chirality [14,15,19], optical filtering [13], perfect absorption [20], surface-enhanced Raman spectroscopy [21], nonlinear frequency-conversion enhancement [2224], etc. High quality-factor (Q-factor) plasmonic resonances are essential for enhancing light–matter interactions, lowering the threshold for lasing and nonlinear processes and increasing the sensitivity of sensors [25]. As a key focus in nanophotonics, high-Q plasmonic resonances hold promise for the development of photonic devices, sensor technologies, and other advancements.

    Localized surface plasmon resonances (LSPRs) and propagating surface plasmon polaritons (SPPs) are two fundamental modes in plasmonic systems [2628]. The Q-factors of LSPRs are usually less than 10 [29]. SPPs, excited at the metal–dielectric interface, feature extended evanescent fields, but their Q-factors are usually under 100 [28]. The intrinsic metallic losses pose significant challenges to their practical applications.

    To overcome these limitations, hybrid plasmonic modes with enhanced optical properties have been developed, including surface lattice resonances (SLRs) and Fano resonances [30,31]. SLRs, formed by the coupling of the LSPRs generated by metal nanoparticles and the Rayleigh anomalies (RAs), exhibit enhanced local fields and reduced radiation losses [3235]. Compared to LSPRs, SLRs have higher Q-factors and are widely used in sensing, laser, and nonlinear optics [18,3638]. Metal nanoparticle arrays with optimized geometry, reduced refractive index mismatches, and coherent light sources further enhance SLR excitation [39,40]. To date, Q-factors as high as 2300 in the communication band (under normal incidence) [39] and 790 in the visible (VIS) band (under oblique incidence) [41] have been reported for plasmonic SLRs.

    SLRs can be considered as bright Fano resonances, which inherently limits their Q-factors. When a Fano resonance collapses, it transitions into bound states in the continuum (BICs) [42,43]. BICs are confined states that eliminate radiation loss [44,45]. Topologically, BICs are polarized vortices in momentum space with quantized topological charges [4649]. Generally, BICs fall into two categories: symmetry-protected BICs (SP-BICs) and Friedrich-Wintgen BICs (FW-BICs) [50]. While ideal BICs are primarily theoretical, they transform into quasi-BICs (q-BICs) with finite lifetimes with broken in-plane C2 symmetry [13,16]. Though BICs have been extensively observed in dielectric systems [5158], achieving BICs in pure plasmonic systems remains challenging, due to metallic losses and the overshadowing of BICs by other bright modes with large linewidth [59]. The reported Q-factors in pure plasmonic cavities have not exceeded 150 [12,13,15,16,60,61]. Hybrid plasmonic–photonic structures, consisting of metal metasurfaces and finite dielectric layers, have been proposed [7,9,6264]. Both SLRs and BICs are advantageous for engineering radiation losses, thereby greatly expanding the available platforms for achieving high-Q resonances. However, research on BICs in the communication band within plasmonic structures is still relatively scarce. Although the coexistence of SLRs and BICs has been numerically predicted before [65], direct experimental comparisons between them in identical structures and energy bands have yet to be studied. Notably, reported Q-factors of SLRs often surpass those of BICs, which is a counterintuitive result. The main reason is that they are typically measured in different samples under varying conditions.

    In this work, we design and fabricate a series of reusable plasmonic–photonic hybrid metasurfaces that support both high-Q plasmonic SLRs and BICs. Notably, the hybrid modes supported by the metasurface can improve the resonance modulation and signal-to-noise ratio (SNR) of q-BICs near the Γ point, allowing higher measured Q-factors. The footprint of the sample is 200  μm×200  μm, significantly smaller than those used in previous studies for achieving high Q-factors. This size is among the best pixel sizes for display applications. First, we study the effects of lattice constant and dielectric cladding thickness on the Q-factors of both modes. With optimized cladding thickness, the measured Q-factors of BICs improve by an order of magnitude for all samples across VIS and near infrared (NIR) wavelengths. This improvement is quantitatively explained using Hopfield coefficients and the coupled oscillator model. Next, we demonstrate the influence of the light collecting fiber core diameter on Q-factors in the Fourier plane, showing that decreasing the core diameter can improve the resolution of the Fourier plane, which is essential for enhancing the measured Q-factors of BICs but has little effect on SLRs. The measured Q-factor of BICs at 1585 nm can reach 260. Finally, we compare the measured Q-factors of SLRs and BICs under identical structures and energy bands. The results show that the Q-factor of BICs is approximately four times that of SLR, indicating that BICs have a clear advantage over SLRs in achieving high-Q resonances, while SLRs are more robust to perturbations. That is to say, any structure that supports high-Q SLRs can also be optimized to support high-Q BICs. This work presents the first, to the best of our knowledge, experimental comparative study of Q-factors for SLRs and BICs using a reusable metasurface, greatly expanding the available platforms for high-Q resonances, which may find applications in sensing, lasing, nonlinear enhancement, photocatalysis, and other fields.

    2. MODEL

    The reusable hybrid plasmonic–photonic metasurface proposed here consists of a rectangular array of gold nanorods embedded in a dielectric cladding, as illustrated in Fig. 1(a). While the geometry of the nanorods and the lattice constant Px are fixed, the cladding thickness t and the lattice constant Py are adjustable. Polyvinyl alcohol (PVA, n1.48) is selected as the dielectric cladding material to create a homogeneous refractive index environment with the silica substrate (n1.45), facilitating the efficient excitation of SLRs. It is worth noting that the structure proposed here is similar to that in a previous work [66]; however, the previous study only employs normal incidence excitation, limiting the exploration to SLRs without considering BICs. In contrast, this work investigates both SLRs and BICs supported by the reusable hybrid metasurface, leveraging the water solubility and easy reconstruction of the PVA cladding film.

    Reusable hybrid plasmonic–photonic metasurface supporting both high-Q plasmonic SLRs and BICs. (a) Hybrid structure comprising a rectangular array of gold nanorods and a dielectric cladding. Here l=200 nm, w=80 nm, h=30 nm, Px=500 nm, and Py and t are variable. The incident plane wave is polarized along the x direction (TE excitation). (b) Schematic diagrams of SLRs and BICs. The red (blue) curves indicate the electric field in the x direction of the SLR (BIC). (c) Simulated angle-resolved transmission spectra of a sample (Py=1100 nm, t=940 nm) under TE wave excitation. The dashed white box highlights the SLR and BIC generated by modes coupling. Insets: magnified view (left panel) and radiation polarization state of high-energy branch (right panel). The red (blue) color corresponds to right-handed (left-handed) polarization. (d) Transmission spectra extracted from (c) at incident angles θ=0° and 2°. The red (blue) regions indicate the SLR (q-BIC). Insets: simulated magnitude of electric field |E| for the unit cell of both SLR (θ=0°) and q-BIC (θ=2°). The dashed white lines indicate the cladding layer. (e) Helium-ion microscopic image of one of the fabricated metasurfaces without dielectric cladding (Py=800 nm).

    Figure 1.Reusable hybrid plasmonic–photonic metasurface supporting both high-Q plasmonic SLRs and BICs. (a) Hybrid structure comprising a rectangular array of gold nanorods and a dielectric cladding. Here l=200  nm, w=80  nm, h=30  nm, Px=500  nm, and Py and t are variable. The incident plane wave is polarized along the x direction (TE excitation). (b) Schematic diagrams of SLRs and BICs. The red (blue) curves indicate the electric field in the x direction of the SLR (BIC). (c) Simulated angle-resolved transmission spectra of a sample (Py=1100  nm, t=940  nm) under TE wave excitation. The dashed white box highlights the SLR and BIC generated by modes coupling. Insets: magnified view (left panel) and radiation polarization state of high-energy branch (right panel). The red (blue) color corresponds to right-handed (left-handed) polarization. (d) Transmission spectra extracted from (c) at incident angles θ=0° and 2°. The red (blue) regions indicate the SLR (q-BIC). Insets: simulated magnitude of electric field |E| for the unit cell of both SLR (θ=0°) and q-BIC (θ=2°). The dashed white lines indicate the cladding layer. (e) Helium-ion microscopic image of one of the fabricated metasurfaces without dielectric cladding (Py=800  nm).

    Figure 1(b) presents an intuitive description of these two modes. When the wavelength of the incident electromagnetic wave meets a specific relationship with the lattice constant P (λnP, where n is the effective refractive index), surface waves propagating along opposite directions can be generated under normal incidence and form two standing wave modes. One mode corresponds to the SLR, where the electric field antinodes coincide with the nanorods. The other mode, where the electric field nodes align with the nanorods, corresponds to the BIC, which is characterized by radiation suppression.

    3. RESULTS AND DISCUSSION

    A. Theoretical Analysis

    To rigorously verify the generation of coupling modes supported by the reusable hybrid metasurface, finite-difference time-domain (FDTD) simulation and eigenmode analysis are first conducted on a metasurface with Py=1100  nm and t=940  nm, as shown in Fig. 1(c). The dashed white box marks the SLR and BIC generated by mode coupling, and the details are zoomed in insets (left panel). The high-energy branch exhibits a breakpoint at the Γ point, corresponding to the BIC with a topological charge of +1 (right panel), while the lower branch represents a bright mode, i.e., the SLR (in-plane SLR under normal incidence, out-of-plane SLR under oblique incidence).

    In this scenario, the system operating near the dashed white box can be approximated by a 3×3 Hamiltonian [13]: H=[ELSPRiγ1gstrgstrgstrERA1iγ2gbgiγ2γ3gstrgbgiγ2γ3ERA1iγ3],where gstr represents the coupling strength between the LSPR and the RAs and gbg is the coupling strength between the RAs, forming a bandgap. ELSPR denotes the resonant frequency of the LSPR, while ERA1 and ERA1 denote the resonant frequencies of the RAs (the subscripts 1 and 1 indicate the diffraction orders). γ1, γ2, and γ3 are the radiation loss, and γ2γ3 represents the radiation coupling between the RAs. At the Γ point (let ELSPR=E1, ERA1=ERA1=E2, and γ2=γ3), the corresponding eigenvalues are Ea=E2gbg,Eb=E1+E2+gbgi(2γ2+γ1)[E2E1+gbgi(2γ2γ1)]2+8gstr22,Ec=E1+E2+gbgi(2γ2+γ1)+[E2E1+gbgi(2γ2γ1)]2+8gstr22.Notably, the eigenvalue Ea has no imaginary part, indicating no radiation loss, which is consistent with the property of BICs. The hybrid modes Eb and Ec are associated with SLRs in this metasurface, which proves that BICs and SLRs have the same origin. By the way, recall that the resonance E1 depends on the geometry of the nanorods and the effective refractive index of the surrounding environment, while E2 is related to the lattice constant of the structure and also the effective refractive index of the surrounding environment. These factors can be used to tune the resonances of the two high-Q modes, providing a foundation for sensor applications based on the two modes.

    The transmission spectra from Fig. 1(c) at incident angles θ=0° and 2° are plotted in Fig. 1(d). As the incident angle increases, the SLR (highlighted in red) undergoes a red shift and an increase in the Q-factor, while the BIC transitions into a q-BIC (highlighted in blue) with a finite Q-factor. The insets display the simulated magnitude of electric field |E| for the unit cell of both SLR (θ=0°) and q-BIC (θ=2°). Oblique incidence will break the symmetry of electric field distribution, resulting in slight differences from the ideal symmetry as depicted in Fig. 1(b). To further understand the nature of SLRs and BICs, a multipole expansion of the scattering cross section of the resonances in Fig. 1(d) is performed [67]. Figures 2(a) and 2(d) illustrate the changes in the results of the multipole expansion as the incident angle θ increases from 0° to 2°. For the SLR, the electric dipole remains consistently dominant. In contrast, for the BIC, the dominant composition transitions from the electric dipole to a combination of both the electric and magnetic dipoles. While the scattering cross section of the electric dipole shows minimal change, that of the magnetic dipole increases significantly. This indicates that the excitation of the BIC at non-zero angles is closely related to the magnetic dipole. Further analysis of the electric and magnetic dipole components reveals that the SLR is predominant of an electric dipole mode along the x direction, as shown in Figs. 2(b) and 2(e), while the BIC corresponds to a magnetic dipole mode along the z direction, as depicted in Figs. 2(c) and 2(f).

    Multipole expansion. (a)–(c) Multipole expansion at incident angle θ=0°, where (b) and (c) display the dominant components of ED and MD, respectively. (d)–(f) Multipole expansion at incident angle θ=2°, where (e) and (f) show the dominant components of ED and MD, respectively. All the results are shown in logarithmic coordinate, and the highlighted areas correspond to Fig. 1(d). ED, electric dipole; MD, magnetic dipole; TD, toroidal dipole; EQ, electric quadrupole; MQ, magnetic quadrupole.

    Figure 2.Multipole expansion. (a)–(c) Multipole expansion at incident angle θ=0°, where (b) and (c) display the dominant components of ED and MD, respectively. (d)–(f) Multipole expansion at incident angle θ=2°, where (e) and (f) show the dominant components of ED and MD, respectively. All the results are shown in logarithmic coordinate, and the highlighted areas correspond to Fig. 1(d). ED, electric dipole; MD, magnetic dipole; TD, toroidal dipole; EQ, electric quadrupole; MQ, magnetic quadrupole.

    B. Effect of Lattice Period and Cladding Thickness

    To experimentally confirm the hybrid metasurface’s ability to generate high-Q resonances, a series of plasmonic metasurfaces are fabricated using electron-beam lithography (EBL) and spin-coating. Each array has the same size (200  μm×200  μm) but different lattice constants, ranging from Py=500  nm to 1100 nm (samples A–I). The cladding layer can be repeatedly cleaned and reapplied by spin-coating, allowing changes in layer thickness without damaging the metasurfaces. This enables the creation of a series of metasurfaces with varying cladding thicknesses from the same sample at a relatively low cost. This capability allows us to systematically study the effect of cladding thickness on the Q-factors of BICs and SLRs under consistent conditions, minimizing ambiguity in the analysis. Figure 1(e) shows an image of a typical fabricated metasurface (sample E) with Py=800  nm before cladding is applied.

    Subsequently, the fabricated samples are tested using a home-built experimental setup with an incoherent light source. The k-space information is obtained by point-by-point scanning in the Fourier plane using a fiber [12]. Figures 3(a)–3(c) show the measured angle-resolved transmission spectra of the three representative samples (A, E, I) with a cladding thickness t=340  nm. As the lattice constant Py increases, the excited BICs (indicated by dashed white ellipses) and SLRs (indicated by solid and dashed black arrows) redshift. The Q-factors of the BICs in the three metasurfaces range from 15 to 35, comparable to or even lower than those of the SLRs at the Γ point in the same metasurfaces (10 to 55).

    Experimentally measured angle-resolved transmission spectra of three typical reusable samples using a fiber with core diameter of 600 μm under the TE wave excitation and extracted Q-factors of BIC bands. (a)–(f) Measured angle-resolved transmission spectra of representative samples A (Py=500 nm), E (Py=800 nm), and I (Py=1100 nm) with the cladding thickness (a)–(c) t=340 nm and (d)–(f) t=940 nm. The dashed white ellipses indicate the BICs. The solid black arrows indicate the upper branch SLRs, and the dashed black arrows indicate the lower branch SLRs. (g)–(i) Extracted Q-factors of BIC bands in (a)–(f). (g) corresponds to (a) and (d), (h) corresponds to (b) and (e), and (i) corresponds to (c) and (f).

    Figure 3.Experimentally measured angle-resolved transmission spectra of three typical reusable samples using a fiber with core diameter of 600 μm under the TE wave excitation and extracted Q-factors of BIC bands. (a)–(f) Measured angle-resolved transmission spectra of representative samples A (Py=500  nm), E (Py=800  nm), and I (Py=1100  nm) with the cladding thickness (a)–(c) t=340  nm and (d)–(f) t=940  nm. The dashed white ellipses indicate the BICs. The solid black arrows indicate the upper branch SLRs, and the dashed black arrows indicate the lower branch SLRs. (g)–(i) Extracted Q-factors of BIC bands in (a)–(f). (g) corresponds to (a) and (d), (h) corresponds to (b) and (e), and (i) corresponds to (c) and (f).

    When the cladding thickness increases to 940 nm, as shown in Figs. 3(d)–3(f), richer mode coupling occurs, resulting in multiple new resonances with noticeable reduced loss in the transmission spectra. Notably, the resonances near the BICs become sharper with a pronounced increase in the Q-factor. Figures 3(g)–3(i) show the Q-factors of the band where the BICs are located (named the BIC band) extracted from Figs. 3(a)–3(f). As the cladding layer thickness increases from 340 to 940 nm, the Q-factors improve significantly by a factor of 6 to 11. The maximum Q-factors observed in these three samples are 129 at 1.68 eV (737  nm), 198 at 1.07 eV (1163  nm), and 218 at 0.78 eV (1585  nm), respectively, covering the spectrum range from the VIS to NIR. The Q-factors for all samples are summarized in Appendix A. For SLRs, the resonances of the lower branch and their Q-factors (10–66) at the Γ point do not change substantially with cladding thickness. However, the upper branches show significant improvement at the Γ point (77–123), although these values remain generally lower than those of the BICs. By closely examining the results in Fig. 3, we can qualitatively explain why the Q-factors of the BICs are greatly enhanced with a thicker cladding layer. To achieve a high Q-factor experimentally, the q-BIC should be as close as possible to the ideal BIC. For a thin cladding layer, the q-BIC near the ideal BIC is weak and lossy. In contrast, a thicker cladding layer involves more waveguide modes (WGMs), making the modulation resonance of the q-BIC stronger and closer to the ideal BIC, leading to a higher Q-factor.

    To further investigate the origin of these new resonance modes and provide a quantitative explanation for the improvement of Q-factors of BICs, detailed simulations and corresponding band fitting are performed, with parameters chosen to match sample E (Py=800  nm, t=340, 940,   nm). Figure 4(a) plots the measured and simulated transmission spectra under normal incidence. Additional resonances are observed with increasing cladding thickness. Next, cross-sectional profiles of magnitude of the electric field |E| for selected resonances indicated by red marks with t=940  nm are simulated, as shown in Fig. 4(b). Obviously, they are all bright SLRs. The electric field at 0.96 eV (1292  nm) is primarily confined to the surface of the nanorods, explaining why its resonance energy is almost unaffected by the cladding thickness. For resonances above 0.96 eV, as the cladding thickness increases, the electric field gradually shifts toward the dielectric layer, showing a different number of nodes in the z direction. This shift indicates the introduction of additional photonic WGMs with reduced absorption loss.

    Mode analysis of simulated angle-resolved transmission spectra of sample E (Py=800 nm) with different cladding thicknesses under the TE-wave excitation. (a) Measured and simulated transmission spectra under normal incidence (t=340 nm and 940 nm). (b) Near-field electric field profiles of resonances indicated in (a) for t=940 nm. The dashed white lines indicate the cladding layer. (c)–(e) Full-wave simulated angle-resolved transmission spectra with band fitting results using a coupled oscillator model. The simulated results show excellent agreement with the measured results, and only half k-space of the fitting results is presented to facilitate comparison with the simulation results. The horizontal and diagonal dashed black lines denote the LSPR and RAs with different orders, while the diagonal dashed green curves indicate WGMs with different orders. The solid curves are hybrid modes resulting from mode coupling, with the pink curves highlighting the BIC bands. (f)–(h) Hopfield coefficients of BIC bands corresponding to pink curves in (c)–(e), respectively.

    Figure 4.Mode analysis of simulated angle-resolved transmission spectra of sample E (Py=800  nm) with different cladding thicknesses under the TE-wave excitation. (a) Measured and simulated transmission spectra under normal incidence (t=340  nm and 940 nm). (b) Near-field electric field profiles of resonances indicated in (a) for t=940  nm. The dashed white lines indicate the cladding layer. (c)–(e) Full-wave simulated angle-resolved transmission spectra with band fitting results using a coupled oscillator model. The simulated results show excellent agreement with the measured results, and only half k-space of the fitting results is presented to facilitate comparison with the simulation results. The horizontal and diagonal dashed black lines denote the LSPR and RAs with different orders, while the diagonal dashed green curves indicate WGMs with different orders. The solid curves are hybrid modes resulting from mode coupling, with the pink curves highlighting the BIC bands. (f)–(h) Hopfield coefficients of BIC bands corresponding to pink curves in (c)–(e), respectively.

    Band fitting for the simulated angle-resolved transmission spectra is performed using a coupled oscillator model. The RAs and WGMs follow the dispersion relations derived from Brillouin zone folding, as shown below [68]: ωRA=±cnRA(k±2πPy),ωWGM=cnWGM(mπLcav)2+(k±2πPy)2,where ωRA and ωWGM are the resonance frequencies of the two modes, c is the speed of light in vacuum, and k and Py represent the in-plane wave vector and lattice constant in the y direction, respectively. nRA and nWGM are the effective refractive indices, m is the order of WGMs, and Lcav is the geometric thickness of the cladding layer.

    Initially, a three-mode coupled oscillator model consisting of the LSPR, RA1, and RA1 is applied in Fig. 4(c) to describe an infinite cladding layer, and the hybrid branches (solid pink curve and solid white curves) are in good agreement with the simulated results. It is notable that the upper branch in this region is very broad and weak. The Hopfield coefficients of the BIC band corresponding to pink curve are further given in Fig. 4(f), demonstrating that the BIC results from the coupling of RA1 and RA1 with opposite phases and equal contributions at the Γ point (solid red and blue curves). For this case, even though the ideal BIC consists of only two RAs, the LSPR plays a crucial role in the q-BIC nearby [12,13], which is a key reason why the reported Q-factors of the plasmonic q-BIC are not very high.

    As the cladding thickness changes from infinity to t=940  nm, the coupling of the periodic metasurface and upper cladding interface can produce a series of WGMs, as shown in Fig. 4(d), and Fano resonances occur in the spectra where multiple WGMs overlap with the hybrid branches in Fig. 4(c). The hybrid branches marked by the solid black ellipses in Fig. 4(d) are not clearly reflected in the simulated and measured angle-resolved transmission spectra due to high loss and weak strength. Figure 4(g) displays the corresponding Hopfield coefficients of the BIC band in Fig. 4(d). Away from the Γ point, the contributions of WGM1 and WGM1 become dominant very quickly, while the contribution of the LSPR is suppressed, resulting in an increased Q-factor of the q-BIC. With a further reduction of cladding thickness to 340 nm, only WGM1 and WGM1 are retained, but they are far from RAs. The modal hybridization is shown in Fig. 4(e). The Hopfield coefficients of BIC band in Fig. 4(h) show that the contribution of LSPR remains almost the same as in Fig. 4(f) in the range of k from 0 to 1, indicating that the introduction of WGMs does not significantly improve the Q-factors.

    C. Role of Core Diameter d of the Fiber

    As we know, the Q-factor of an ideal BIC should approach infinity. However, in practice, every experimental setup has finite resolution, which prevents it from reaching the ideal BIC. What is actually obtained is a q-BIC convolved with the system’s resolution. For a given sample, the higher the resolution, the higher the measured Q-factor will be. In angle-resolved measurements, the Fourier plane contains information from each angle after the incident beam passes through the sample, as shown in Fig. 5(a). Therefore, the resolution of the Fourier plane, determined by the core diameter d of the collecting fiber in this work, can significantly affect the measurement of Q-factors of BICs.

    Impact of core diameter d of the collecting fiber. (a) Schematic diagram illustrating the influence of the core diameter d on the actual resolution of the Fourier plane. (b) Measured Q-factors of BICs of all samples (A–I) by three fibers with different core diameters d=600 μm, 400 μm, and 105 μm at Γ point. Error bars are shown in the curves with d=105 μm. (c)–(f) Measured transmission spectra (solid black curves) and fitting curves (solid red curves) of SLRs (c), (d) and BICs (e), (f) of sample I using two different fibers at Γ point (d=600 μm, top panel; d=400 μm, bottom panel). The Q-factors in (b) indicated by the arrows are obtained from the fitting of the measured transmission spectra in (e) and (f), respectively.

    Figure 5.Impact of core diameter d of the collecting fiber. (a) Schematic diagram illustrating the influence of the core diameter d on the actual resolution of the Fourier plane. (b) Measured Q-factors of BICs of all samples (A–I) by three fibers with different core diameters d=600  μm, 400 μm, and 105 μm at Γ point. Error bars are shown in the curves with d=105  μm. (c)–(f) Measured transmission spectra (solid black curves) and fitting curves (solid red curves) of SLRs (c), (d) and BICs (e), (f) of sample I using two different fibers at Γ point (d=600  μm, top panel; d=400  μm, bottom panel). The Q-factors in (b) indicated by the arrows are obtained from the fitting of the measured transmission spectra in (e) and (f), respectively.

    Figure 5(b) summarizes the measured Q-factors of the BICs for all samples using three fibers with different core diameters (Appendix B). It is evident that the smaller the core diameter, the higher the measured Q-factor. However, if the core diameter is too small, the collected signal intensity becomes too weak, leading to a poor SNR and unreliable measurements. As a result, the Q-factors for samples A, B, H, and I are not provided for d=105  μm. For subsequent measurements, we use the fiber with core diameter d=400  μm instead of d=105  μm, with sample I at the Γ point serving as a reliable demonstration of improved Q-factor. The results are presented in Figs. 5(c)–5(f), where the Q-factor of SLR remains nearly constant (Q-factor 66), while the Q-factor of the BIC increases by 40 (up to 260) when the core diameter d is reduced to 400 μm. The Q-factor of 260 (1585  nm) is among the highest measured values of BICs achieved near the communication band with a sample size of 200  μm×200  μm and measured with an incoherent light source. We estimate that this value could be further improved with a smaller core diameter, a spectrometer with higher SNR, a thicker cladding layer, and a larger Fourier plane.

    D. Comparison of Q-Factors between SLRs and BICs

    As mentioned earlier, in a plasmonic system, the reported Q-factors of SLRs are generally higher than those of BICs. However, these measurements are often based on different structures and wavelength regions. In Fig. 3, we have already shown the evolution of the Q-factors of q-BICs with varying t. Here we further compare it with that of SLRs and discuss their respective advantages. Only sample I is used for this comparison, because the frequencies of q-BIC and SLR at the Γ point are very close to each other (difference: 0.021 eV), and since they are obtained from the same sample under identical excitation condition, the comparison is free of ambiguity.

    Figures 6(a) and 6(b) display part of the measured and simulated transmission spectra of the SLR band and BIC band in detail, where the highlighted red (blue) regions indicate the evolution trend of SLR (BIC) resonances. The corresponding Q-factors are extracted and shown in Fig. 6(c). At the Γ point, the measured Q-factors of SLR and BIC are 65 and 260, respectively, and the simulated Q-factors can be increased to 174 and 603 at an incident angle θ0.9°. Compared to SLR, the Q-factor of BIC is increased by 4 times (measured) and 3.5 times (simulated). These results represent significant progress for structures with similar configuration and footprint [39]. However, plasmonic BICs are more sensitive to structure parameter, defects, operating wavelengths, etc., which explains the relatively low Q-factors reported in the literature. Basically, all the structures that support high-Q SLRs can be optimized to exhibit high-Q BICs. With advancements in nanofabrication technology, optimization of structure parameters, and the improvements of measurement accuracy, plasmonic BICs with Q-factors exceeding those of SLRs can be achieved. Meanwhile, SLRs also have significant advantages, such as their ability to enhance the interaction with the far field and maintain high-Q characteristics under large excitation angles.

    Comparison of Q-factors between SLRs and BICs using a fiber with core diameter of 400 μm. (a) Measured transmission spectra of sample I under different incident angles, with the highlighted red (blue) regions indicating the evolution trend of SLR (BIC) resonances. (b) Simulated transmission spectra corresponding to (a). (c) Extracted Q-factors from the data in (a) and (b).

    Figure 6.Comparison of Q-factors between SLRs and BICs using a fiber with core diameter of 400 μm. (a) Measured transmission spectra of sample I under different incident angles, with the highlighted red (blue) regions indicating the evolution trend of SLR (BIC) resonances. (b) Simulated transmission spectra corresponding to (a). (c) Extracted Q-factors from the data in (a) and (b).

    4. CONCLUSION

    In this work, we have demonstrated the capability of a reusable hybrid plasmonic–photonic metasurface to support high-Q resonances through both SLRs and BICs. By systematically varying the cladding thickness, the introduced WGMs enhance the resonance modulation of q-BICs near the Γ point through mode hybridization. This approach allowed us to experimentally achieve significantly improved Q-factors for BICs, enhanced by a factor of 6 to 11, within a compact device footprint of 200  μm×200  μm. Our results also highlight the critical role of Fourier plane resolution in accurately measuring the Q-factors of BICs. Using fibers with smaller core diameters, we achieved a Q-factor of 260, among the highest for BICs near the communication band (Appendix C). Notably, all experiments were performed using an incoherent light source, suggesting that these results could be further optimized [39]. We also conducted a comparative study of SLRs and BICs, showing that BICs can achieve up to four times the Q-factor of SLRs under identical conditions. However, BICs are more sensitive to structural parameters and defects, whereas SLRs exhibit greater robustness and stronger interaction with the far field. This work provides a comprehensive framework for the development of high-Q metasurfaces, with potential applications in sensing, display, lasing, nonlinear and quantum optics, and plasmon modulated chemical reaction [69].

    Acknowledgment

    Acknowledgment. J.S. acknowledges financial support from NSFC. The authors thank Yang Li for help with nanofabrication and Prof. Shumei Sun for help with optical measurement.

    APPENDIX A: Effect of Cladding Thickness

    The Q-factors of BICs for all samples are measured under different cladding thickness, and the results are shown in Table 1. With the increasing of cladding thickness, the Q-factors are improved by one order of magnitude, illustrating that the cladding thickness has a significant effect on the Q-factors.

    Summary of the Measured Q-Factors of BICs for All Samples with Cladding Thickness of t=340  nm and t=940  nm, Using a Fiber with Core Diameter of 600 μma

    Q-Factor
    Cladding ThicknessA (500)B (600)C (700)D (750)E (800)F (850)G (900)H (1000)I (1100)
    t=340  nm192418141817193536
    t=940  nm129141152162198173170172218

    Q-factors of samples A–I are listed, with Py (in nm) following the sample number in parentheses.

    APPENDIX B: Role of Core Diameter d of the Fiber

    The Q-factors of BICs for all samples are measured under different core diameters, and the results are shown in Table 2. The Q-factors increase with the decrease of the core diameter, which proves the importance of Fourier plane’s resolution in measured Q-factors.

    Summary of the Measured Q-Factors of BICs for All Samples with a Cladding Thickness of t=940  nm, Using Two Fibers with Different Core Diameters da

    Q-Factor
    Core DiameterA (737)B (881)C (1021)D (1093)E (1163)F (1233)G (1303)H (1444)I (1585)
    d=600  μm129141152162198173170172218
    d=400  μm135156173189205193190215260

    Q-factors of samples A–I are listed, with Py (in nm) following the sample number in parentheses.

    APPENDIX C: Summary of Experimentally measured Q-factors of SLRs and BICs

    Experimentally measured Q-factors of SLRs and BICs in prior works are summarized in Table 3. By comparing the Q-factors of BICs and the array sizes, it can be found that the plasmonic metasurface in this work has the characteristics of both small size and high Q-factor, and enriches the study of BICs in communication band.

    Summary of the Experimentally Measured Q-Factors in Previous Works Compared to Our Resultsa

    Q-Factorλ (nm)StructureArray Size (μm×μm)MechanismLight Source
    2340 [39]1550Ag nanorods600×600In-plane SLRSCL
    1250 [39]1550Ag nanorods600×600In-plane SLRHL
    600 [39]1550Ag nanorods300×300In-plane SLRSCL
    0 [39]1550Ag nanorods300×300In-plane SLRHL
    790 [41]712Ag nanorods600×600Out-of-plane SLRSCL
    750 [35]1100V-shaped Al nanoparticles300×300In-plane SLRSCL
    536 [41]750Au nanorods600×600Out-of-plane SLRSCL
    350 [34]702Au grooves5000×5000FP-WA coupled in-plane SLRSCL
    330 [33]648Ag nanorods2500×2500In-plane SLRLDLS
    300 [32]1500Au nanostripes300×100Out-of-plane SLRHL
    260 (this work)1585Ag nanorods–dielectric film200×200Hybrid plasmonic-photonic SP-BICHL
    203 [63]1280Asymmetric Au nanodisks–polymer film–Au film400×400Hybrid plasmonic-photonic SP-BICTL
    200 [9]675Ag nanostripes–dielectric film20×20Hybrid plasmonic-photonic SP-BICHL
    145 [16]875Au nanodisksPlasmonic FW-BICSCL
    110 [61]1220Asymmetric Au nanodisks10,000×10,000Plasmonic SP-BIC
    66 [13]832Ag nanostripes–dielectric film–Ag filmPlasmonic SP-BICHL
    62 [12]443Ag grooves7×7Plasmonic SP-BICHL
    50 [62]1150Dielectric nanostripes–Au film5000×5000Hybrid plasmonic-photonic FW-BIC
    45 [20]1700Au tilted ellipse pairs–dielectric film–Au film115×115Plasmonic SP-BICQCL

    SCL, supercontinuum laser; HL, halogen lamp; LDLS, laser-driven light source; TL, tunable laser; QCL, quantum cascade laser.
