High Power Laser and Particle Beams, Volume. 36, Issue 2, 025005(2024)

Investigation of bipolar pulse source based on half-bridge structure

Yingjin Pan1, Yiming Xiong3, Zi Li1, Song Jiang1, and Junfeng Rao2、*
Author Affiliations
  • 1School of Mechanical Engineering, University of Shanghai for Science and Technology, Shanghai 200093, China
  • 2Suzhou Institute of Biomedical Engineering and Technology, Chinese Academy of Sciences, Suzhou 215163, China
  • 3State Grid Materials Co. Ltd, Beijing 100120, China
  • show less

    To meet the application requirements of pulsed electric field ablation and solve the problem of uneven distribution of unipolar pulse electric field, a bipolar submicrosecond high voltage pulse power supply with high repetition rate and nanosecond front based on the main circuit of half-bridge structure was developed. The pulse power supply is provided by the FPGA control signal, after amplifying the control signal by the driver chip, the photocoupler is used to drive multiple SiC MOSFETs. The drive circuit requires less components, its signal control timing is simple, and it can provide negative voltage bias, so that the switch tube is reliably turned off, which improves the anti-electromagnetic interference ability of the circuit, guranteeing stable operation of the power supply. Through resistance load experiment, the influence of different gate resistors on the driving voltage is compared and analyzed. The shorter the driving voltage rise time, the faster the bipolar high voltage pulse front is. The experimental results show that the designed high-frequency bipolar pulse power supply can stably generate repetitive bipolar nanosecond pulses on 100 Ω pure resistive load. The output voltage is adjustable from 0 to ±4 kV, the pulse width is adjustable from 0.2 μs to 1.0 μs, the phase delay between positive and negative pulses is adjustable from 0 to 1 ms, and the rising edge and falling edge are between 60 ns and 150 ns. The design structure of the bipolar pulse source circuit is compact, which can meet the application parameter requirements.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Yingjin Pan, Yiming Xiong, Zi Li, Song Jiang, Junfeng Rao. Investigation of bipolar pulse source based on half-bridge structure[J]. High Power Laser and Particle Beams, 2024, 36(2): 025005

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Sep. 22, 2023

    Accepted: Nov. 29, 2023

    Published Online: Mar. 21, 2024

    The Author Email: Junfeng Rao (raojunfeng1985@163.com)

    DOI:10.11884/HPLPB202436.230329
