Laser & Optoelectronics Progress, Volume. 62, Issue 14, 1411003(2025)

Correction Method for Scanning Position Errors in Ptychographic Imaging Based on Parallel Cross-Correlation

Lei Zhong1, Li Liu1, Jinxiang Du1, Honggang Gu1,3、*, and Shiyuan Liu1,2,3、**
Author Affiliations
  • 1School of Mechanical Science and Engineering, Huazhong University of Science and Technology,Wuhan 430074, Hubei , China
  • 2School of Integrated Circuits, Huazhong University of Science and Technology, Wuhan 430074, Hubei , China
  • 3Optics Valley Laboratory, Wuhan 430074, Hubei , China
  • show less

    Ptychography achieves large field-of-view, high-resolution imaging by leveraging relative movement between the illumination probe and the sample under test. However, its imaging resolution is highly dependent on the positioning accuracy of the motion stage. To address this limitation, we propose a scanning position error correction method for ptychographic imaging based on parallel cross-correlation. By constructing a virtual probe matrix, the method calculates the cross-correlation peaks among the actual probe before and after updating, as well as the virtual probe, in parallel. Additionally, a dynamic weighting function optimization is employed to achieve efficient and robust correction of scanning position errors. This approach significantly enhances the efficiency of actual probe correction while eliminating the need for complex parameter tuning or high upsampling rates. It effectively prevents oscillations and crosstalk during the convergence process and avoids local optima traps. Results demonstrate that the method achieves an accuracy of 0.005 pixel within 100 iterations. Compared to simulated annealing, particle swarm optimization, and serial cross-correlation position calibration methods, it improves convergence speed by 10×, 4×, and 3×, respectively, while boosting calibration accuracy by 20×, 10×, and 6×. These advancements pave the way for extending position error calibration to applications in Fourier ptychographic imaging and tomography.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Lei Zhong, Li Liu, Jinxiang Du, Honggang Gu, Shiyuan Liu. Correction Method for Scanning Position Errors in Ptychographic Imaging Based on Parallel Cross-Correlation[J]. Laser & Optoelectronics Progress, 2025, 62(14): 1411003

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Imaging Systems

    Received: Jan. 22, 2025

    Accepted: Feb. 25, 2025

    Published Online: Jul. 16, 2025

    The Author Email: Honggang Gu (hongganggu@hust.edu.cn), Shiyuan Liu (shyliu@hust.edu.cn)

    DOI:10.3788/LOP250563

    CSTR:32186.14.LOP250563
