High Power Laser and Particle Beams, Volume. 36, Issue 1, 011002(2024)

Reflectivity measurement of highly reflective mirrors at spectral band of 2.7−3.0 μm

Wenchao Zhou1,2, Qianhe Wei3, Chen Peng2, Dequan Huang2, and Rihong Zhu1
Author Affiliations
  • 1School of Electronic and Optical Engineering, Nanjing University of Science and Technology, Nanjing 210094, China
  • 2Institute of Applied Electronics, CAEP, Mianyang 621900, China
  • 3School of Optoelectronic Science and Engineering, University of Electronic Science and Technology of China, Chengdu 610054, China
  • show less

    The highly reflective (HR) mirrors with high-performance are widely employed in mid-infrared (mid-IR) laser systems. The manufacturing of mid-IR HR mirrors with high reflectivity requires techniques to precisely measure their high reflectivity. In this paper, a continuous-wave cavity ring-down (CRD) experimental apparatus in the 2.7-3.0 μm spectral range is established based on a quantum-cascade laser for high reflectivity measurement. By precisely optimizing the laser wavelength within the reflection band of the mid-IR HR mirrors, analyzing the influence of water vapor absorption on the ring-down time and reflectivity measurements, and comparing the reflectivity results measured under ambient air in clean-room laboratory and under nitrogen purging, the accurate measurement of high reflectivity is achieved at the 2.7-3.0 μm spectral band with an absolute reflectivity measurement accuracy of below 2×10-5 for about 99.95% reflectivity. The experimental results demonstrate that by setting the laser wavelength precisely to 2.9 μm and employing equal lengths of initial and test ring-down cavities (RDC) to avoid the influence of water vapor’s absorption lines, the reflectivity measurement for the 2.7-3.0 μm spectral band can be performed under normal clean-room laboratory air, without the need of nitrogen purging.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Wenchao Zhou, Qianhe Wei, Chen Peng, Dequan Huang, Rihong Zhu. Reflectivity measurement of highly reflective mirrors at spectral band of 2.7−3.0 μm[J]. High Power Laser and Particle Beams, 2024, 36(1): 011002

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Dec. 10, 2023

    Accepted: Jan. 15, 2024

    Published Online: Mar. 21, 2024

    The Author Email:

    DOI:10.11884/HPLPB202436.240014
