High Power Laser and Particle Beams, Volume. 36, Issue 2, 025003(2024)

Research on solid state Marx power supply with fast front

Dongsheng Li1, Zi Li1, Yonggang Wang1, Song Jiang1, and Junfeng Rao2、*
Author Affiliations
  • 1School of Mechanical Engineering, University of Shanghai for Science and Technology, Shanghai 230026, China
  • 2Suzhou Institute of Biomedical Engineering and Technology, Chinese Academy of Sciences, Suzhou 215163, China
  • show less

    Nanosecond pulse electric field ablation requires the generation of thousands of volts of nanosecond pulses on a 100 Ω load, and accelerating the pulse front is beneficial for obtaining narrower nanosecond pulses. This article proposes a solid-state Marx generator with a fast front, which inserts an inductor into each stage of the circuit and allows the discharge tube and charging tube to conduct simultaneously for tens of nanoseconds. After the discharge tube is fully opened, the charging tube is turned off to discharge the load, eliminating the limitation of stray inductance on the pulse front by the discharge tube and discharge circuit, and obtaining a high-voltage pulse with a fast front. A 32 level Marx prototype was built, and in the experiment, a high-voltage pulse with a voltage rise of 35 ns, a pulse width of 800 ns, and a current of 186 A was obtained on a low resistance load of 100 Ω by adjusting the through time. We compared and analyzed the effect of the direct time between the charging tube and the discharge tube on the rising edge, and found that the longer the direct time, the faster the front of the pulse current. The maximum peak current at the output end can reach 186 A. This indicates that the pulse voltage source can effectively increase the current output and improve the system’s load capacity. Compared with traditional improvement methods, this scheme not only improves the system’s anti-interference ability, but also reduces the number of switches used and reduces the cost of pulse power supply.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Dongsheng Li, Zi Li, Yonggang Wang, Song Jiang, Junfeng Rao. Research on solid state Marx power supply with fast front[J]. High Power Laser and Particle Beams, 2024, 36(2): 025003

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category:

    Received: Jun. 28, 2023

    Accepted: Nov. 6, 2023

    Published Online: Mar. 21, 2024

    The Author Email: Junfeng Rao (raojf@sibet.ac.cn)

    DOI:10.11884/HPLPB202436.230197
