Opto-Electronic Engineering, Volume. 52, Issue 4, 240294(2025)

Repetitive-control-based high-frequency disturbance suppression method in tip-tilt correction

Nian Feng1,2,3,4, Tao Tang1,2,3、*, and Long Hu1,2,3,4
Author Affiliations
  • 1National Key Laboratory of Optical Field Manipulation Science and Technology, Chinese Academy of Sciences, Chengdu, Sichuan 610209, China
  • 2Key Laboratory of Optical Engineering, Chinese Academy of Sciences, Chengdu, Sichuan 610209, China
  • 3Institute of Optics and Electronics, Chinese Academy of Sciences, Chengdu, Sichuan 610209, China
  • 4School of Electronics, Electrical and Communication Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
  • show less

    Disturbance suppression, especially high-frequency disturbance suppression beyond the closed-loop bandwidth, is the core of realizing high-precision stability control for tip-tilt correction systems. Repetitive control has good performance of periodic trajectory tracking and disturbance suppression, which is applied to the stability control of high-precision systems. The high-frequency disturbance suppression problem of the tip-tilt correction system is analyzed in this paper, and the performance of high-frequency disturbance suppression based on repetitive control is summarized. To solve the problems of natural frequency drift and waterbed amplification in traditional repetitive controllers, a comb-like repetitive controller based on Youla parameterization is designed to suppress high-frequency disturbances beyond the closed-loop bandwidth. In order to solve the problem that the integer-order repetitive control is only effective for specific frequency points, especially in most high frequency regions, the controller will fail due to disturbance fluctuations and uncertainty, an all-pass frit-order delay filter is optimized to suppress the high frequency disturbance at any frequency point up to Nyquist frequency in the tip-tilt correction system. Finally, a parallel repetitive control scheme is designed to suppress the vibration of aperiodic structures which is difficult to suppress, and its robust stability and effectiveness are discussed.

    Keywords
    Tools

    Get Citation

    Copy Citation Text

    Nian Feng, Tao Tang, Long Hu. Repetitive-control-based high-frequency disturbance suppression method in tip-tilt correction[J]. Opto-Electronic Engineering, 2025, 52(4): 240294

    Download Citation

    EndNote(RIS)BibTexPlain Text
    Save article for my favorites
    Paper Information

    Category: Article

    Received: Dec. 16, 2024

    Accepted: Mar. 3, 2025

    Published Online: Jun. 11, 2025

    The Author Email: Tao Tang (唐涛)

    DOI:10.12086/oee.2025.240294
